HOW TO INSTALL
TO REMOVE TODDLER FROM RESTRAINT
A. Press the red button on Harness Buckle then both
Harness Tongues will be released. Move each shoulder
strap to the toddler's side, then remove the toddler.
TO REMOVE RESTRAINT FROM
VEHICLE
A. Disengage seat belt tongue from buckle and
remove from restraint.
B. Fully press Upper Anchorage Strap Adjuster
Button (A) while pulling Upper Anchorage Strap
(B) to slacken as shown right. In some vehicles
loosening of the Upper Anchorage Strap may
be difficult. If so, try pushing the restraint
against the vehicle seat back or slightly lifting
the restraint to release the tension.
C. Disengage Attachment Clip from the Car's
Anchor Fitting. The child restraint is now
disconnected and can be removed from the car.
22 Instructions for Installation & Use - Series No. 8100/A/2010
Fully press Adjuster Button (A) while pulling
Upper Anchorage Strap (B) to lengthen.
A
B
Storage
Band
Roll up excess strap
and store with the
storage band to
avoid tripping when
moving the restraint.
PLACING TODDLER IN THE
RESTRAINT
A. Lengthen harness by pressing Harness
Adjustment button while pulling on either
shoulder strap until the harness will
accommodate the child.
B. Place child in the restraint and feed each arm
through shoulder straps. Pull harness buckle
up between child's legs.
Engage the buckle tongues and tighten the
harness as described on the next page.
Instructions for Installation & Use - Series No. 8100/A/2010

HOW TO USE

Pull to
lengthen
Press and hold
A
Pull harness
adjuster
strap to
tighten.
B C
23
