Owners &
Installation
Freestanding Woodstove
Vancouver
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional in-
formation consult an authorised installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other fl am-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
918-348
Model: F2402M
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electri-
cal switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fi re
department.
12/07/11
Advertisement
Table of Contents
Related Manuals for Regency Vancouver F2402M
Summary of Contents for Regency Vancouver F2402M
- Page 1 Owners & Installation Freestanding Woodstove Vancouver Model: F2402M PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, altera- What to do if you smell gas: tion, service or maintenance can cause Do not try to light any appli- injury or property damage.
- Page 2 The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area.
-
Page 3: Table Of Contents
TABLE OF CONTENTS THE REGENCY FREESTANDING WOOD STOVE Optional Accessories Installation SAFETY LABEL - Pedestal Ash Drawer Kit ..........16 - Bottom Shield Ashdrawer Kit........16 Copy of Data Badge ..............4 - Screen Door ...............16 - Blower/Fan ..............17 INSTALLATION - Blower/Fan Wiring Diagram ........17 Unit Dimensions ..............5... -
Page 4: Safety Label
SAFETY LABEL This is a copy of the label that accompanies each NOTE: Regency units are constantly being Regency Freestanding Woodstove (F2402M). improved. Check the label on the unit and if We have printed a copy of the contents here there is a difference, the label on the unit is the correct one. -
Page 5: Unit Dimensions
UNIT DIMENSIONS 27-3/8” (695mm) 24-7/8” (632mm) 6-5/8” (168mm) 24” (610mm) Regency Freestanding Woodstove... -
Page 6: Residential Installation
MODULAR INSTALLATION OPTIONS The following items are required when assembling your Regency Stove. F2402M unit - the Rear Heat Defl ector is supplied with the stove, but if you choose not to use it you must use the Airmate instead. -
Page 7: Minimum Clearance To Combustibles
INSTALLATION AUSTRALIA ONLY IMPORTANT The Regency F2402M has been tested with the fl ue kits listed Use only the instructions and clearance dimensions on this page for below. A default fl ue kit as listed in AS/NZS 2918:2001 may also heaters to be installed in Australia. -
Page 8: Minimum Alcove Clearances
INSTALLATION Minimum Alcove Clearance to Combustible Materials The Regency Freestanding models have been alcove approved and must be installed with a listed double wall connector to the ceiling level. Note: Minimum alcove ceiling height - 84" (2134mm) Maximum depth of alcove - 36" (914mm) -
Page 9: Stove Assembly Prior To Installation
See diagrams 2 & 3. Rear Heat Defl ector Assembly The rear heat defl ector is supplied with the stove Diagram 2 Diagram 3 Regency Freestanding Woodstove... -
Page 10: Leg And Bottom Shield Assembly
Ensure that the legs are properly aligned with heat shield and tighten the bolts. 4) Push the Regency logo into the two holes in the front bottom left corner of the pedestal 4) Level the stove by adjusting the levelling cover plate. -
Page 11: Masonry Chimney
"T" section package, fi restops (where needed), insulation shield, roof fl ashing, chimney cap, etc. Maintain proper clearance to the structure as recommended by the manufacturer. The chimney must be the required height above the roof or other obstructions for safety and proper draft operation. Regency Freestanding Woodstove... -
Page 12: Combustible Wall Chimney Connector Pass-Throughs
Cover opening with and support chimney section on both sides with 24 gage minimum sheet metal supports. See that the supports are fastened securely to wall surfaces on all sides. Make sure fasteners used to secure chimney fl ue liner. Regency Freestanding Woodstove... -
Page 13: Recommended Height For Woodstove Flue
18.0 19.0 23.0 20.5 25.5 8000-9000 16.0 17.0 18.5 20.0 24.0 21.0 26.5 9000-10000 16.5 17.5 19.0 20.5 24.5 22.0 27.0 NOTE: No more than two offsets (four elbows) allowed. Two 45 elbows equal one 90 elbow. Regency Freestanding Woodstove... -
