System Overview

Intel® Server System R2000LH2/LT2 Product Family
System Features and Components
Optical Drive Bay
Hard Drive Bays
* 3.5" Hard Drive Bay system as shown
Useful Information:
• The SCU1 (4-7) port requires an Intel
System Fans
Front Control Panel
RAID C600 Upgrade Key installed to be functional.
®
1+1 Redundant Power Supply Modules
Add-in Card Riser Assembly
CPU2
CPU 3
Server Board
CPU4
1
CPU1
Air Duct
