  • Page 1 Grandstream Networks, Inc. GXP2120/GXP2110/GXP2100/GXP14xx SIP Enterprise Phones GXP2120/GXP2110/GXP2100/GXP14xx USER MANUAL...

  • Page 2: Table Of Contents

    GXP2120/GXP2110/GXP2100/GXP14xx User Manual Index GUI INTERFACE EXAMPLES ..............5 GNU GPL INFORMATION ................6 CHANGE LOG ................... 7 FIRMWARE VERSION 1.0.5.58 ......................7 FIRMWARE VERSION 1.0.5.32 ......................7 FIRMWARE VERSION 1.0.5.26 ......................7 FIRMWARE VERSION 1.0.5.24 ......................7 FIRMWARE VERSION 1.0.5.15 ......................8 FIRMWARE VERSION 1.0.4.23 ......................
  • Page 3 RECEIVING CALLS........................31 DO NOT DISTURB ........................31 DURING A PHONE CALL ........................32 CALL WAITING/CALL HOLD ....................... 32 MUTE ............................32 CALL TRANSFER ........................32 5-WAY CONFERENCING/3-WAY CONFERENCING ..............33 VOICE MESSAGES (MESSAGE WAITING INDICATOR) ............35 SHARED CALL APPEARANCE (SCA) ..................36 CALL FEATURES ..........................
  • Page 4 Table of Tables GXP2120/GXP2110/GXP2100/GXP14xx User Manual Table 1: GXP2120/GXP2110/GXP2100/GXP14xx FEATURES IN A GLANCE .......... 11 Table 2: GXP2120/GXP2110/GXP2100/GXP14xx COMPARISON GUIDE ..........12 Table 3: GXP2120/GXP2110/GXP2100/GXP14xx TECHNICAL SPECIFICATIONS ......... 12 Table 4: GXP2120/GXP2110/GXP2100/GXP14xx EQUIPMENT PACKAGING ......... 16 Table 5: GXP2120/GXP2110/GXP2100/GXP14xx CONNECTORS ............16 Table 6: LCD DISPLAY DEFINITIONS ......................

  • Page 5: Gxp2120/Gxp2110/Gxp2100/Gxp14Xx User Manual

    GUI INTERFACE EXAMPLES http://www.grandstream.com/products/gxp_series/general/documents/gxp21xx_gui.zip 1. Screenshot of Login Page 2. Screenshots of Status Pages 3. Screenshots of Accounts Pages 4. Screenshots of Settings Pages 5. Screenshots of Network Pages 6. Screenshots of Maintenance Pages 7. Screenshots of Phonebook Pages FIRMWARE VERSION 1.0.5.58 GXP2120/GXP2110/GXP2100/GXP14xx USER MANUAL Page 5 of 80...

  • Page 6: Gnu Gpl Information

    GNU GPL INFORMATION GXP2120/GXP2110/GXP2100/GXP14xx firmware contains third-party software licensed under the GNU General Public License (GPL). Grandstream uses software under the specific terms of the GPL. Please see the GNU General Public License (GPL) for the exact terms and conditions of the license. Grandstream GNU GPL related source code can be downloaded from Grandstream web site from: http://www.grandstream.com/support/faq/gnu_gpl.

  • Page 7: Change Log

    CHANGE LOG This section documents significant changes from previous versions of user manuals for GXP2120/GXP2110/GXP2100/GXP14xx. Only major new features or major document updates are listed here. Minor updates for corrections or editing are not documented here. FIRMWARE VERSION 1.0.5.58  Added “3CX Auto Provision”...

  • Page 8: Firmware Version 1.0.5.15

    FIRMWARE VERSION 1.0.5.15  Updated Web GUI interface examples with new screenshots for 1.0.5.15. [GUI INTERFACE EXAMPLES]  Merged GXP140x user manual content in this manual.  Add pin-out information. [Figure 1: GXP2120/GXP2110/GXP2100/GXP14xx Pin-out]  Updated Auto Attended Transfer information. [CALL TRANSFER] ...
  • Page 9 Added Editing Contacts and Click-to-Dial information. [EDITING CONTACTS AND CLICK-TO-DIAL]  Added GNU GPL information. [GNU GPL INFORMATION]  Added Change Log for this user manual. [CHANGE LOG]  Merging GXP1450 User Manual content with GXP2120/GXP2110/GXP2100 User Manual. FIRMWARE VERSION 1.0.5.58 GXP2120/GXP2110/GXP2100/GXP14xx USER MANUAL Page 9 of 80...

