3.

SYSTEM INITIALIZATION

This chapter provides the information necessary for initializing the FELCOM19. Once
the equipment is initialized, you need do no more than press a few keys to get fully
automatic transmission and reception.
Inmarsat assigns an MES (your ship) an Inmarsat Mobile Number (IMN) when it ap-
plies for Inmarsat registration and it is entered during the installation of the MES. The
IMN is necessary to communicate in the Inmarsat system.
3.1

System Settings

3.1.1

Confirm the main terminal

The main terminal is where you set up the system. (You cannot set up the system from
an external terminal.) Confirm that the main terminal is selected as below.
1. Press the F8 key to show the [Setup] menu.
If your screen looks something like the one shown in the illustration above, you are
using the main terminal. (If you are using an external terminal, some menu items ap-
pear in gray.)
3.1.2

System setup

The [System Setup] menu is where you enter the date, time, operating mode, and port
function.
1. Press the F8 and 1 keys to show the [System Setup] menu.
Entered at installation
(Cannot be changed.)
For the serviceman
2. [System Date & Time] is selected; press the Enter key to open the date entry win-
dow.
3. Enter the date with the numeric keys.
4. Press the Enter key to close the window. (Note that the IMN is entered during in-
stallation. The IMN window cannot be opened.)
Setup
1. System Setup
2. Editor Setup
3. Terminal Setup
4. EGC Setup
5. Auto Mode Setup
6. E-Mail Setup
7. Directories
8. Configuration
System Setup
System Date & Time 03:11 11-12-25 (YY-MM-DD)
IMN 123456789
MES Operation Mode INMARSAT-C
Nav Port INT
LAN Port ON
Message Output Port INT
EGC Output Port INT
Network Setup
Command Window
3-1
