This appliance shall be installed in accordance with:
• Manufacturer's Installation Instructions
• Current AS/NZS 5601 AS/NZS 3000
• Local Regulations and Municipal Building Codes including local OH&S requirements
This appliance must be installed, maintained and removed by an Authorised Person.
For continued safety of this appliance it must be installed and maintained in
accordance with the manufacturers instructions.
Split Type Wall Mounted Air Conditioner
COOL
DRY HEAT FAN
LOW
AUTO
C
SET
F
h
ROOM
ON
OFF
SWING
FAV
SWING

Operation Manual

To Suit Models:
RINV25R-A
RINV35R-A
RINV70R-A
