Britax MAX-FIX II User Instructions

PRODUCT OVERVIEW
03
04
05
06
07
08
09
10
13 14
01 02
ISOFIX attachement points (car)
Shoulder straps
01 06
ISOFIX insert guides
Harness buckle
02
07
Cover
Adjusting button
03
08
Headrest
Adjustment strap
04
09
Shoulder pads
Recline wheel
05
10
• The child safety seat has been designed, tested and certified according to the requirements of the Euro-
pean Standard for Child Safety Equipment (ECE R 44/04). The test mark E (in a circle) and the certifica-
Tested and certified ac-
BrITaX rÖMEr
tion number are located on the orange certification sticker (sticker on the child safety seat).
cording to ECE* r 44/04
• This certification will be invalidated if you make any modifications to the child safety seat.
child safety seat
• The MAX-FIX II child safety seat must only be used to secure your child in the vehicle. It must never be
Group Body weight
used as a seat or toy in the home.
• Risk of injury due to unauthorised modifications! Unauthorised technical modifications may reduce or
MaX-FIX II 0+ & 1 0 to 18 kg entirely void the seat´s protective properties.
- Do NOT make any technical modifications to the baby seat.
- Use the baby seat only as described in the user instructions.
*ECE = European Standard for Child safety Equipment

CARE AND MAINTENANCE

Care for the harness buckle
It is vital for the safety of your child that the harness buckle works correctly.
Malfunctions of the harness buckle are usually caused by accumulations of dirt
or foreign bodies. Malfunctions are as follows:
• The buckle latches are ejected only slowly when the red release button is
pressed.
• The buckle latches will no longer lock home (i.e. they are ejected again if you
try to push them in).
• The buckle latches engage without an audible „click".
• The buckle latches are difficult to insert (you feel resistance).
• The buckle only opens if extreme force is applied.
remedy
wash out the harness buckle so that it functions properly once again:
Cleaning the harness buckle
24
07
26
10
1. Open the harness buckle 07 (press the red button).
2.Turn the recline wheel and move the seat shell 26 upwards into the most
10
reclined position.
26
3. Grasp under the seat shell and slide the metal plate 24 which is used to
fasten the harness buckle 07 to the seat shell up on its edge through the
strap slot 25 .
4. Soak the harness buckle 07 in warm water with dishwashing liquid for at
least an hour. Then rinse and dry it thoroughly.
Cleaning the cover
Please be sure to use only genuine Britax/RÖMER replacement seat covers,
as the seat cover is an integral part of the child safety seat which plays an
important role in ensuring that the system works properly. Replacement
seat covers are available from your retailer.
• The child seat must not be used without its cover.
• The cover can be removed and washed with a mild detergent using the
15
16
17
18
11
19
12
Fabric loop MAX-FIX II base
11
16
Locking arms
Support leg
12
17
Release button
Adjustment buttons
13
18
ISOFIX indicators Support leg indicator
14 19
Storage compartment
15
washing machine's cycle for delicate items (30 °C). Please observe the
instructions on the washing label of the cover.
• The plastic parts can be cleaned using soapy water. Do not use harsh
cleaning agents (such as solvents).
• The harnesses can be washed in lukewarm soapy water.
• The shoulder pads can be washed in lukewarm soapy water.
Caution: Never remove the buckle latches 21 from the straps.
Caution:
The child seat must not be used without the seat cover.
removing the cover
04
07
10
1. Turn the recline wheel and move the seat shell
26
10
upright position.
2. Loosen the harness straps as far as possible.
3. Open the harness buckle 07 (press the red button).
4. Slide the headrest 04 to its lowest position.
6. Remove the cover of the headrest 04 .
7. Open the poppers on the left and right of the rear part of the cover.
8. Fold the rear part of the cover onto the seat surface.
9. Thread the harness straps through the cutout in the cover.
10. Unhook the elastic seam of the cover under the edge of the seat shell.
TIP: Start at the handles on the side and at the upper edge of the seat shell.
11. Pull the cover up and over the bezel of the strap adjuster.
12. Feed out the harness buckle 07 and the end of the strap from the cover.
13. Pull the cover upwards a little and then put it with the cutout over the head-
rest .
04
Re-fitting the Cover:
Simply follow the steps in the opposite order.
Caution: Check that the harness straps are not twisted and that they
have been correctly inserted in the belt slots on the cover.
CARE INSTRUCTIONS
To ensure the full protective effect of the child safety
seat:
• In the event of an accident with an impact speed above 10
km/h it is possible that the child safety seat may have been
damaged, but that the damage may not be immediately obvi
ous. In this case the child safety seat must be replaced.
Please dispose of it properly.
• Regularly check all important parts for damage. Make sure
that the mechanical components in particular are all in per-
fect working order.
• To prevent damage, ensure that the child safety seat does
not become jammed between hard objects (car door, seat
runners etc.).
• Always have the child safety seat checked if it has been
damaged (e.g. if it is dropped).
• Never lubricate or oil parts of the child seat.
• In order to properly protect your child, it is imperative that
you install and use the MAX-FIX II exactly as described in
this manual.
Please observe the waste disposal regulations in your country.
Disposal of packaging
Cover
Plastic parts
Metal parts
Harness straps
Buckle &latch