  • Page 10: Welcome

    Reproduction or transmittal of the entire or any part, in any form or by any means, electronic or print, for any purpose without the express written permission of Grandstream Networks, Inc. is not permitted. FIRMWARE VERSION 1.0.5.58 GXP2120/GXP2110/GXP2100/GXP14xx USER MANUAL...

  • Page 11: Product Overview

    GXP2100 3 XML programmable soft keys  XML Application  XML Idle Screen Customization  2 lines  GXP1450 3 XML programmable soft keys  XML Idle Screen Customization  2 lines  3 XML programmable soft keys GXP140x ...

  • Page 12: Gxp2120/Gxp2110/Gxp2100/Gxp14Xx Technical Specifications

    SIP PUBLISH method (RFC3903), SIP Presence Package (RFC3856, 3863) for use of Standards MPKs, SIP Dialog Package (RFC4235), SIP Message method (RFC3428) Note: MPKs are not applicable to GXP14xx. Network Dual switched 10/100Mbps port Interfaces Integrated PoE for GXP2120/GXP2110/GXP2100/GXP1450/GXP1405 FIRMWARE VERSION 1.0.5.58 GXP2120/GXP2110/GXP2100/GXP14xx USER MANUAL Page 12 of 80...
  • Page 13 LCD size and backlight: GXP2120 GXP2110 GXP2100 GXP1450 GXP140x Graphic Display 320x160 pixel 240x120 pixel 180x90 pixel 180x60 pixel 128x40 pixel Backlight Backlight Backlight Backlight No Backlight Feature key comparison: GXP2120 GXP2110 GXP2100 GXP1450 GXP140x HOLD SPEAKER SEND TRANSFER CONF...
  • Page 14 (GXP2100 only) Input: 100-240VAC 50-60Hz; Output: 5VDC, 800mA or 5VDC, 1200mA Efficiency Integrated Power-over-Ethernet (Built-in auto-sensing: Cisco and IEEE 802.3af standard) Max power consumption 2.5W (power adapter) or 3W (PoE) GXP2120 GXP2110 GXP2100 GXP1450 GXP140x Dimension 251mm(W) 252mm (W) 222mm (W) 186mm (W)
  • Page 15 Package GXP2120/GXP2110/GXP2100/GXP14xx phone, handset with cord, base stand, wall Content mount spacers, universal power supply, network cable, quick start guide FCC Part 15 (CFR 47) Class B; EN55022 Class B, EN55024, EN61000-3-2, Compliance EN61000-3-3, EN60950-1; AS/NZS CISPR 22 Class B, AS/NZS CISPR 24, RoHS; UL 60950 (power adapter) FIRMWARE VERSION 1.0.5.58 GXP2120/GXP2110/GXP2100/GXP14xx USER MANUAL...

  • Page 16: Installation

    Handset Port 2.5mm and RJ9 for GXP2120/GXP2110/GXP2100/1450; RJ9 for GXP140x Headset Port 10/100Mbps RJ-45 port connecting to Ethernet; LAN Port Integrated PoE for GXP2120/GXP2110/GXP2100/GXP1450/GXP1405 PC Port 10/100Mbps RJ-45 port for PC connection EXT Port Extension module connection port for GXP2120/GXP2110...

  • Page 17: Gxp2120/Gxp2110 Extension Module

    6. Using the keypad configuration menu or phone's embedded web server (Web GUI) by entering the IP address in web browser, you can further configure the phone. Please see below the pin-out information for GXP2120/GXP2110/GXP2100/14xx. GXP2120/GXP2110/GXP2100/GXP14xx GXP2120/GXP2110/GXP2100/GXP1450 Handset/Headset Jack 2.5mm Headset Jack GXP2120/GXP2110/GXP2100/GXP14xx...

  • Page 18: Figure 2: Gxp2120/Gxp2110 Ext Board Connection

    GXP2120 with 2 GXP EXT Boards GXP EXT Board Reverse side of connection with connection GXP2120/2110 has a special port on plate the back Figure 2: GXP2120/GXP2110 EXT Board Connection Connect the first GXP EXT board to the GXP2120/2110 using the connection cable found in the GXP EXT board package.

