468
6-3. Do-it-yourself maintenance
Fuse
34 DOME
35 MPX-B
36 IGCT NO.4
37 IGCT NO.3
38 IGCT NO.2
39 IG2 NO.1
40 GAUGE
41 DC/DC
42 P/I DC/DC
43 RH J/B DC/DC
44 LH J/B DC/DC
45 H-LP CLN
46 FAN NO.2
47 LUG J/B DC/DC
48 FAN NO.1
49 PTC NO.1
50 PTC NO.2
51 HTR
GS450h_OM_OM30E26U_(U)
Ampere
Personal lights, ornament lights, trunk light,
footwell lights, door courtesy lights, vanity
7.5
lights, rear door inside handle illuminations,
power trunk opener and closer
Body ECU, smart access system with push-
button start, electric tilt and telescopic steer-
ing column, power seats, head-up display,
10 front door ECU, gauges and meters, steer-
ing sensor, yaw rate and G sensor, overhead
module, RR CTRL SW, power trunk opener
and closer, clock, CAN gateway ECU
10 Power control unit
Hybrid battery (traction battery), DC/DC
7.5
converter
5 Hybrid system
5 DCM, CAN gateway ECU
5 Gauges and meters
RH-J/B DC/DC, P/I DC/DC,
150
LH-J/B DC/DC, LUG-J/B DC/DC
RR S/SHADE, DEFOG, FOG, TAIL,
100
PANEL
80 Right-hand junction block
50 Left-hand junction block
30 Headlight cleaner
40 Electric cooling fans
80 Luggage compartment junction block
80 Electric cooling fans
50 PTC heater
50 PTC heater
50 Air conditioning system
Circuit
