Owners &
Installation
LISTINGS
AND
CODE
APPROVALS
These gas appliances have been
tested in accordance with AG 103,
NZS 5262 and have been certified
by the Australian Gas Association
for installation and operation as
described in these Installation and
Operating Instructions.
Your unit should be serviced
annually by an authorised
service person.
F33 Freestanding Gas Stove
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause inju-
ry or property damage. Refer to this manual.
For assistance or additional information
consult an authorized installer, service agen-
cy or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flamma-
ble vapours and liquids in the vicinity of this
or any other appliance.
Installation and service must be performed by
an authorized installer, service agency or the
gas supplier.
908-878a
Model:
F33-NG1
F33-LPG1
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any ap-
pliance
Do not touch any electrical
switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fire
department.
01/10/06
Advertisement
Table of Contents
Related Manuals for Regency F33-NG1
Summary of Contents for Regency F33-NG1
- Page 1 Owners & Installation F33 Freestanding Gas Stove Model: F33-NG1 F33-LPG1 PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, altera- What to do if you smell gas: tion, service or maintenance can cause inju- Do not try to light any ap- ry or property damage.
- Page 2 The models F33-NG1 and F33-LPG1 have been approved by the Australian Gas Association for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow.
-
Page 3: Table Of Contents
Optional Wall Thermostat ......12 Final Check ..........12 OPERATING INSTRUCTIONS Operating Instructions ......13 Lighting Procedure .........13 Shutdown Procedure ......... 13 Copy of Lighting Plate Instructions .... 14 Normal Operating Sounds of Gas Appliances ........15 Regency F33-1 Freestanding Gas Stove... -
Page 4: Safety Label
SAFETY LABEL This is a copy of the label that accompanies each Regency DATA BADGE NOTE: Regency units are constantly being F33-1 Freestanding Gas Stove. We have printed a copy of the improved. Check the label on the unit and if there is a difference, contents here for your review. -
Page 5: Installation
Before leaving this unit with the customer, the installer must To prevent injury, do not allow anyone who is unfamiliar with ensure that the appliance is firing correctly and operation fully the operation to use the fireplace. explained to customer. Regency F33-1 Freestanding Gas Stove... -
Page 6: Clearances To Combustibles
CAUTION: Any alteration to the product that causes sooting or Push the Regency logo into the two holes in the front bottom carboning that results in damage is not the responsibility of the left corner of the pedestal cover plate. -
Page 7: Wiring Instructions For Pedestal & Leg/Bottom Shield Assembly
10) Connect the orange wire from the spill switch to the Burner ON/OFF switch. 11) Re-connect the fan harness plug. 12) Secure the power cord with the supplied grommet at the back of the Bottom Shield or Pedestal. Wiring Diagram on page 8. Regency F33-1 Freestanding Gas Stove... -
Page 8: Draft Hood
610m. we recommend that a minimum flue height of 3.6m is used. For your safety this heater is equipped with a flue safety switch. This thermally actuated switch is located within the draft hood Regency F33-1 Freestanding Gas Stove... -
Page 9: Gas Connection
Make sure the valve is in the "OFF" position. Loosen the "IN" and/or "OUT" pressure tap(s), turning counterclockwise with a 1/8" wide flat screwdriver. Attach manometer to "IN" and/or "OUT" pressure tap(s) using a 5/16" ID hose. Regency F33-1 Freestanding Gas Stove... -
Page 10: Test For Flue Spillage
Place the cross logs on top of the larger logs aligning the holes on the underside of the cross log with the log pins in the larger logs. See diagrams 1 & 2. Carefully push the cross logs onto the pins. Diagram 1 Regency F33-1 Freestanding Gas Stove... -
Page 11: Safety Latch