Page 14: Mobile Home Installation
11) WARNING: DO NOT INSTALL IN A SLEEP- ING ROOM OF A MOBILE HOME. 12) Use silicone to create an effective vapour barrier at the location where the chimney or other component penetrates to the exterior of the structure. Regency Freestanding Woodstove... -
Page 15: Listed Components For Mobile Home Installation
FOR MOBILE HOME 6DVL8693 Connector Kit 6DP-MH9096 Mobile Home Kit INSTALLATION ICC EXCEL 2100 The Regency F2402M and S2402M Freestanding Qty.Part # Description pedestal units are approved for installation in a 6CL48 48" (1219mm)Chimney length Mobile Home if one of the following pipe systems Front View (also in 12"... -
Page 16: Brick Installation
3) Remove the ash dump cover plates (one inside the fi rebox and one on the underside of the fi rebox) by removing the two nuts and bolts holding the 2 plates together from inside Handle at 10 o'clock position. the fi rebox. Regency Freestanding Woodstove... -
Page 17: Blower/Fan
(grounding) plug for your protection against shock when servicing controls. Wiring errors can cause hazard and should be plugged directly into a properly improper and dangerous operation. grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug. Regency Freestanding Woodstove... -
Page 18: Operating Instructions
DRAFT CONTROL a fi replace in your home, a downdraft may be created by your Regency Stove causing 4) After about 45 minutes, when your wood Both the primary and air wash drafts are control- a draft down your chimney. If this occurs,... -
Page 19: Fan Operation
Manual and carry away. To manually operate the fan system push the 7) Your Regency stove can be very hot. You bottom switch to "MAN" and the top switch may be seriously burned if you touch the to either "HIGH" or "LOW". This will bypass... -
Page 20: Maintenance
Dealer. GLASS MAINTENANCE 1. Close all draft and damper controls. WOOD STORAGE Your Regency stove is supplied with 5 mm 2. CALL THE FIRE DEPARTMENT. Neoceram ceramic glass (Part #846-302) that will withstand the highest heat that your unit will... -
Page 21: Parts List
Retainer Plate - Ash Dump - Top Nut - 1/4 - 20 Hex 918-348 Manual 846-570 7/8" Door Gasket Repair Kit 846-918 Hinge Cap - Gold (2/set) *Not available as a replacement part. 948-101 Spring Handle - Large 948-102 Spring Handle - Small Regency Freestanding Woodstove... -
Page 22: Pedestal, Bottom Shield And Legs
Ash Plug Tool Handle 140) 850-126 Legs - Cast Black 850-127 Legs - Cast Gold 850-128 Legs - Cast Brush Nickel 142) 850-125 Legs - Steel Black 948-216 Logo - Regency *Not available as a replacement part. Regency Freestanding Woodstove... -
Page 23: Firebrick
Part # Description 902-111 Brick - Regular Full Size: 1-1/4" x 4-1/2" x 9" 802-147 Brick Partial: 1-1/4" x 4-1/2" x 3-1/2" 802-122 Brick Partial: 1-1/4" x 4-1/2" x 2" 802-152 Brick Partial: 1-1/4" x 2" x 9" Regency Freestanding Woodstove... - Page 24 NOTES Regency Freestanding Woodstove...
- Page 25 NOTES Regency Freestanding Woodstove...
- Page 26 NOTES Regency Freestanding Woodstove...
-
Page 27: Warranty
Conditions: Any part or parts of this unit which in our judgement show evidence of such defects will be repaired or replaced at Regency Fireplace Products option, through an accredited distributor or agent provided that the defective part be returned to the distributor or agent Transportation Prepaid, if requested. In areas where there is not an approved service agent or the closest approved service agent is situated more than thirty (30) kilometres from the installation, Regency is not obliged to arrange warranty repairs and travel and/or additional labour charges will apply. - Page 28 DISTRIBUTORS: Western Australia Eastern Australia AIRGROUP AUSTRALIA 28 DIVISION ST. WELSHPOOL, WA 6106 SERVICE AGENTS: AIRGROUP AUSTRALIA 28 DIVISION ST. WELSHPOOL, WA 6106 NOTE: PLEASE RETAIN YOUR INVOICE AS PROOF OF PURCHASE FOR WARRANTY VERIFICATION INCORRECT INSTALLATION OR GAS PRESSURE SETTINGS ARE NOT COVERED BY WARRANTY A SERVICE OR CALLOUT FEE WILL BE CHARGED IN THESE CIRCUMSTANCES.