  • Page 19: Safety Compliances

    SAFETY COMPLIANCES The GXP2120/GXP2110/GXP2100/GXP14xx phone complies with FCC/CE and various safety standards. The GXP2120/GXP2110/GXP2100/GXP14xx power adapter is compliant with the UL standard. Use the universal power adapter provided with the GXP2120/GXP2110/GXP2100/GXP14xx package only. The manufacturer’s warranty does not cover damages to the phone caused by unsupported power adapters. WARRANTY If the GXP2120/GXP2110/GXP2100/GXP14xx phone was purchased from a reseller, please contact the company where the phone was purchased for replacement, repair or refund.

  • Page 20: Using The Gxp2120/Gxp2110/Gxp2100/Gxp14Xx

    USING THE GXP2120/GXP2110/GXP2100/GXP14xx GETTING FAMILAR WITH THE LCD GXP2120/GXP2110/GXP2100/GXP14xx has a dynamic and customizable screen. The screen displays differently depending on whether the phone is idle or in use (active). The following table describes the items displayed on the GXP2120/GXP2110/GXP2100/GXP14xx idle screen. Table 6: LCD DISPLAY DEFINITIONS Displays the current date and time.
  • Page 21 toggle among default idle screen, weather information, IP Address and the SIP extension number.  ForwardAll Unconditionally forwards the phone line (account 1) to another phone.  MissedCalls Shows up unanswered calls to this phone.  Redial Redials the last dialed number when there is existed dialed call log.
  • Page 22 entering transfer target number. Press Transfer softkey to do blind transfer.  Split In auto-attended transfer mode, after establishing the second call, press Split to quit transfer and go back to normal talking status.  ConfCall Conferences the active calls. ...

  • Page 23: Table 7: Gxp2120/Gxp2110/Gxp2100/1450 Lcd Icons

    Table 7: GXP2120/GXP2110/GXP2100/1450 LCD ICONS DND Status. OFF - Do Not Disturb disabled ON - Do Not Disturb enabled Call Forward All Status. OFF - Call Forward All feature disabled ON - Call Forward All feature enabled Call Forward Busy Status. OFF - Call Forward Busy feature disabled ON - Call Forward Busy feature enabled Call Forward No Answer Status.
  • Page 24 Missed Call Status. OFF - No missed call ON - New missed call Save Call Record Status. OFF - No saving call record activity ON - The phone is writing the call records into the flash at the moment Waiting For Response. Please wait for the phone to response before the keypad entry Handset Status.

  • Page 25: Table 8: Gxp140X Lcd Icons

    MUTE Status. OFF - No muted ON - Muted Call On Hold. Call Active. Conference Call. Core Dump. Core dump file can be downloaded from phone's Web GUI->Status page. Table 8: GXP140x LCD ICONS Registration Status: Registered. Registration Status: Not Registered. Handset Status.

  • Page 26: Getting Familar With The Keypad

    OFF - SRTP is not used ON - SRTP is used GETTING FAMILAR WITH THE KEYPAD The following table describes the buttons used on the GXP2120/GXP2110/GXP2100/GXP14xx keypad. Table 9: KEYPAD DEFINITIONS GXP2120/GXP2110/GXP2100 GXP1450 GXP140x Definition Open or switch line; LINE KEYS LINE KEYS LINE 1/LINE 2 resume the call on hold.

  • Page 27: Making Phone Calls

    PHONEBOOK Phonebook/Contacts. Volume (For GXP2100/GXP14xx only). For GXP2120/GXP2110, press UP or DOWN button to adjust the volume when the phone is on hook. Voicemail. Standard phone keypad. 0 - 9, *, # Configure key mode and User ID to use the Multi MULTI PURPOSE KEYS Purpose key as Speed Dial, BLF, Call Park and...

