Page 4
Table of Contents Britax Child Safety, Inc. Child Seat Features Front Rear...
Page 5
Table of Contents MARATHON CLICKTIGHT User Guide Description 1. Cover 2. Harness Height Adjuster 3. Head Pad 4. Stay Put Comfort Pads Comfort Pads (For select covers only) User Guide Storage (in pocket behind cover) 6. Chest Clip 7. Harness Buckle 8.
Page 6
GENERAL USE • Follow all instructions on this child restraint and in the written instructions. • Britax strongly recommends that children should remain in a child seat with a 5-point harness until reaching the maximum weight or height allowed. • Register your child restraint with the manufacturer.
Page 7
See Serial Number and Manufactured Date Label on child seat (pages 2 - 3). • The use of non-Britax covers, inserts, toys, accessories, or tightening devices is not approved by Britax. Their use could cause this child seat not to perform as intended in a crash.
Page 8
Send your name, address, e-mail address if available and the restraint’s model number and manufacturing date to Britax Child Safety, Ltd., P.O. Box 7289, RPO Brunswick Square, Saint John NB E2L 4S6, or call 1-888-427-4829 or 1-704- 409-1699, or register online at us.britax.com/registration.
Page 9
Child Fit Information Rear-Facing : 2.3 – 18 kg (5 – 40 lbs) Britax strongly recommends that children ride rear facing to the highest weight or height specified. Use rear facing: • with harness straps in the closest position at or below the child’s...
Page 10
Table of Contents Britax Child Safety, Inc. Rear-Facing Installation Lap-Shoulder Belt Installation (Preferred Method) 1. Open the CLICKTIGHT. a. Press the dimple on the CLICKTIGHT dial. b. Rotate dial clockwise until CLICKTIGHT releases and lift to open. 2. Attach the anti-rebound bar (see page 27).
Page 11
Table of Contents MARATHON CLICKTIGHT User Guide 7. Hold harness straps up and away from seat while closing the CLICKTIGHT. NOTE: A click helps confirm the CLICKTIGHT is secure. Rear-Facing Installation with Lap-Shoulder Belt 9 Logo on the CLICKTIGHT dial has returned to a horizontal position.
Page 12
Table of Contents Britax Child Safety, Inc. LUAS Installation IMPORTANT: Do not install rear-facing with LUAS for a child weighing more than 15.8 kg (35 lbs). 1. Open the CLICKTIGHT. a. Press the dimple on the CLICKTIGHT dial. b. Rotate dial clockwise...
Page 13
Table of Contents MARATHON CLICKTIGHT User Guide 6. Pull the end of the lower connector strap to remove slack. 7. Hold harness straps up and away from seat while closing the CLICKTIGHT. NOTE: A click helps confirm the CLICKTIGHT is secure.
Page 14
Table of Contents Britax Child Safety, Inc. Lap Belt Installation 1. Open the CLICKTIGHT. a. Press the dimple on the CLICKTIGHT dial. b. Rotate dial clockwise until CLICKTIGHT releases and lift to open. 2. Attach the anti-rebound bar (see page 27).
Page 15
Table of Contents MARATHON CLICKTIGHT User Guide 7. Hold harness straps up and away from seat while closing the CLICKTIGHT. NOTE: A click helps confirm the CLICKTIGHT is secure. Rear-Facing Installation with Lap Belt Installation 9 Logo on the CLICKTIGHT dial has returned to a horizontal position.
Page 16
Table of Contents Britax Child Safety, Inc. Forward-Facing Installation IMPORTANT: Do not use the anti-rebound bar in a forward- facing position. Lap-Shoulder Belt Installation (Preferred Method) 1. Remove the tether from the tether storage compartment and retainer tabs and place it up and over the child seat back.
Page 17
Table of Contents MARATHON CLICKTIGHT User Guide 7. Hold harness straps up and away from seat while closing the CLICKTIGHT. NOTE: A click helps confirm the CLICKTIGHT is secure. 8. Attach the tether to a designated anchor (see vehicle owner’s manual) and remove slack (see page 30).
Page 18
Table of Contents Britax Child Safety, Inc. LUAS Installation IMPORTANT: Do not install forward-facing with LUAS for a child weighing more than 18 kg (40 lbs). 1. Remove the lower connectors from the storage compartment at the rear of the seat and pull the strap to full length toward the child’s left...
