[FRONT UNIT]

REF ORDER
NO. NO.
Q1 1530002060 S.TRANSISTOR
D1 1750000930 S.DIODE
D2 1750000930 S.DIODE
D3 1750000930 S.DIODE
L1 6200001620 S.COIL
R1 7030003400 S.RESISTOR
R2 7030003200 S.RESISTOR
R3 7030003200 S.RESISTOR
R8 7030001150 S.RESISTOR
R9 7030001150 S.RESISTOR
R10 7030001160 S.RESISTOR
R11 7030001150 S.RESISTOR
R12 7030001150 S.RESISTOR
R13 7030001150 S.RESISTOR
R15 7030003460 S.RESISTOR
R17 7030008220 S.RESISTOR
R18 7030008220 S.RESISTOR
R19 7540000240 S.ABSORBER
R21 7030003640 S.RESISTOR
R22 7030003640 S.RESISTOR
R23 7030003640 S.RESISTOR
R24 7030003640 S.RESISTOR
R26 7030003640 S.RESISTOR
R27 7030010910 S.RESISTOR
R28 7030010910 S.RESISTOR
C1 4030006860 S.CERAMIC
C2 4030006860 S.CERAMIC
C3 4030006860 S.CERAMIC
C4 4030006860 S.CERAMIC
C5 4030006860 S.CERAMIC
C12 4030006860 S.CERAMIC
C13 4030006860 S.CERAMIC
C14 4030006860 S.CERAMIC
C15 4030006860 S.CERAMIC
C16 4030006860 S.CERAMIC
C17 4030017200 S.CERAMIC
C18 4030017200 S.CERAMIC
J1 6510022620 S.CONNECTOR
J2 6510022580 S.CONNECTOR
J3 6510021600 S.CONNECTOR
J4 6510022910 CONNECTOR
J6 6510022790 CONNECTOR
J7 6450001470 CONNECTOR
J8 6510023250 S.CONNECTOR
J9 6510021600 S.CONNECTOR
DS1 5040001820 LED
DS2 5040001820 LED
DS3 5040001330 LED
DS4 5040001820 LED
DS5 5040001820 LED
DS6 5040001820 LED
DS7 5030002190 LCD
S1 2260001680 S.SWITCH
S2 2260001680 S.SWITCH
S3 2260001680 S.SWITCH
S4 2260001680 S.SWITCH
S5 2260001680 S.SWITCH
S6 2260001680 S.SWITCH
S7 2260001680 S.SWITCH
S8 2260001680 S.SWITCH
EP1 0910056085 PCB
EP2 6910014560 SPACER
EP3 6910014550 SPACER
EP4 6910014540 SPACER
EP5 6910014540 SPACER
EP6 6910014540 SPACER
DESCRIPTION
2SC4081 T106 R
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
ELJFC 1R0K-F
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 100 V (10 Ω)
MCR50JZHJ 150 Ω (151)
MCR50JZHJ 150 Ω (151)
MCR50JZHJ 180 Ω (181)
MCR50JZHJ 150 Ω (151)
MCR50JZHJ 150 Ω (151)
MCR50JZHJ 150 Ω (151)
ERJ3GEYJ 152 V (1.5 kΩ)
MCR100JZHJ 47 Ω (470)
MCR100JZHJ 47 Ω (470)
KU10R29N-4063
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ1TYJ 150U (15 Ω)
ERJ1TYJ 150U (15 Ω)
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
GRM31BR32J102KY01L
GRM31BR32J102KY01L
10FMN-BMTTR-A-TBT
24FMN-BMTTR-A-TBT
S2B-PH-SM3-TB
IMSA9201B-1-16Z012Z
95003-2641
95003-2881
S3B-PH-SM3-TB
S2B-PH-SM3-TB
BG3889S
BG3889S
BR3889S
BG3889S
BG3889S
BG3889S
MSC-C161UYLT-4W
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
SKQDPB
B 5652E
LM-15
LM-13
LM-10
LM-10
LM-10
[FRONT UNIT]
REF ORDER
NO. NO.
EP7 6910014540 SPACER
[LOGIC UNIT]
REF ORDER
NO. NO.