  • Page 28: Completing Calls

    For example: If 2 independent accounts are registered on GXP2120/GXP2110/GXP2100/GXP14xx, when LINE 1 is pressed, the LINE 1 LED will light up in green. If LINE 2 is pressed, the LINE 2 LED will light up in green and the subsequent call will be made through SIP account 2. Incoming calls to a specific account will attempt to use its corresponding LINE if it is not in use.
  • Page 29  Enter Call History and select "Answered Calls", "Missed Calls", "Transferred Calls" or "Forwarded Calls";  Select the entry you would like to call using the navigation arrow keys;  Press SEND button to dial out.  Via Phonebook. Dial the number from the phonebook. ...

  • Page 30: Making Calls Using Ip Addresses

    REDIAL;  By default, # can be used as SEND to dial the number out. Users could disable it by setting "User # as Dial Key" to "No" from Web GUI->Account X->Call Settings;  For Paging/Intercom, if the SIP Server/PBX supports the feature and has Paging/Intercom feature code set up already, users do not necessarily need toggle to paging mode in the call screen.

  • Page 31: Answering Phone Calls

    make direct IP calls using only the last few digits (last octet) of the target phone's IP address. This is possible only if both phones are under the same LAN/VPN. This simulates a PBX function using the CSMA/CD without a SIP server. Controlled static IP usage is recommended. To enable Quick IP Call Mode, go to phone's Web GUI->Settings->Call Features, set "Use Quick IP Call Mode"...

  • Page 32: During A Phone Call

    while the phone is in idle. Or users could set it from phone's Menu following the steps below:  Press the Menu button and select "Preference" using navigation keys;  Press Menu button again to get into Preference options;  Select "Do Not Disturb"...

  • Page 33: 5-Way Conferencing/3-Way Conferencing

     Attended Transfer.  During the first active call, press LINE key. The first call will be put on hold;  Enter the number for the second call in the new line and establish the call;  Press TRAN key; ...
  • Page 34  While 1 call is active, the other call will be put on hold with its LINE key blinking in green;  Press CONF key;  Press the desired LINE key on hold, the conference will be established;  Repeat the previous 2 steps for all the other parties on hold to join the conference. ...

  • Page 35: Voice Messages (Message Waiting Indicator)

     Press CONF key or press the ConfCall softkey to join the new party in the established conference.  Split and Re-conference.  During the conference, press HOLD key. The conference call will be split and both calls will be put on hold separately with 2 LINE keys blinking in green;...

  • Page 36: Shared Call Appearance (Sca)

    SHARED CALL APPEARANCE (SCA) The GXP2120/GXP2110/GXP2100/GXP14xx phone supports shared call appearance by Broadsoft standard. This feature allows members of the SCA group to shared SIP lines and provides status monitoring (idle, active, progressing, hold) of the shared line. When there is an incoming call designated for the SCA group, all of the members of the group will be notified of an incoming call and will be able to answer the call from the phone with the SCA extension registered.
  • Page 37 Block Caller ID (per call)  Off hook the phone;  Dial *67 and then enter the number to dial out. Send Caller ID (per call)  Off hook the phone;  Dial *82 and then enter the number to dial out. Disable Call Waiting (per Call) ...

  • Page 38: Customized Lcd Screen & Xml

     Dial *92 and then enter the number to forward the call;  Press OK softkey or SEND key. Cancel Delayed Call Forward. To cancel the delayed call forward:  Off hook the phone;  Dial *93;  Hang up the call. CUSTOMIZED LCD SCREEN &...

  • Page 39: Configuration Guide

    CONFIGURATION GUIDE The GXP2120/GXP2110/GXP2100/GXP14xx can be configured via two ways:  LCD Configuration Menu using the phone's keypad;  Web GUI embedded on the phone using PC's web browser. CONFIGURATION VIA KEYPAD To configure the LCD menu using phone's keypad, follow the instructions below: ...
  • Page 40 Gateway and DNS server. Displays phonebook. Users could add, edit, search and delete contacts/groups Phone Book here, or download phonebook XML to the phone. When doing phonebook search, user can only search ASCII characters. Note: Besides 3 embedded groups: Family, Friends and Work, user can create your own new groups.
  • Page 41  Star Key Lock Turns on/off keypad lock feature and configures keypad lock password. Config sub menu includes the following options: Config  Configures SIP Proxy, Outbound Proxy, SIP User ID, SIP Auth ID, SIP Password, SIP Transport and Audio information to register SIP account on the phone.
  • Page 42 Specifies Protocol, IP and Port of the target UCM server Reboot Reboot the phone. Exit Exit from this menu. The following picture shows the keypad MENU configuration flow. FIRMWARE VERSION 1.0.5.58 GXP2120/GXP2110/GXP2100/GXP14xx USER MANUAL Page 42 of 80...