Page 19
Table of Contents MARATHON CLICKTIGHT User Guide 7. Hold harness straps up and away from seat while closing the CLICKTIGHT. NOTE: A click helps confirm the CLICKTIGHT is secure. 8. Attach the tether to a designated anchor (see vehicle owner’s manual) and remove slack (see page 30).
Page 20
Table of Contents Britax Child Safety, Inc. Lap Belt Installation 1. Remove the tether from the tether storage compartment and retainer tabs and place it up and over the child seat back. 2. Place upright forward- facing on the vehicle seat.
Page 21
Table of Contents MARATHON CLICKTIGHT User Guide 7. Hold harness straps up and away from seat while closing the CLICKTIGHT. NOTE: A click helps confirm the CLICKTIGHT is secure. NOTE: If the CLICKTIGHT is difficult to close, repeat step 6 with less tension in the vehicle belt.
Page 22
Table of Contents Britax Child Safety, Inc. Securing Your Child IMPORTANT: Impact absorbing chest pads are highly recommended for forward-facing mode. Removal of chest pads is optional for rear-facing mode to ensure a snug fit for small infants. 1. Make the proper...
Page 23
Table of Contents MARATHON CLICKTIGHT User Guide 7. Fasten the harness buckle. NOTE: After inserting each buckle tongue, listen for a click to help ensure proper connection. 8. Check for proper harness height and pull any excess slack up to the child’s shoulder area...
Page 24
Table of Contents Britax Child Safety, Inc. Child Seat Functions Adjusting the Harness Height In rear-facing mode, the harness straps should be in the closest position at or below your child’s shoulders. See page 7. In forward-facing mode, the harness straps should be in the closest position at or above your child’s shoulders.
Page 25
Table of Contents MARATHON CLICKTIGHT User Guide 3. Thread the end of the harness through the opening on the inside of the metal bar behind the anchor to the bottom of the seating area. 4. Wrap the end of the...
Page 26
Table of Contents Britax Child Safety, Inc. Harness Buckle Position The child seat shell contains an inner buckle slot and an outer buckle slot. Position the buckle in the slot closest to but not under the child. INNER SLOT ADJUSTMENT...
Page 27
Table of Contents MARATHON CLICKTIGHT User Guide Comfort Pillow The comfort pillow is designed to provide better fit and comfort for infants using this child seat. NOTE: Remove the comfort pillow after the child can sit comfortably in the child seat without additional support.
Page 28
Table of Contents Britax Child Safety, Inc. Overhang It is important that the base of the child seat rests completely flat on the vehicle seat with no side overhang. As seen in the illustration, it is permissible to allow up to 7.5 cm (3 in.) of the base...
Page 29
Table of Contents MARATHON CLICKTIGHT User Guide Anti-Rebound Bar WARNING! The anti-rebound bar is not intended for use as a carry handle. Do not use the anti-rebound bar to carry this child seat. IMPORTANT: The anti-rebound bar MUST be removed for forward-facing installation.
Page 30
Table of Contents Britax Child Safety, Inc. Using the Lower Universal Anchorage System (LUAS) and Tether The Lower Universal Anchorage System, or LUAS, is a system available on this child seat that offers an alternative to vehicle seat belt installation methods. The figure below shows typical locations for lower anchors and tether anchors in a vehicle.
Page 31
Failure to follow the guidelines below may cause the child seat not to perform as intended. • Britax recommends that the tether be used when installing the child seat forward facing. Using the tether will improve the stability of your child seat and reduce the risk of injury.
Page 32
Table of Contents Britax Child Safety, Inc. Using the Tether IMPORTANT: Do not use the top tether strap with rear-facing installations. To attach the tether to a tether anchor: 1. Firmly press the hook over the tether anchor point. 2. Pull the loose end of the webbing to remove slack from the tether.
Page 33
Table of Contents MARATHON CLICKTIGHT User Guide The Tether as a Crash Indicator The tether can indicate when the child seat has been in a moderate or severe crash (see “Important Notes” on page 5) and replacement of the child seat is necessary.
Page 34
Table of Contents Britax Child Safety, Inc. Vehicle Compatibility Vehicle Seating Positions WARNING! DO NOT place child seat rear-facing in the front seat of a vehicle with a passenger air bag. DEATH or SERIOUS INJURY can occur. Owners of vehicles with front passenger side airbags should refer to their owner’s...