IC1 1110003780 S.IC
IC2 1110003780 S.IC
IC3 1110003780 S.IC
IC4 1110003780 S.IC
IC6 1110002400 S.IC
IC7 1110003780 S.IC
IC8 1110003780 S.IC
IC9 1110003780 S.IC
IC10 1110003780 S.IC
IC11 1180000420 S.IC
IC12 1110003780 S.IC
IC13 1130008090 S.IC
IC14 1130004200 S.IC
IC16 1130006220 S.IC
IC17 1110003090 IC
IC20 1130006220 S.IC
IC21 1130006220 S.IC
IC25 1190001350 S.IC
IC26 1110003800 S.IC
IC28 1110002400 S.IC
IC29 1190001720 S.IC
IC30 1130006220 S.IC
IC31 1130007400 S.IC
IC32 1130006220 S.IC
IC33 1140010140 S.IC
IC34 1110005710 S.IC
IC35 1130009320 S.IC
IC36 1130009320 S.IC
IC37 1140008650 S.IC
IC38 1180002250 S.IC
IC39 1130007570 S.IC
IC40 1130007570 S.IC
IC41 1130007570 S.IC
IC42 1170000280 S.IC
IC43 1170000280 S.IC
IC44 1120002830 S.IC
IC45 1110005000 S.IC
IC46 1190001740 S.IC
IC47 1190001730 S.IC
IC48 1170000280 S.IC
IC49 1170000280 S.IC
IC50 1130006220 S.IC
IC51 1110002400 S.IC
IC52 1110005690 S.IC
IC53 1130006220 S.IC
Q1 1590001400 S.TRANSISTOR
Q2 1530002060 S.TRANSISTOR
Q3 1590001940 S.TRANSISTOR
Q4 1530002060 S.TRANSISTOR
Q5 1510000510 S.TRANSISTOR
Q6 1530002060 S.TRANSISTOR
Q7 1590001400 S.TRANSISTOR
Q8 1590003210 S.TRANSISTOR
Q9 1590003210 S.TRANSISTOR
Q10 1590003210 S.TRANSISTOR
Q11 1590003210 S.TRANSISTOR
Q17 1590001940 S.TRANSISTOR
Q18 1590002010 S.TRANSISTOR
Q19 1590002010 S.TRANSISTOR
Q20 1590002010 S.TRANSISTOR
Q24 1550000020 S.FET
Q25 1530002060 S.TRANSISTOR
Q26 1590001960 S.TRANSISTOR
Q27 1590001960 S.TRANSISTOR
Q28 1590001960 S.TRANSISTOR
Q29 1590001960 S.TRANSISTOR
Q37 1590001940 S.TRANSISTOR
Q38 1590001400 S.TRANSISTOR
Q40 1590001940 S.TRANSISTOR
5 - 2
DESCRIPTION
LM-10
DESCRIPTION
NJM2902V-TE1
NJM2902V-TE1
NJM2902V-TE1
NJM2902V-TE1
NJM2107F-TE1
NJM2902V-TE1
NJM2902V-TE1
NJM2902V-TE1
NJM2902V-TE1
TA78L05F (TE12R)
NJM2902V-TE1
BU4066BCFV-E1
TC4S66F (TE85R)
TC4W53FU (TE12L)
LA4425A
TC4W53FU (TE12L)
TC4W53FU (TE12L)
M62364FP 600D
NJM2904V-TE1
NJM2107F-TE1
FX805LG
TC4W53FU (TE12L)
LC7387M-TRM
TC4W53FU (TE12L)
HD64F2238BFA13
S-80842CLUA-B63-T2
BU4011BFV-E2
BU4011BFV-E2
HN58X2464TI
S-812C50AMC-C3E-T2
BU4094BCFV-E2
BU4094BCFV-E2
BU4094BCFV-E2
TLP121 (GB-TPL)
TLP121 (GB-TPL)
NJM2125F-TE1
LMC567CM
BA6566F-E2
LC73701M-TLM
TLP121 (GB-TPL)
TLP121 (GB-TPL)
TC4W53FU (TE12L)
NJM2107F-TE1
NJM2520V-TE1
TC4W53FU (TE12L)
XP1214 (TX)
2SC4081 T106 R
DTC144EE TL
2SC4081 T106 R
2SA1576A T106R
2SC4081 T106 R
XP1214 (TX)
XP1111 (TX)
XP1111 (TX)
XP1111 (TX)
XP1111 (TX)
DTC144EE TL
XP1114 (TX)
XP1114 (TX)
XP1114 (TX)
2SJ377 (TE16R)
2SC4081 T106 R
XP4311 (TX)
XP4311 (TX)
XP4311 (TX)
XP4311 (TX)
DTC144EE TL
XP1214 (TX)
DTC144EE TL
S.=Surface mount