  • Page 43: Figure 3: Keypad Menu Flow

    Answered Calls First Name Dialed Calls Last Name Missed Calls Number Transferred Calls Acct Clear All Groups MENU Back Confirm Add Cancel & Return Server Address Groups Call History Port New Entry Base Search User Name Download Phonebook XML Status Password Delete All Entries LDAP Number Filter...

  • Page 44: Configuration Via Web Browser

    Note: is not applicable to GXP140x. *LCD Brightness CONFIGURATION VIA WEB BROWSER The GXP2120/GXP2110/GXP2100/GXP14xx embedded Web server responds to HTTP/HTTPS GET/POST requests. Embedded HTML pages allow a user to configure the IP phone through a Web browser such as Microsoft’s IE, Mozilla Firefox and Google Chrome. To access the Web GUI: 1.

  • Page 45: Definitions

    page do not require reboot). DEFINITIONS This section describes the options in the phone's Web GUI. As mentioned, you can log in as an administrator or an end user.  Status: Displays the Account status, Network status, and System Info of the phone; ...

  • Page 46: Accounts Page Definitions

    NTP Server The NTP server phone uses to sync up time. PPPoE Link Up PPPoE connection status. 802.1q/802.1p(LLDP) The 802.1q/802.p status. 802.1q/VLAN Tag The assigned VLAN tag on phone. 802.1q Priority The assigned 802.1q priority on phone. NTP Server The NTP server phone uses to sync up time. Status ->...
  • Page 47 number. SIP service subscriber's Authenticate ID used for authentication. It can be Authenticate ID identical to or different from the SIP User ID. The account password required for the phone to authenticate with the ITSP Authenticate Password (SIP) server before the account can be registered. After it is saved, this will appear as hidden for security purpose.
  • Page 48 NAT/Firewall. Do not configure this parameter unless this feature is supported on the SIP server. Account x -> SIP Settings -> Basic Settings If the phone has an assigned PSTN telephone number, this field should be set to "User=Phone". Then a "User=Phone" parameter will be attached to the TEL URI Request-Line and "TO"...
  • Page 49 When set to "Yes", a SUBSCRIBE for Message Waiting Indication will be sent SUBSCRIBE for MWI periodically. The phone supports synchronized and non-synchronized MWI. The default setting is "No". SUBSCRIBE for When set to "Yes", a SUBSCRIBE for Registration will be sent out periodically. Registration The default setting is "No".
  • Page 50 menu and publish it to call center. The default setting is "No". This feature is used for Broadsoft call feature synchronization. When it's Feature Key enabled, DND, Call Forward features and Call Center Agent status can be Synchronization synchronized between Broadsoft server and phone. The default setting is "Disabled".
  • Page 51 a session timer when it makes outbound calls. If set to "Yes" and the remote party supports session timers, the phone will use Callee Request Timer a session timer when it receives inbound calls. If Force Timer is set to "Yes", the phone will use the session timer even if the remote party does not support this feature.
  • Page 52 Vocoder in 200OK SDP received 200OK SDP as the codec. The default setting is "No". Enables the SRTP mode based on your selection. The default setting is SRTP Mode "Disabled". Crypto Life Time Choose whether to include the lifetime parameter in SRTP crypto offer. Defines whether symmetric RTP is supported or not.
  • Page 53 b) xx. - only 2 digit numbers c) ^ - exclude d) [3-5] - any digit of 3, 4, or 5 e) [147] - any digit of 1, 4, or 7 <2=011> - replace digit 2 with 011 when dialing g) | - the OR operand ...
  • Page 54 Wait Time The default value is 20 seconds. The default setting is "Yes". When enabled, call features using star codes will be supported locally. If set to "No", Call Features and DND options under LCD Enable Call Features menu are supported. And ForwardAll soft key will not be displayed in LCD for Account 1.

