ADJUSTMENT MODE CH LIST

CH RX TX
A01 479.275 450.275 A01 LW TXREF ***
A03 465.075 465.275
A03 LW MRTUN ***
A05 450.075 450.275
A05 LW RPTSQL***
A06 450.075 450.275
A06 HW POWER ***
A07 465.075 465.275
A07 LW M DEV ***
A08 450.075 450.275
A08 LW LMODC ***
A09 479.925 479.725
A09 LW HMODC ***
A10 465.075 465.275
A10 LW CTCDEV***
A11 450.075 465.275
A11 LW DTCADJ***
A12 465.075 465.275
A12 LN CTCDEV***
A13 460.275 465.275
A13 LW RPTAF ***
A14 465.075 465.275
A14 LN RPTAF ***.
I LCD DISPLAY IN THE ADJUSTMENT MODE
LCD DISPLAY
A01 LW TXREF 127
4 - 3
W/N
BAND
H W TVCO/RVCO adjustment.
Reference frequency adjustment.
M W RX sensitivity adjustment.
L W RPT SQL adjustment.
M W TX power adjustment.
M W TX modulation adjustment.
L W TX modulation adjustment.
H W TX modulation adjustment.
M W CTCSS modulation adjustment
M W DTCS modulation adjustment.
M N CTCSS modulation adjustment. (NARROW)
M W RPT modulation adjustment.
M N RPT modulation adjustment.
Adjustment value
Adjustment item
Band width (WIDE)
TX power (LOW)
Adjustment frequency channel
ADJUSTMENT
(WIDE)
(NARROW)