Page 35
NOTE: This Britax car seat may not be compatible with every inflatable lap-shoulder belt. See FAQs in the support section of the Britax website (us.britax.com/ faqs) for additonal instructions.
Page 36
Table of Contents Britax Child Safety, Inc. Maintenance IMPORTANT: Before each use, check this car seat and its components to make sure they are in good condition and good working order. Cover Removing the Cover WARNING! Never remove the buckle tongues from the harness.
Page 37
Table of Contents MARATHON CLICKTIGHT User Guide d. Pull the end of the belly pad and buckle retainer out of the buckle slot in the cover to remove. e. Turn the buckle retainer sideways and slide the buckle out of the belly pad (see page 39).
Page 38
Table of Contents Britax Child Safety, Inc. Replacing the Cover 1. Attach one side of the upper shell cover at the forward-facing belt path, pull the cover over the back of the shell, and secure at opposite belt path. 2. Replace lower shell cover.
Page 39
Table of Contents MARATHON CLICKTIGHT User Guide Reattach the two elastic loops at the front of the lower shell. 3. Replace the belly pad and buckle: a. Turn the buckle retainer sideways and route it through the belly pad. b. Route the belly pad...
Page 40
Table of Contents Britax Child Safety, Inc. 6. Replace the head pad. a. Loosen the harness and raise the head pad to the highest position. b. Slide on the head pad to install. c. For select cover sets only (if applicable):...
Page 41
Table of Contents MARATHON CLICKTIGHT User Guide 4. Pull the end of the belly pad and buckle retainer out of the slot in the seat cover to remove. 5. Turn the buckle retainer sideways and route the buckle assembly out of the belly pad.
Page 42
Table of Contents Britax Child Safety, Inc. 5. Replace the cover, ensuring the seat cover is tucked behind the CLICKTIGHT bar, then close the CLICKTIGHT. Impact Absorbing Chest Pads IMPORTANT: Impact absorbing chest pads are highly recommended for forward-facing mode. Removal of chest pads is optional for rear-facing mode to ensure a snug fit for small infants.
Page 43
Table of Contents MARATHON CLICKTIGHT User Guide 8. Nest the end of the left harness strap into the right. 9. Slide the harness straps completely onto the yoke. Ensure that the adjuster and harness straps are not twisted and that...
Page 44
Table of Contents Britax Child Safety, Inc. 7. Route the harness straps through the seat to the back. Ensure that the TUBE harness straps pass over the tube. 8. Nest the end of the left harness strap into the right.
Page 45
Table of Contents MARATHON CLICKTIGHT User Guide Cleaning Shell • SPONGE CLEAN the DO NOT shell using warm water • Use abrasive and mild soap. cleaners • TOWEL DRY. Cover • Refer to product DO NOT care label for wash •...
Page 46
Proof of purchase is required. Your exclusive remedy for this warranty is that Britax will, at its option, provide repair or replacement components for this product. Britax reserves the right to discontinue or change fabrics, parts, models or products, or to make substitutions.
Table des matières Britax Child Safety, Inc. Caractéristiques du siège pour enfant Avant Arrière...
Page 49
Table des matières MARATHON CLICKTIGHT Guide d’utilisation Description 1. Housse 2. Dispositif de réglage de hauteur du harnais 3. Coussin d’appuie-tête 4. Coussinets de confort Coussinets confort (Pour certaines housses seulement) Rangement du guide d’utilisation (dans la pochette derrière la housse) 6.
• Suivez toutes les instructions apparaissant sur l’ensemble de retenue pour enfant et dans le livret d’instructions • Britax recommande fortement de continuer d’utiliser un siège pour enfant équipé d’un harnais à cinq points jusqu’à ce que l’enfant atteigne le poids ou la taille maximale autorisée.
(voir les pages 2-3) • L’utilisation de housses, de pièces, de jouets d’accessoires ou de dispositifs de fixation de marque autre que Britax n’est pas approuvée par Britax. Leur emploi pourrait nuire à l’efficacité prévue du siège pour enfant en cas de collision •...
