Icom IC-FR4000 Service Manual page 37

[VR UNIT]
REF ORDER
NO. NO.
R1 7210003110 VARIABLE
R2 7210003120 VARIABLE
J1 6510018950 S.CONNECTOR
EP1 0910056093 PCB
[JACK1 UNIT]
REF ORDER
NO. NO.
L1 6200009940 S.COIL
L2 6200009940 S.COIL
L3 6200009940 S.COIL
L4 6200009940 S.COIL
L5 6200009940 S.COIL
L6 6200009940 S.COIL
L7 6200009940 S.COIL
L8 6200009940 S.COIL
R1 7540000210 S.ABSORBER
R2 7540000210 S.ABSORBER
R3 7540000210 S.ABSORBER
R4 7540000210 S.ABSORBER
R5 7540000210 S.ABSORBER
R6 7540000210 S.ABSORBER
R7 7540000210 S.ABSORBER
R8 7540000210 S.ABSORBER
R9 7540000210 S.ABSORBER
R10 7540000210 S.ABSORBER
C1 4030007170 S.CERAMIC
C2 4030007170 S.CERAMIC
C3 4030007170 S.CERAMIC
C4 4030007170 S.CERAMIC
C5 4030007170 S.CERAMIC
C6 4030007170 S.CERAMIC
C7 4030007170 S.CERAMIC
C8 4030007170 S.CERAMIC
C9 4030007170 S.CERAMIC
C10 4030007170 S.CERAMIC
J1 6450001650 CONNECTOR
J2 6510016170 CONNECTOR
J3 6510022730 S.CONNECTOR
EP1 0910056113 PCB
DESCRIPTION
RK0971110 10KA
RK0971110 10KB
B7B-PH-SM3-TB
B 5653C
DESCRIPTION
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
KU15N14-4063
KU15N14-4063
KU15N14-4063
KU15N14-4063
KU15N14-4063
KU15N14-4063
KU15N14-4063
KU15N14-4063
KU15N14-4063
KU15N14-4063
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
HSJ0836-01-500
52018-8835
S13B-PH-SM3-TB
B 5655C
[JACK2 UNIT]
REF ORDER
NO. NO.
D1 1750000930 S.DIODE
D2 1750000930 S.DIODE
D3 1750000930 S.DIODE
D4 1750000930 S.DIODE
D5 1750000930 S.DIODE
D6 1750000930 S.DIODE
D11 1750000930 S.DIODE
D12 1750000930 S.DIODE
D13 1750000930 S.DIODE
D14 1750000930 S.DIODE
D15 1750000930 S.DIODE
D16 1750000930 S.DIODE
D17 1750000930 S.DIODE
D18 1750000930 S.DIODE
D19 1750000930 S.DIODE
D20 1750000930 S.DIODE
D21 1750000930 S.DIODE
D22 1750000930 S.DIODE
D23 1750000930 S.DIODE
L1 6200009940 S.COIL
L2 6200009940 S.COIL
L3 6200009940 S.COIL
L4 6200009940 S.COIL
L5 6200009940 S.COIL
L6 6200009940 S.COIL
L11 6200009940 S.COIL
L12 6200009940 S.COIL
L13 6200009940 S.COIL
L14 6200009940 S.COIL
L15 6200009940 S.COIL
L16 6200009940 S.COIL
L17 6200009940 S.COIL
L18 6200009940 S.COIL
L19 6200009940 S.COIL
L20 6200009940 S.COIL
L21 6200009940 S.COIL
L22 6200009940 S.COIL
L23 6200009940 S.COIL
C1 4030007090 S.CERAMIC
C2 4030007090 S.CERAMIC
C3 4030007090 S.CERAMIC
C4 4030007090 S.CERAMIC
C5 4030007090 S.CERAMIC
C6 4030007170 S.CERAMIC
C8 4030007170 S.CERAMIC
C11 4030007170 S.CERAMIC
C12 4030007170 S.CERAMIC
C13 4030007170 S.CERAMIC
C14 4030007170 S.CERAMIC
C15 4030007170 S.CERAMIC
C16 4030007170 S.CERAMIC
C17 4030007170 S.CERAMIC
C18 4030007170 S.CERAMIC
C19 4030007170 S.CERAMIC
C20 4030007170 S.CERAMIC
C21 4030007170 S.CERAMIC
C22 4030007170 S.CERAMIC
C23 4030007170 S.CERAMIC
J1 6510023290 CONNECTOR
J2 6510022730 S.CONNECTOR
J3 6510022730 S.CONNECTOR
EP1 0910056124 PCB
5 - 15
DESCRIPTION
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
NNCD8.2C-T1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
BLM21PG221SN1
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
DBR61-25K1200-B
S13B-PH-SM3-TB
S13B-PH-SM3-TB
B 5656D
S.=Surface mount
