MULTI FORMAT LCD MONITOR
DT-V24G2
DT-V21G2
DT-V17G2
DT-V17G25
INSTRUCTIONS
This is the English instruction manual. Instruction manuals in other languages (German, French, Italian,
Spanish, Russian) are included on the supplied CD-ROM as PDF files (for Europe only).
For Customer Use:
Enter below the Model No. and Serial No.
which is located on the body. Retain this
information for future reference.
Model No.
:
Serial No.
:
The illustration of the monitor is of DT-V21G2.
Please read the following before getting
started:
Thank you for purchasing this product.
Before operating this unit, please read the
instructions carefully to ensure the best
®
possible performance.
B5A-1245-00

Advertisement

Table of Contents
loading

Summary of Contents for JVC DT-V21G2

  • Page 1 DT-V17G2 DT-V17G25 INSTRUCTIONS The illustration of the monitor is of DT-V21G2. This is the English instruction manual. Instruction manuals in other languages (German, French, Italian, Spanish, Russian) are included on the supplied CD-ROM as PDF files (for Europe only). For Customer Use: Please read the following before getting Enter below the Model No.
  • Page 2: Safety Precautions (English)

    FCC NOTICE CAUTION: Changes or modifications not approved by JVC could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 3: Table Of Contents

    Operating Precautions The LCD panel and backlight have life expectancy. Due to the basic characteristics of the LCD panel, an afterimage or uneven display may occur. It is recommended that you change images occasionally, activate the power saving function, or often turn off the power to reduce the load on the LCD panel.
  • Page 4: Installation

    0° Stand Approx. 6° The illustration of the Monitor monitor is of DT-V21G2. Be careful not to pinch your fingers in the gap between the The illustration of the monitor and the stand. monitor is of DT-V21G2. How to set up 2 To install the stand You can place the monitor as illustrated below.
  • Page 5: Index Of Parts And Functions

    DT-V21G2. Note for connections and the equipment. 1 REMOTE terminal 9 Screw holes for external battery attachment (DT-V21G2/DT- Terminal for controlling the monitor by an external control V17G2 only) (+ “External Control” on page 20). Attach external battery for DC power supply by using 2 screw 2 VIDEO terminals (BNC) holes.
  • Page 6: Front Panel

    You can also select whether the whole lamp is turned on at once, or whether it is turned on one half at a time. (+ “Tally Setting” in “Function Setting” on page 15 and “External Control” on page 20) The illustration of the monitor is of DT-V21G2. 1 - e, i and ; are common to DT-V24G2, DT-V21G2, DT-V17G2 and DT-V17G25.
  • Page 7 Select the style of the area marker in “Marker” of the Main Menu (+ page 12). o DC lamp (DT-V21G2/DT-V17G2 only) This function works only when displaying the picture in 16:9 When the DC power voltage is being lowered due to the battery aspect ratio.
  • Page 8: Showing Input Signals

    Showing Input Signals Audio Channel Selection Select the audio channel output from the Speaker and AUDIO ASSIGN (MONITOR OUT) (OUT1(L)/OUT2(R)) terminals when an EMBEDDED AUDIO signal is input during SDI input. Embedded Audio screen Store the setting for each input of SDI 1 and SDI 2. <...
  • Page 9: Menu Configuration

    Menu Configuration First Time Installation When you turn on the power and the monitor, “First Time Installation” appears. Start setting referring to the menu configuration. < First Time Installation > For the setting items, see the pages below. Language : English No Sync Action : Off...
  • Page 10: Menu Transition Diagram

    Menu Configuration (cont.) Menu Transition Diagram Main Menu Backlight Picture Memory Mode Picture Function Aperture H Size Save Aperture Level H Position Setting Size/Position Adjust V Size V Postion Gamma sub menu Aspect Color Temperature reset Picture Memory Auto Aspect sub menu Manual Aspect Zebra...
  • Page 11: Main Menu

    Main Menu Picture Function Setting for the picture quality. Item To do Setting value Backlight Adjusts the brightness of the display. –20 to +20 Aperture* Activates/deactivates the function at the level set in “Aperture Level”. Off, On Aperture Level* Compensate the frequency response of the luminance signal of the video signal. 01 to 10 Adjust the clearness of the outlines of the chrominance signal.
  • Page 12 Menu Configuration (cont.) 1:1* Displays the picture in the original resolution of the input signal. Off, On The aspect ratio of the picture may change depending on the input signal. 16:9 Size* Normal, V Full Selects the picture size when the input signal format is 16:9. Normal Matches the vertical picture size to the number of pixels.
  • Page 13: Audio Setting