Envoyez votre nom, votre adresse, votre adresse courriel, s’il y a lieu, ainsi que le numéro de modèle et la date de fabrication du siège pour enfant à Britax Child Safety, Ltd., Case postale 7289, RPO Brunswick Square, Saint John NB E2L 4S6, ou bien composez le 1-888-427-4829 ou 1-704-409-1699, ou encore allez en ligne au us.britax.com/registration.
Information pour l’installation de l’enfant Orientation vers l’arrière : 2,3 à 18 kg (5 à 40 lb) Britax recommande que les enfant soient dans le siège pour enfant orienté vers l’arrière jusqu’au maximum de poids ou de grandeur spécifié pour le modèl du siège.
Table des matières Britax Child Safety, Inc. Installation orientée vers l’arrière Installation avec la ceinture sous-abdominale/ baudrier (méthode préférée) 1. Ouvrez le CLICKTIGHT. a. Appuyez sur le cran d’arrêt du témoin CLICKTIGHT. b. Tournez le témoin dans le sens horaire jusqu’à...
Page 55
Table des matières MARATHON CLICKTIGHT Guide d’utilisation 7. Pendant que vous fermez le CLICKTIGHT, tenez les sangles du harnais vers le haut, à distance du siège. REMARQUE : Un déclic confirme que le CLICKTIGHT est en place. Ceinture sous-abdominale et baudrier 9 Assurez-vous que le logo du témoin CLICKTIGHT a bien...
Table des matières Britax Child Safety, Inc. Installation avec le DUA IMPORTANT : Ne pas utiliser le DUA pour attacher cet siege pour enfant avec un enfant pesant plus de 15,8 kg (35 lb). 1. Ouvrez le CLICKTIGHT. a. Appuyez sur le cran d’arrêt du témoin...
Page 57
Table des matières MARATHON CLICKTIGHT Guide d’utilisation 6. Tirez sur l’extrémité de la sangle de l’attache inférieure pour la tendre. 7. Pendant que vous fermez le CLICKTIGHT, tenez les sangles du harnais vers le haut, à distance du siège. REMARQUE : Un déclic confirme que...
Table des matières Britax Child Safety, Inc. Installation avec la ceinture sous-abdominale 1. Ouvrez le CLICKTIGHT. a. Appuyez sur le cran d’arrêt du témoin CLICKTIGHT. b. Tournez le témoin dans le sens horaire jusqu’à ce que le CLICKTIGHT se déverrouille, puis levez pour ouvrir.
Page 59
Table des matières MARATHON CLICKTIGHT Guide d’utilisation 7. Pendant que vous fermez le CLICKTIGHT, tenez les sangles du harnais vers le haut, à distance du siège. REMARQUE : Un déclic confirme que le CLICKTIGHT est en place. Installation orientée vers l’arrière avec la ceinture sous- abdominale 9 Assurez-vous que le logo du témoin CLICKTIGHT a bien...
Table des matières Britax Child Safety, Inc. Installation orientée vers l’avant IMPORTANT : Ne pas utiliser la barre anti-rebond en position orientée vers l’avant. Installation avec la ceinture sous-abdominale/ baudrier (méthode préférée) Retirez la courroie d’ancrage de son compartiment de...
Page 61
Table des matières MARATHON CLICKTIGHT Guide d’utilisation Pendant que vous fermez le CLICKTIGHT, tenez les sangles du harnais vers le haut, à distance du siège. REMARQUE : Un déclic confirme que le CLICKTIGHT est en place. Fixez la courroie d’ancrage au boulon d’ancrage désigné...
Table des matières Britax Child Safety, Inc. Installation avec le DUA IMPORTANT : Ne pas utiliser le DUA pour attacher cet siege pour enfant avec un enfant pesant plus de 18 kg (40 lb). 1. Retirez les attaches inférieures du compartiment de rangement situé...
Page 63
Table des matières MARATHON CLICKTIGHT Guide d’utilisation 7. Pendant que vous fermez le CLICKTIGHT, tenez les sangles du harnais vers le haut, à distance du siège. REMARQUE : Un déclic confirme que le CLICKTIGHT est en place. 8. Fixez la courroie d’ancrage au boulon...
Table des matières Britax Child Safety, Inc. Installation avec la ceinture sous-abdominale Retirez la courroie d’ancrage de son compartiment de rangement et les languettes de retenue, puis placez-la par-dessus le dossier du siège pour enfant. Placez-le en position verticale et orienté vers l’avant sur le siège du...
