Toshiba E-studio2007 Quick Manual

General Print & copy Speed
20/25/25 ppm (A4)
14/14/14 ppm (A3)
warm-up Time Approx. 20 seconds
Paper Size & weight Cassette: B5-A3, 64-80 g/m
Bypass: A5R-A3, 52-163 g/m
Paper capacity
1x 250 sheets (Cassette), 100 sheets (Bypass)
Maximum: 1,700 sheets
Automatic Duplex A5R-A3, 64-80 g/m
1)
Inner Output Tray
100 sheets
Memory 512 MB
Interface 10/100 BaseT (incl. IPv6), High Speed USB 2.0,
WLAN 2) (IEEE802.11b/g/n)
Dimension & weight 575 x 540 x 402 mm (W x D xH), ~ 25.5 kg
Starter kit
Toner, Drum, Developer
Print Resolution Max. 2,400 x 600 dpi with smoothing
Page Description language PCL6 emulation
Supported Systems
Windows 8/7/Vista/XP/Server 2008/Server 2003
(32/64 bit), Server 2012/Server 2008R2 (64 bit)
Print Functions Multiple pages per sheet, Rotate sort
Toner save mode
Scan Resolution Max. 600 x 600 dpi
Scan Speed 25/7 ipm (monochrome/colour with 300 dpi)
Scan Modes
Colour, Greyscale, Monochrome
File Formats JPEG, Multi/Single Page TIFF, Multi/Single Page PDF
Scan Functions Scan to USB, Scan to E-Mail, Scan to File (SMB,
FTP), TWAIN
copy Resolution Scan: 600 x 600 dpi
Print: max. 2,400 x 600 dpi with smoothing
First copy Output Time
Approx. 7 seconds
Zoom 25-400%
copy Modes Text, Text/Photo, Photo, Background erase
copy Functions Electronic sort, Rotate sort
edge erase, 2-in-1/4-in-1 mode
Fax communication Super G3, G3
2)
Transmission Speed Approx. 3 seconds per page
compression JBIG, MMR, MR, MH
Fax Memory 6 MB Transmission/Reception
Network-fax Driver Windows 8/7/Vista/XP/Server 2008/ Server
2003 (32/64 bit), Server 2012/Server 2008R2 (64 bit)
Fax Functions
One-touch dialing (5 keys), group dialing
System & Device Management Top Access for remote administration and
Security configuration
System Features
Internal toner recycling, Energy save modes
Accounting & Security IP and MAC address filter
Productivity and paper specifications are related to a paper size of A4 and a paper weight of 80 g/m
otherwise mentioned.
T O S H I B A T E C G E R M A N Y
IMAGING SYSTEMS GMBH
CARL-SCHURZ-STRASSE 7 · D-41460 NEUSS
TEL. +49(0)2131-12450, FAX +49(0)2131-1245402
WWW.TOSHIBA-EUROPE.COM/TEC
OPTIONS
RADF – MR-3027
2
50-sheet capacity, A5R-A3, 50-104 g/m
2
AuTOMATIc DuPlex uNIT – MD-0106
2
A5R-A3, 64-80 g/m
2
PAPeR FeeD uNIT – MY-1043
250-sheet capacity, B5-A3, 64-80 g/m
575 x 565 x 117 mm (W x D x H), ~ 5.5 kg
PAPeR FeeD PeDeSTAl – KD-1039
550-sheet capacity, A5R-A3, 64-80 g/m
575 x 565 x 406 mm (W x D x H), ~ 29 kg
, DRAweR MODule – MY-1044
3)
550 sheet cassette for PFP KD-1039,
A5R-A3, 64-80 g/m
2
OTHeR OPTIONS
DESK – MH-2507
FAX BOARD – GD-1330
WIRELESS LAN MODULE – GN-1080
3) , ID card copy,
Standard for e-STUDIO2507i
1)
2) Optional
Requires Paper Feed Unit
3)
2 if not
2
1)
2
2
Document
Manager
A3 document manager with print, scan, copy and fax functionality
n
Excellent image quality thanks to advanced Toshiba technology
n
Network capable systems ideal for small workgroups and offices
n
Compliant with highest environmental standards
n
Networking Documents.