USE IN THE VEHICLE

Please observe the instructions on the use of child restraint systems described
in your vehicle owner's manual.
The seat may be used in all vehicles equipped with the ISOFIX anchoring
systems. Please consult your vehicle owner's manual for information the seats
which are approved for child safety seats in the weight class 0-18 kg.
The fastening with ISOFIX and support leg is based on semiuniversal approval.
The seat may be used only in those vehicles cited in the enclosed vehicle type
list. This type list is constantly updated. The latest version can be obtained from
us or from www.britax.eu / www.roemer.eu.
You can use your child car seat as follows:
In the direction of travel
On seats featuring:
ISOFIX attachments (between seat surface and
backrest)
(Please observe the applicable regulations in your country)
1) If there is a front airbag: Slide the passenger seat a long way back and refer to any
instructions in vehicle owner's manual.
downwards into the
0-18 kg
NEXT CHILD SAFETY SEATS
BrITaX rÖMEr Child safety seats
rearward facing Forward facing
MaX-WaY
MULTI-TECH 2
KIDFIX /KIDFIX SICT
KID / KID plus
TWO-YEAR WARRANTY
For this child safety seat we offer a 2-year warranty against manufacturing or
material defects. The warranty period is effective from the day of purchase.
The warranty covers only child safety seats which have been handled properly
and which have been sent to us in a clean and proper condition.
The Warranty does not cover:
• natural signs of wear and damage resulting from excessive stress
• damage resulting from inappropriate or improper use
What is covered by the warranty?
Fabrics: All of our fabrics meet very high requirements with regard to colour
fastness when exposed to UV radiation. Nevertheless, all fabrics fade when
exposed to UV radiation. This is not a material defect, but rather a normal sign
of wear which is not covered by the warranty.
Buckle: Buckle malfunctions are often due to accumulations of dirt or foreign
bodies which may stop the buckle from working properly. If this happens, the
buckle can be cleaned, olease follow the procedure described in your user
instructions.
Please contact your retailer immediately in the event of a warranty claim. He or
she will give you the advice and support you need. When processing claims,
product-specific depreciation rates will be applied. Please refer to our General
Terms and Conditions which are available from your retailer.
Use, care and maintenance
The child safety seat must be used in accordance with the user instructions.
We point out expressly that only genuine accessories and replacement parts
must be used.
Container for cardboard
Residual waste, thermal utilisation
BRITAX EXCELSIOR LIMITED
In accordance with the labelling in the
1 Churchill Way West
designated container
Andover
Hampshire SP10 3UW
Container for metals
United Kingdom
Container for polyester
BRITAX RÖMER
Kindersicherheit GmbH
Residual waste
Blaubeurer Straße 71
D-89077 Ulm
Germany
0 – 18 kg
0 ~ 4 y
MAX-FIX II
No
Yes 1)
User instructions
Testing and certification
in accordance with ECE r 44/04
Group Body weight
1 – 2 9 – 25 kg
1 – 2 9 – 25 kg
www.britax.eu
2 – 3 15 – 36 kg
2 – 3 15 – 36 kg
t: +44 (0) 1264 333343
f: +44 (0) 1264 334146
e: helpline@uk.britaxeurope.com
www.britax.eu
t: +49 (0) 731 9345-199/-299
f: +49 (0) 731 9345-210
e: info@de.britaxeurope.com
www.roemer.eu
