1.
To make assembly easier, read the
information on page 5 before you begin.
Remove the screws and the metal shipping
bracket (not shown) from the underside of the
Frame (2). Discard the screws and the shipping
bracket.
While a second person tips the Frame (2)
backward, attach the Front Stabilizer (98) to the
Frame with two M10 x 88mm Patch Screws
(104) and two M10 Split Washers (72).
2. Carefully tip the Frame (2) onto its side. Orient
the Base (1) as shown, and then insert the Base
into the Frame. Attach the Base with two M10 x
62mm Patch Screws (97), two M10 Spacers
(76), two M10 x 48mm Patch Screws (78), and
two M10 Split Washers (72).
Tighten two Feet (26) and two Rear Foot
Spacers (102) into the underside of the Base
(1).
Then, carefully tip the elliptical exerciser to an
upright position.
1
72
104
2
1
26
102
26
6
2
98
2
1
76
72
97
78