    Audio Setting Settings for AUDIO signals, EMBEDDED AUDIO signals and audio level meter signal. Item To do Setting value Balance Adjust the balance between the right and left speakers. L5 to L1, 0, R1 to R5 SDI-1 Select* Select the input through which audio is output. Off, Auto, Digital, Analog1, SDI-2 Select* Analog2...
  • Page 14 Menu Configuration (cont.) Transparent Adjust the transparency of the level meter display against the image. Off, Background, All Peak Hold Activates/deactivates the peak hold function of the level meter. Off, On Lissajous Setting Lissajous setting <Lissajous display example> H Axis Channel(X) Select an EMBEDDED AUDIO CH to display on the horizontal axis of the Lissajous screen.
  • Page 15: Set-Up Menu

    Sync Function Settings for the synchronization with signals. Item To do Setting value No Sync Action Select the screen status when no signal is coming in. Off, Standby, Power Save (power save mode) Gray Back (gray screen) Delay Time Select the period until the screen status changes as selected in “No Sync Action” after signals 30s, 5min, 15min stop coming in.
  • Page 16 Menu Configuration (cont.) Standby Mode Select the operation status when the monitor is powered OFF (standby). Normal, Serial, SDI Out Normal Changes to Low Power Mode 30 seconds after powered OFF to reduce power consumption. In this case, it cannot power on by external control. Serial Can power on by external control after powered OFF.
  • Page 17 White Balance Setting Display the color temperature, and adjusts the drive level and cutoff point of each color (R/G/B). Item To do Setting value Color Temperature Select the color temperature. (Cannot be set/changed) 9300K, 6500K, 5600K, User R Drive * Adjust the drive level of each color (red, green, and blue).
  • Page 18 Off : Not displayed On : Displayed IMD Protocol Serial communication protocol setting Off, TSL V4.0 Off : Supports JVC protocol TSL V4.0 : Supports TSL UMD Protocol V4.0 Address Address setting 000 to 126 000 to 126 : Set a particular address...
  • Page 19 Setting of “Character Setting” Change the input to one that you want to assign a video source name for. Select “Character Setting”. C h a r a c t er S et t i ng Press buttons to select the first character. Each time you press button, the character changes as follows.
  • Page 20: External Control

    External Control About the external control Using the MAKE/TRIGGER system This monitor has two external control terminals. The MAKE/TRIGGER terminal is configured as follows. MAKE/TRIGGER terminal (RJ-45): The following external control You can assign a function to each pin terminal in “Remote Setting”. systems are available.
  • Page 21: Using The Serial Communication

    <Functions controlled by the MAKE/TRIGGER system> Display Functions to be controlled Opening Short-circuiting – – – No function — — Tally lamp color selection* Green Tally Color Tally lamp lighting method selection Whole One half at a time Tally Type Light the left half of the tally lamp in red* Tally-L(R) Light the right half of the tally lamp in green*...
  • Page 22 External Control (cont.) <Specifications of the RS-485 terminal> <Specifications of the RS-232C terminal> OUT terminal Pin No. Signal Pin No. IN terminal signal signal TXD + TXD + TXD – TXD – RXD + RXD + RXD – RXD – This is a female This is a female terminal.
  • Page 23: Troubleshooting

    Press the button. (DT-V17G2/DT-V21G2 only) Firmly insert the AC power plug or DC power plug. (DT-V17G2/DT-V21G2 only) Turn on the POWER switch or DC switch on the rear panel. No power supply. (DT-V17G25/DT-V24G2 only) Firmly insert the AC power plug.
  • Page 24: Self-Check Program

    If this happens, follow the steps below and contact your dealer to resolve the problem. The illustration of the monitor is of DT-V21G2. When the screen goes blank, and one or some of the INPUT SELECT lamps (COMPO., VIDEO) on the front control panel start flashing...
  • Page 25: Specifications

    Specifications General Model name DT-V24G2 DT-V21G2 DT-V17G2 DT-V17G25 Type Multi format LCD monitor Screen size Type 24 wide format Type 21.5 wide format Type 16.5 wide format Aspect ratio 16:10 16:9 Horizontal/vertical frequency 31.467 kHz – 75.000 kHz (computer signal) 49.990 Hz –...
  • Page 26: Dimensions