If the flame hesitates at any point, check the area of hesita- tion and see if there is an ember or rock wool blocking a burner port or ports. If so, move the obstruction and then check the flame flow again. Regency F33-1 Freestanding Gas Stove... -
Page 12: Optional Remote Wall Switch
OPTIONAL REMOTE CONTROL (Two-Wire) When Using Wall Thermostat (CP-2 System) INSTALLATION Wire Size Max. Length Use the Optional Regency Remote Control Kit approved for this 14 GA. 15.24 m unit. Use of other systems may void your warranty. 16 GA. 9.75 m 18 GA. -
Page 13: Operating Instructions
IT IS IN OPERATION control to turn off the burner. Push in the PILOT knob slightly and turn clockwise to off. Do not force. Turn off all electric power to the appliance if service is to be performed. Regency F33-1 Freestanding Gas Stove... -
Page 14: Copy Of Lighting Plate Instructions
OPERATING INSTRUCTIONS COPY OF THE LIGHTING PLATE INSTRUCTIONS Regency F33-1 Freestanding Gas Stove... -
Page 15: Normal Operating Sounds Of Gas Appliances
Blower: The appliance and fluing system must be inspected before Regency gas appliances use high tech blowers to push heated use, and at least annually, by an authorised field service air farther into the room. It is not unusual for the fan to make a person, to ensure that the flow of combustion and ventilation "whirring"... -
Page 16: General Flue Maintenance
If for any reason a log should need replacement, use only Regency replacement logs. The position of these logs must 11) Slip door over hinge pins and put hinge caps back onto door. be as shown in the diagram under Log Installation. -
Page 17: Aeration Adjustment
Shut off gas supply. Note: If you have an incorrect flame pattern, contact your If optional fan is installed, disconnect power source to Regency dealer for further instructions. stove. Remove access panel. a) Front panel on pedestal model. See diagram 1. -
Page 18: Installing Valve Assembly
To install a new valve assembly, reverse instructions for remov- ing valve. See assembly steps 1-11. Check for leaks and manifold pressure. See Gas Pressure Test instructions. To reinstall valve, reverse instructions for removing valve assembly, steps 12-18. Regency F33-1 Freestanding Gas Stove... -
Page 19: Fan Replacement
Loosen the four 8-32 x 1/2 screws provided into the nutserts as shown in diagram 3. NOTE: Make sure the fan is supported as it may fall when the 4 screws are loosened. Wiring Diagram Diagram 3 Regency F33-1 Freestanding Gas Stove... -
Page 20: Service
• Follow same steps for thermocouple. Note: For service technicians only. See the Regency Troubleshooting Guide for more detailed information. (Troubleshooting Regency Gas Products) ABNORMAL OPERATION If the main burner does not light but pilot stays on shut down heater and contact your dealer... -
Page 21: Parts List
Hinge Cap - Gold Plated (2/set) Screw #10 - 24 x 3/4" Pan Head Washer 1/4" split lock Screw #10 - 24 x 1/2 Pan Head 471-031 Door Retainer Clip 948-101 Spring Handle - Large Regency F33-1 Freestanding Gas Stove... - Page 22 Orifice #36 (NG) 904-390 Orifice #52 (LPG) *Not available as a replacement part. 948-294 Burner - NG 948-279 Burner - LPG Complete Burner Tray Assy-SIT-NG Complete Burner Tray Assy-SIT-LPG 490-023 Front Log Deflector - NG/LPG Regency F33-1 Freestanding Gas Stove...
- Page 23 123) * Pedestal Blanking Plate 124) 820-058 Pedestal Cover 140) 850-127 Cast Legs - Gold 125) * Rear Cover Plate 140) 850-126 Cast Legs - Black 142) 850-125 Steel Legs *Not available as a replacement part. Regency F33-1 Freestanding Gas Stove...
- Page 24 NOTES Regency F33-1 Freestanding Gas Stove...
- Page 25 NOTES Regency F33-1 Freestanding Gas Stove...
- Page 26 NOTES Regency F33-1 Freestanding Gas Stove...
-
Page 27: Warranty
Regency, may nullify your warranty on this product. valves are covered for one year from the date of purchase. Regency Industries Ltd., shall in no event be liable for any special, indirect consequential damages of any nature whatsoever which Conditions: are in excess of the original purchase price of the product. - Page 28 © Copyright 2004, FPI Fireplace Products International Ltd. All rights reserved. MADE IN CANADA...