Page 65
Table des matières MARATHON CLICKTIGHT Guide d’utilisation Pendant que vous fermez le CLICKTIGHT, tenez les sangles du harnais vers le haut, à distance du siège. REMARQUE : Un déclic confirme que le CLICKTIGHT est en place. REMARQUE : Si le CLICKTIGHT est difficile à...
Table des matières Britax Child Safety, Inc. Attacher votre enfant IMPORTANT : Les coussinets de poitrine pour absorption d’impact sont fortement recommandés avec l’orientation vers l’avant. Retirez les coussinets de poitrine avec l’orientation vers l’arrière afin d’assurer un ajustement parfait pour les petits enfants.
Page 67
Table des matières MARATHON CLICKTIGHT Guide d’utilisation 7. Attachez le harnais et la boucle. REMARQUE : Après avoir inséré chaque languette de la boucle, un déclic confirmera que la boucle est bien attachée. 8. Vérifiez que la hauteur du harnais est adéquate et tirez l’excédent au-dessus...
Table des matières Britax Child Safety, Inc. Fonctionnement du siège pour enfant Réglage de la hauteur du harnais ‐ En orientation vers l’arrière, les sangles du harnais sont dans la position la plus proche au-dessous des épaules de l’enfant. Voir page 7.
Page 69
Table des matières MARATHON CLICKTIGHT Guide d’utilisation 3. Enfilez l’extrémité du harnais dans l’ouverture située à l’intérieur de la barre de métal derrière l’ancre, au fond de la zone d’assise. 4. Enroulez l’extrémité du harnais à l’extérieur de la barre et faites glisser la boucle du harnais complètement à...
Table des matières Britax Child Safety, Inc. Position de la boucle du harnais La coque du siège d’enfant contient une fente de boucle intérieure et une fente de boucle extérieure. Placez la boucle dans la fente la plus FENTE INTÉRIEURE proche de l’enfant, mais pas...
Table des matières MARATHON CLICKTIGHT Guide d’utilisation Coussin de confort Le coussin de confort est conçu pour offrir le meilleur réglage et un confort sans pareil aux enfants installés dans ce siège pour enfant. REMARQUE : Retirez le coussin de confort lorsque l’enfant est en mesure de...
Table des matières Britax Child Safety, Inc. Dépassement du siège Il est essentiel que la base du siège pour enfant soit complètement à plat sur le siège de la voiture sans qu’il y ait d’espacement latéral. Conformément à l’illustration ci-contre, la base peut dépasser...
Table des matières MARATHON CLICKTIGHT Guide d’utilisation Barre anti-rebond MISE EN GARDE! La barre anti-rebond ne doit pas être utilisée comme poignée de transport. Ne pas utiliser la barre anti-rebond pour porter le siège pour enfant. IMPORTANT : La barre anti-rebond DOIT être retirée dans les installations vers l’avant.
Table des matières Britax Child Safety, Inc. Utilisation du dispositif universel d’ancrages (DUA) et courroie d’ancrage Le dispositif universel d’ancrages d’attaches inférieures ou DUA, est un système disponible sur ce siège pour enfant qui offre une alternative aux méthodes d’installation avec les ceintures de sécurité...
• Britax recommande d’utiliser la courroie lorsque le siège est orienté vers l’avant. La courroie d’ancrage permet d’améliorer la stabilité du siège et de réduire le risque de blessure.
Page 76
Table des matières Britax Child Safety, Inc. Utilisation de la courroie d’ancrage IMPORTANT : N’utilisez pas la sangle de la courroie d’ancrage supérieure pour une installation orientée vers l’arrière. Pour attacher la courroie d’ancrage au boulon d’ancrage : 1. Appuyez fermement le crochet sur le boulon d’ancrage.
Page 77
Table des matières MARATHON CLICKTIGHT Guide d’utilisation La courroie d’ancrage comme indicateur de collision La courroie d’ancrage peut indiquer si le siège pour enfant a été impliqué dans une collision modérée ou grave (voir « remarques importantes » en page 5) et si le remplacement du siège en question est nécessaire.