    This monitor is precision equipment and needs dedicated packing material for transportation. Never use any packing material supplied from sources other than JVC or JVC-authorized dealers. For easy understanding, pictures and illustrations are shown by being emphasized, omitted or composed, and may be slightly different from actual products.
  • Page 27: Available Signals

    Available signals The following signals are available for this monitor. √: Acceptable Video signals —: Not acceptable Input terminal Signal format shown in the 3G/HD/SD SDI (IN 1, IN 2)* Signal name status display VIDEO COMPO. HDMI SD/HD DUAL (+ page 8)* 3G SDI (1.5G) LINK...
  • Page 28: Sicherheitsmaßregeln (Deutsch)

    Beseitigung vom Benutzer geeignete Maßnahmen zu ergreifen sind. Ausschließlich mit der zulässigen Netzspannung. Netzstrom: 120 V / 220 V – 240 V, 50 Hz/60 Hz Gleichstrom: 12 V – 17 V (Nur DT-V21G2/DT-V17G2) VESA-Montagelöcher WARNUNG Zum Verhindern von Verletzungen durch versehentliches Herunterfallen Bringen Sie den Monitor mit Drähten an einer Wand an.
  • Page 29: Précautions De Sécurité (Français)

    être requis de prendre les mesures correctives nécessaires. N’utiliser que la source d’alimentation spécifiée sur l’appareil. Alimentation secteur: 120 V / 220 V – 240 V, 50 Hz/60 Hz Alimentation CC: 12 V – 17 V (DT-V21G2/DT-V17G2 uniquement) Trous de montage VESA AVERTISSEMENT Pour éviter les blessures causées par une chute...
  • Page 30: Precauzioni Di Sicurezza (Italiano)

    Usare solamente le sorgenti di alimentazione specificate sull’apparecchio. Alimentazione CA: 120 V / 220 V – 240 V, 50 Hz/60 Hz Alimentazione CC: 12 V – 17 V (Solo DT-V21G2/DT-V17G2) Fori per montaggio VESA AVVERTENZA Per impedire la caduta accidentale del monitor e conseguenti lesioni alle persone Fissare il monitor a una parete usando cavi robusti.
  • Page 31: Precauciones De Seguridad (Español)

    Utilice sólo la fuente de alimentación especificada en la unidad. Alimentación de CA: 120 V / 220 V – 240 V, 50 Hz/60 Hz Alimentación de CC: 12 V – 17 V (Sólo DT-V21G2/DT-V17G2) Orificios de montaje VESA ADVERTENCIA Para evitar lesiones mediante una caída accidental...
  • Page 32: Меры Предосторожности (Русский)

    Меры предосторожности (Русский) Переменный ток: 120 В/220 В – 240 В, 50 Гц/60 Гц Постоянный ток: 12 В – 17 В (Только DT-V21G2/DT-V17G2) Крепежные отверстия стандарта VESA Крепление монитора Крюк и винт (M4 x 10 мм) Крюк (не прилагается) (не прилагаются) На...
  • Page 33: Указатель Частей И Функций

    выключите выключатель DC. включен или находится в режиме “Энергосбереж.”. Сигнал EMBEDDED AUDIO... q Разъем DC IN (только DT-V21G2/DT-V17G2) – декодируется в аналоговый сигнал и затем выводится; Разъем для подсоединения источника – выводится, только когда выбрано “SDI 1” или “SDI 2” и когда сигналы...
  • Page 34 Также можно выбрать режим работы индикатора: он может включаться сразу полностью либо наполовину за раз. На рисунке изображен монитор DT-V21G2. 1 - e, i и ; являются общими для DT-V24G2, DT-V21G2, DT-V17G2 и DT-V17G25. На рисунке изображен монитор DT-V21G2. DT-V24G2 DT-V17G25 горит, даже...
  • Page 35 “Энергосбереж.” формате 16:9. (энергосбережения). Эта функция не работает, когда для параметра “Маркер o Индикатор DC (только DT-V21G2/DT-V17G2) области” или “Маркер области - R” установлено значение “Выкл.” в поле “Маркер”. Когда напряжение источника питания постоянного тока понижается из-за расхода заряда батареи, индикатор изменяет...
  • Page 36 © 2016 JVC KENWOOD Corporation B5A-1245-00...