  • Page 55: Settings Page Definitions

    If set to "Yes", the phone will automatically turn on the speaker phone to Allow Auto Answer by answer incoming calls after a short reminding beep, based on the SIP info Call-Info header sent from the server/proxy. The default setting is "No". Refer-To Use Target If set to "Yes", the "Refer-To"...
  • Page 56 non-symmetric NAT routers work with STUN. Configures to turn on/off public mode for hot desking feature on the phone. If set to "Yes", users would need fill in the SIP Server address for account 1 as well. Then reboot the phone. When the phone boots up, users will need enter SIP User ID and Password on the LCD to login and Public Mode use the phone.
  • Page 57 If set to "Yes", the DND button will not set the phone to DND. The default Disable DND Button setting is "No". Disable Transfer Disables the Transfer function. The default setting is "No". If this feature is enabled, MUTE key will take effect in idle state and future Enable Idle Mute incoming call will be answered with mute.
  • Page 58  When the phone is in idle, press HEADSET button to off hook the phone and make calls by using headset. Headset icon will display on the screen in dialing/talking status.  When there is an incoming call, press HEADSET button to pick up the call using headset.
  • Page 59 This options is not applicable to GXP140x. LCD Contrast Configures the LCD contrast level (from 0 to 20). The default value is 10. When it's set to "Yes", the LCD backlight will not be turned on when there is a new missed call. The default setting is "No". Disable Missed Call Backlight Note: This option is not applicable to GXP140x.
  • Page 60  MMMM dd, dddd: October 12, Friday Configures the time display in 12-hour or 24-hour format on the LCD. The Time Display Format default setting is in 12-hour format. Settings -> Web Service Configures to enable or disable weather update on the phone. The Enable Weather Update default setting is "Yes".
  • Page 61 field could be IP address or URL, with up to 256 characters. Note: This option is not applicable to GXP14xx. Specifies the soft key name displayed on the idle screen for the users to enter XML application. Please make sure the label name does not exceed the soft key range on each model.
  • Page 62 Enter a series of DTMF digits in the Value field to be dialed during the call. "Enable MPK Sending DTMF" has to be set to "Yes" first.  Voice Mail Select Account and enter the Voice Mail access number in the Value field.

  • Page 63: Network Page Definitions

    This option is similar to the BLF option but in this case the PBX collects the information from the phones and sends it out in one single notify message. PBX server has to support this feature.  Speed Dial via active account Similar to Speed Dial but it will dial based on the current active account.
  • Page 64 obtain IPv4 address. Users could select "DHCP", "Static IP" or "PPPoE". By default, it is set to "DHCP". DHCP Host name Specifies the name of the client. This field is optional but may be required by (Option 12) some Internet Service Providers. DHCP Vendor Class ID Used by clients and servers to exchange vendor class ID.

  • Page 65: Maintenance Page Definitions

    Upload 802.1X Client certificate to the phone; or delete existed 802.1X Client 802.1X Client Certificate certificate from the phone. Specifies the HTTP proxy URL for the phone to send packets to. The proxy HTTP Proxy server will act as an intermediary to route the packets to the destination. Specifies the HTTPS proxy URL for the phone to send packets to.
  • Page 66 HTTP/HTTPS Password The password for the HTTP/HTTPS server. Upgrade Via Allows users to choose the firmware upgrade method: TFTP, HTTP or HTTPS. Defines the server path for the firmware server. It could be different from the Firmware Server Path configuration server for provisioning. Defines the server path for provisioning.
  • Page 67 Syslog messages are sent based on the following events:  product model/version on boot up (INFO level);  NAT related info (INFO level);  sent or received SIP message (DEBUG level);  SIP message summary (INFO level);  inbound and outbound calls (INFO level); ...

  • Page 68: Phonebook Page Definitions

     Unrestricted. All the options can be accessed in keypad Menu.  Basic settings only. The CONFIG option will not be available in LCD Menu.  Constraint Mode. CONFIG, FACTORY FUNCTIONS and NETWORK options will not be available in LCD menu. If set to "Yes", the keypad can be locked by pressing and holding the STAR * key for about 4 seconds.
  • Page 69 Configures the phonebook download interval (in minutes). If it's set to 0, the Phonebook Download automatic download will be disabled. The default value is 0. The valid range is Interval 5 to 720 minutes. Remove Manually-edited If set to "Yes", when XML phonebook is downloaded, the entries added Entries on Download manually will be automatically removed.

