- Page 1 DT-V17L2D MULTI FORMAT LCD MONITOR MULTI FORMAT LCD MONITOR MONITEUR LCD MULTI-FORMAT MONITOR LCD MULTIFORMATO MONITOR LCD MULTIFORMATO МУЛЬТИФОРМАТНЫЙ ЖК МОНИТОР LCT2346-001A INSTRUCTIONS BEDIENUNGSANLEITUNG MANUEL D’INSTRUCTIONS ISTRUZIONI MANUAL DE INSTRUCCIONES ИHCТРУKЦИЯ ПО ЭКСПЛУАТАЦИИ ITALIANO ESPAÑOL FRANÇAIS РУССКИЙ DEUTSCH ENGLISH...
-
Page 2: Table Of Contents
DT-V17L2D MULTI FORMAT LCD MONITOR CAUTION RISK OF ELECTRICAL SHOCK DO NOT OPEN CAUTION: To reduce the risk of electric shock. Do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel. Table of Contents Safety Precautions ... -
Page 3: Safety Precautions
Safety Precautions WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS. IMPORTANT SAFEGUARDS Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety. -
Page 4: Maintenance
U.S.A. only FCC NOTICE CAUTION: Changes or modifications not approved by JVC could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 5: Installation
Installation CAUTION • Do not rest your arm on the monitor or lean against the monitor. • Do not touch the LCD panel when installing the monitor. • Make sure to install the monitor securely to prevent the monitor from falling over, which causes damage to the monitor or injury. - Page 6 To adjust the stand height You can select the stand height—higher position or lower position. To change the stand height, change the position of the stand plate as illustrated below after detaching the stand from the monitor. • For detaching the stand, see “To detach the stand” on page 4. <Higher position>...
-
Page 7: Daily Operations / Connections
Daily Operations / Connections 7 Front panel • “NO EFFECT” is displayed when you press a button which is not available for the current input or signal format (the lamp lights even when the function does not Tally lamp • The items controlled by the MAKE system cannot be controlled by the buttons on the front panel (“REMOTE ON” is displayed and the lamps do not light). This lamp is controlled by the tally function of the MAKE/TRIGGER terminal (☞... - Page 8 Menu Operations Audio Channel Selection Select audio channels emitted from the speakers Display the menu. (L/R) and the MONITOR OUT (L/R) terminals, To display the MAIN MENU when EMBEDDED AUDIO signals come in to the \ Press MENU button. E. AUDIO HD/SD SDI terminal (IN1 or IN2) and To display the SET-UP MENU SDI input (1 or 2) is selected.
-
Page 9: Rear Panel
Daily Operations / Connections (cont.) 7 Rear panel Carry handle Use this handle when carrying the monitor. Security slot Install a security wire to this slot. 1 REMOTE terminal Terminal for controlling the monitor by an external control. ☞ “External Control” on page 14 2 VIDEO terminals (BNC) Input (IN) and output (OUT) terminals for the composite signals. -
Page 10: Available Signals
7 Available signals The following signals are available for this monitor. Video signals Signal format shown in the COMPONENT Signal name status display VIDEO (Analog (☞ page 7) component) NTSC NTSC √ √ B/W50 B/W50 √ B/W60 B/W60 √ 480/59.94i 480/60i —... -
Page 11: Menu Configuration-Main Menu
Menu Configuration—MAIN MENU For the operation procedure, see page 7. Operation guide Shows the buttons for each operation. • The menu automatically disappears in about 30 seconds after the previous operation. • Some items may not appear on the menu depending on the input or the input signal. •... - Page 12 Adjustment bar Displayed when selecting “BALANCE.” Operation guide Shows the buttons for each operation. • The menu automatically disappears in about 30 seconds after the previous operation. • Some items may not appear on the menu depending on the input or the input signal. •...
-
Page 13: Menu Configuration-Set-Up Menu
Menu Configuration—SET-UP MENU For the operation procedure, see page 7. Operation guide Shows the buttons for each operation. • The menu automatically disappears in about 30 seconds after the previous operation. • Some items may not appear on the menu depending on the input or the input signal. - Page 14 Operation guide Shows the buttons for each operation. • The menu automatically disappears in about 30 seconds after the previous operation. • Some items may not appear on the menu depending on the input or the input signal. • The items controlled by the MAKE system do not appear on the menu. NOTE Setting of “CHARACTER SET.”...
-
Page 15: External Control
External Control 7 About the external control This monitor has three external control terminals. • MAKE/TRIGGER terminal (RJ-45): The following external control systems are available. (1) MAKE (make contact) system: Controls the monitor by short-circuiting the corresponding pin terminal to the GND pin terminal, or disconnecting (opening) it (☞... -
Page 16: Using The Serial Communication
Operation Set “PARALLEL TYPE” of “REMOTE SETTING” to “MAKE” or “TRIGGER” in the SET-UP MENU. Short-circuit the 7th pin terminal (ENABLE) to the 8th pin terminal (GND) so that the monitor can be controlled by the external control. When selecting “MAKE” system: Operate each function by short-circuiting the corresponding pin terminal to the 8th pin terminal (GND) or opening it. -
Page 17: Troubleshooting
Troubleshooting Solutions to common problems related to the monitor are described here. If none of the solutions presented here solves the problem, unplug the monitor and consult an authorized dealer or service center. Symptom Probable cause and corrective action • Turn on the POWER switch or DC switch on the rear panel. •... -
Page 18: Specifications
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. Notice on transportation This monitor is precision equipment and needs dedicated packing material for transportation. Never use any packing material supplied from sources other than JVC or JVC-authorized dealers. 7 Input/output terminals VIDEO Input/output of composite signal: 1 line, BNC connector x 2, 1 V(p-p), 75 Ω... -
Page 19: Dimensions
