General Installation Process

The installation instructions in this section are for common components of Intel® Server System
R2000LH2/LT2 Product Family.
Minimum Hardware Requirements
To avoid integration difficulties and possible board damage, your system must
meet the following minimum requirements:
• Processor:
Intel Xeon ® processor E5-4600 product family.
®
• Memory Type:
Minimum of one 512MB DDR3 1066/1333 MHz UDIMM or one 1GB
DDR3 1066/1333 MHz RDIMM.
• Hard Disk Drives: SATA
For a complete list of compatible processors, heatsinks, and memory, see
http://www.intel.com/support.
2

Remove Power Supply Module

C
B
4

Remove Add-in Card Riser Assembly

A
Pull up the release lever of the
riser assembly.
B
Grasp the riser assembly with
both hands and pull up to
remove from system.
A
B
A
Push the green
latch to unlock the
power supply.
B
While pushing the
green latch, pull
the power supply
out of the system
by the handle.
A
C
Repeat step A and
B to remove the
second power
supply.
CAUTION: Place the
riser assembly upside
down or sideways to
avoid damage to the riser card
connector.
A
B
1

Preparing System

Observe normal ESD (Electrostatic Discharge)
procedures.
Place your Intel
surface to perform the following integration procedures.
Observe ESD procedures before reaching inside to make
server board connections or install components.
3

Remove Top Cover

A
Remove three screws.
B
Slide cover back and lift upward.
B
5

Remove Air Duct

A
Lift up the
tilt bay.
B
Bend and
slide out
the air duct.
2
® Server System on a flat anti-static
A
B
CAUTION:
Unplug all
A
AC power cords
and remove all
power supply
modules before
lifting tilt bay.
B
C
B
C
Remove the air duct from
the chassis.