  • Page 70: Nat Settings

    (&(cn=%) (telephoneNumber=*)) returns all the records with the "cn" field starting with the entered prefix and "telephoneNumber" field set. Selects the protocol version for the phone to send the bind requests. The LDAP Version default setting is "Version 3". Specify the "name" attributes of each record which are returned in the LDAP search result.

  • Page 71: Weather Update

    If the devices are kept within a private network behind a firewall, we recommend using STUN Server. The following settings are useful in the STUN Server scenario:  STUN Server Under Settings->General Settings, enter a STUN Server IP (or FQDN) that you may have, or look up a free public STUN Server on the internet and enter it on this field.

  • Page 72: Public Mode

    By default the City Code is set to "Automatic", which allows the phone to obtain weather information based on the IP location detected. To use "Self-Defined City Code" option, please follow the steps below to obtain the correct city code: ...

  • Page 73: Editing Contacts And Click-To-Dial

     Under Web GUI->Settings->General Settings, set "Public Mode" option to "Yes". Click "Save and Apply" and reboot the phone;  When the phone boots up, SIP User ID and Password to register to the configured SIP server in account 1 will be required. Enter the correct account information to log in to the phone. When entering the account information, press softkey "123"/"abc"...

  • Page 74: Figure 4: Web Gui - Phonebook->Contacts

     password=admin/123: The admin login password or user login password of phone's Web GUI. Click to call this contact Add contacts Click to dial from Edit contact. from the phone. available lines. Figure 4: Web GUI - Phonebook->Contacts Figure 5: Click-to-Dial SAVING THE CONFIGURATION CHANGES After users makes changes to the configuration, press the "Save"...
  • Page 75 changes. REBOOTING FROM REMOTE LOCATIONS Press the "Reboot" button on the top right corner of the web GUI page to reboot the phone remotely. The web browser will then display a reboot message. Wait for about 1 minute to log in again. FIRMWARE VERSION 1.0.5.58 GXP2120/GXP2110/GXP2100/GXP14xx USER MANUAL Page 75 of 80...

  • Page 76: Upgrading And Provisioning

    UPGRADING AND PROVISIONING The GXP2120/GXP2110/GXP2100/GXP14xx can be upgraded via TFTP/HTTP/HTTPS by configuring the URL/IP Address for the TFTP/HTTP/HTTPS server and selecting a download method. Configure a valid URL for TFTP or HTTP/HTTPS; the server name can be FQDN or IP address. Examples of valid URLs: firmware.grandstream.com fw.ipvideotalk.com/gs...

  • Page 77: No Local Tftp/Http Servers

    restart again. Please do not interrupt or power cycle the phone when the upgrading process is on. Firmware upgrading takes around 60 seconds in a controlled LAN or 5-10 minutes over the Internet. We recommend completing firmware upgrades in a controlled LAN environment whenever possible. NO LOCAL TFTP/HTTP SERVERS For users that would like to use remote upgrading without a local TFTP/HTTP server, Grandstream offers a NAT-friendly HTTP server.
  • Page 78 numbers. i.e., P2 is associated with the "Admin Password" in the Web GUI->Maintenance->Web/Telnet Access page. For a detailed parameter list, please refer to the corresponding firmware release configuration template. When GXP2120/GXP2110/GXP2100/GXP14xx boots up, it will send TFTP or HTTP/HTTPS requests to download configuration files, “cfg000b82xxxxxx”...

  • Page 79: Restore Factory Default Settings

    RESTORE FACTORY DEFAULT SETTINGS Warning: Restoring the Factory Default Settings will delete all configuration information on the phone. Please backup or print all the settings before you restore to the factory default settings. Grandstream is not responsible for restoring lost parameters and cannot connect your device to your VoIP service provider. Please follow the instructions below to reset the phone: ...

  • Page 80: Experiencing The Gxp2120/Gxp2110/Gxp2100/Gxp14Xx

    EXPERIENCING THE GXP2120/GXP2110/GXP2100/GXP14xx Please visit our website: http://www.grandstream.com to receive the most up- to-date updates on firmware releases, additional features, FAQs, documentation and news on new products. We encourage you to browse our product related documentation, FAQs User and Developer Forum for answers to your general questions.