Table des matières Britax Child Safety, Inc. Compatibilité du véhicule Places assises du véhicule MISE EN GARDE! NE PAS placer le siège pour enfant sur le siège avant du véhicule avec un sac gonflable du côté passager. Ceci peut entraîner la MORT ou des BLESSURES GRAVES.
REMARQUE : Ce siège pour enfant Britax peuvent ne pas être compatible avec tous les ceintures gonflables dans tous les fabricants et modèles de véhicules. Voir les FAQ dans la section support du site Britax (us.britax.com/faqs), pour obtenir des instructions supplémentaires.
Table des matières Britax Child Safety, Inc. Entretien IMPORTANT : Avant chaque utilisation, vérifiez ce siège d’auto et ses composants pour vous assurer qu’ils sont en bon état et en bon état de marche. Housse Retirer la housse MISE EN GARDE! Ne retirez jamais les boucles à...
Page 81
Table des matières MARATHON CLICKTIGHT Guide d’utilisation d. Tirez l’extrémité du coussinet abdominal et de la retenue de boucle hors de la fente de boucle située dans la housse pour l’enlever Placez de biais la retenue de boucle et glissez la boucle hors du coussinet abdominal (voir page 39).
Page 82
Table des matières Britax Child Safety, Inc. Replacer la housse Fixez un des côtés de la partie supérieure de la housse de la coque au passage de ceinture de l’orientation vers l’avant, tirez la housse sur le dossier de la coque et fixez solidement le passage de ceinture opposé.
Page 83
Table des matières MARATHON CLICKTIGHT Guide d’utilisation Réattachez les deux sangles élastiques à l’avant de la partie inférieure de la coque. Replacez la boucle et le coussinet abdominal : Placez de biais la retenue de boucle et passez-la dans le coussinet abdominal.
Table des matières Britax Child Safety, Inc. 6. Remettez la housse de l’appuie-tête en place. a. Desserrez le harnais et levez le coussin de tête à la position la plus haute. b. Glissez le coussin d’appui-tête pour installer. c. Pour certains...
Page 85
Table des matières MARATHON CLICKTIGHT Guide d’utilisation 4. Tirez l’extrémité du coussinet abdominal et de la retenue de boucle hors de la fente située dans la housse pour l’enlever. 5. Placez de biais la retenue de boucle et passez l’ensemble de boucle hors du coussinet abdominal.
Table des matières Britax Child Safety, Inc. 5. Remettez la housse du fond de siège en place en vérifiant si elle est bien emboîtée derrière la barre CLICKTIGHT, puis fermez la porte CLICKTIGHT. Coussinets de poitrine pour absorption d’impact Les coussinets de poitrine pour absorption IMPORTANT : d’impact sont fortement recommandés avec l’orientation vers...
Page 87
Table des matières MARATHON CLICKTIGHT Guide d’utilisation Passez les sangles du harnais du siège vers l’arrière. Assurez-vous que TUBE les sangles du harnais passent sur le tube. Placez l’extrémité de la sangle gauche du harnais dans la droite. Faites glisser entièrement les sangles du harnais dans la chape.
Page 88
Table des matières Britax Child Safety, Inc. Repassez la sangle du harnais dans le coussinet de poitrine, l’attache à la poitrine et le coussinet de confort. Faites de même avec l’autre sangle. 7. Passez les sangles du harnais du siège vers l’arrière.
Table des matières MARATHON CLICKTIGHT Guide d’utilisation Nettoyage Coque NE PAS • NETTOYEZ À L’ÉPONGE la coque en utilisant de • Utiliser de l’eau chaude et du savon nettoyants doux. abrasifs. • SÉCHEZ AVEC UNE SERVIETTE Housse • Se reporter à l’étiquette NE PAS d’entretien du produit pour...
Table des matières Britax Child Safety, Inc. Garantie Ce siège pour enfant a été fabriqué par Britax Child Safety, Inc. (« Britax »). Britax garantit ce produit à l’acheteur original comme suit : GARANTIE LIMITÉE D’UN AN Ce produit est garanti contre les vices de matériaux ou de fabrication pendant un an à...
Page 92
Tel.: 1-888-427-4829 Britax Child Safety, Ltd. P .O. Box 7289, Tel.: 1-704-409-1699 RPO Brunswick Square, Saint John NB E2L 4S6 A Britax Childcare Group Limited www.Britax.ca company Une société de Britax Childcare Group Limited...
