Refit the dashboard, Torque tighten the passenger front airbag bolts on the dashboard
cross member (8 N.m). Connect the passenger front airbag connectors (3). Lock the
passenger front airbag connectors (3). Connect the battery. Switch on the ignition.
Check that there are no faults on the instrument panel.
Front Side Airbag or Front Side + Curtain Airbag
The front side (chest-level) airbag is fixed to the lower section of the seatback of each front
seat on the door side. The airbag tears the module cover and the seatback cover when it
deploys.
Removal
Disconnect the battery, the front seat (75A, Front seat frames and runners),
- the front seatback cover partially(77A, Front seat trim).
Mark the wiring routing on the seat frame, Unlock the front side (chest-level) airbag connector
at (2) .
