User Manual
T W O - W A Y L C D A U T O M A T I C / M A N U A L
T R A N S M I S S I O N R E M O T E S T A R T E R W I T H
F U L L A L A R M S Y S T E M
______________
User Guide
It is the responsibility of the vehicle operator to ensure their vehicle
is parked in a safe and responsible manner.
1. a) Manual transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in the NEUTRAL
position and the parking brake is engaged in order to avoid accidents
upon remote starting.
b) Automatic transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in "Park" in order to
avoid accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is
disabled or put into valet mode before servicing.
Battery Low Voltage Warning
Once the battery is weak, the LCD remote will display a battery low voltage icon
and an "L-BAT" indication with 2 beeps to warn the user to charge it.
Designed & engineered in Canada
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (EIRP) is not more than that required for successful communication.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to
this equipment. Such modifications could void the user's authority to operate the equipment.
Doc#: 110916
Rev:1.8
© 2011
WARNING !
-2W-FM-LCD-CMB-HD-
-PGa+FcN-
Canada
