  • Page 1 Installed on bike model, number plate/frame: INSTALLATION AND USE MANUAL GEMINI Technologies S.p.A. Via Luigi Galvani 12 - 21020 Bodio Lomnago (VA) - Italia Tel. +39 0332 943211 - Fax +39 0332 948080 Web site: www.gemini-alarm.com For all EU Countries AC 2743/UK-REV.00- 01/10/08...
  • Page 2: Table Of Contents

    CONTENTS CONTENTS INSTALLER MANUAL - PRELIMINARY ADVICE USER MANUAL 14.0 INSTRUCTIONS FOR ALARM SYSTEM INSTALLATION - ALARM SYSTEM CONTROL DEVICES DESCRIPTION 15.0 TECHNICAL DATA 2.1 - Remote control 16.0 CONTROL UNIT POSITIONING 2.2 - Electronic key 17.0 ACCESSORIES POSITIONING - SYSTEM OPERATION WITH BASIC CONFIGURATION 17.1 - Receptacle for electronic key and LED 3.1 - Arming 17.2 - Perimetral push-button (optional)
  • Page 3: Preliminary Advice

    A further possibility to deactivate the system, when needed, is given by the 953: Nr. 2 remote control, Nr. 1 electronic key and self-powered. PIN-CODE. 953.02: Nr.
  • Page 4: Electronic Key

    2.2 - ELECTRONIC KEY 3.0 - SYSTEM OPERATION WITH The electronic key can be considered a kind of “simplified remote control”. BASIC CONFIGURATION As a matter of fact, in emergency situations (e.g. a failure in the remote 3.1 - ARMING control), it can activate and deactivate the alarm, or activate and deactivate the Pressing the (dotted) button #1 on the remote control or inserting the electronic anti-hijacking function (if previously programmed).
  • Page 5: Armed Condition

    3.6 - ARMED CONDITION 3.10 - SYSTEM DISARMING WITHOUT ALARM MEMORY At the end of the neutral time, after about 20 seconds, the alarm system goes in Pressing the button N.1 (dotted) on the remote control or inserting the the armed condition and signals this with a blinking LED. electronic key in the receptacle will deactivate the system.
  • Page 6: Acoustic And Optic Signalling

    4.3 - SHOCK SENSOR 4.0 - DESCRIPTION OF THE EXTRA FUNCTIONS The system may generate an alarm condition caused by a shock or a shifting of The table below shows the programmable functions. the vehicle The shock sensor is buil in the alarm and is adjustabl The manufacturer supplies the system with some of these functions disabled (in order to achieve a good trade-off between ease and completeness of use) FUNCTIONNING...
  • Page 7: Pre-Alarm

    WARNING Gemini Technologies S.p.A. is not responsible for damages to the system in case of an improper use of it.
  • Page 8: Xample Eof System Unlock By Pin-Code

    8.0 - UNLOCK PROCEDURE BY PIN-CODE 9.0 - EXAMPLE OF SYSTEM UNLOCK BY PIN-CODE The PIN-CODE procedure allows deactivating the alarm system in case of To better understand the alarm system unlock by means of PIN-CODE, please emergency, that is to say when, for any reason whatsoever, the remote control refer to the following example considering the case of a PIN-CODE formed by or the electronic key cannot be used these digits: 2-3-4-1...
  • Page 9: Example Of Pin-Code Personalization

    Push both remote control buttons at the same time. 10.0 - EXAMPLE OF PIN-CODE PERSONALIZATION The LED will go off. To better understand how to set up the PIN-CODE, please refer to the example below. The following customized PIN-CODE 2-3-4-1 will be entered.
  • Page 10: Remote Control Batteries Replacement

    The warranty will become void if labels are missing or torn, if the installation certificate is not fully compiled or if the enclosed sale document is missing. The guarantee is valid exclusively at Authorized Gemini Technologies S.p.A. Centers. The manufacturer declines any responsibility for eventual malfunctions of the...
  • Page 11: Installer Manual

    GEMINI TECHNOLOGIES S.p.A. alarm system making both the alarm system and GEMINI TECHNOLOGIES S.p.A. reserves its right to make any changes vehicle unreliable. to these characteristics without giving prior notice to its potential buyers No part of this document can be reproduced without GEMINI TECHNOLOGIES’s prior written authorization...
  • Page 12: Accessories Positioning

    17.0 - ACCESSORIES POSITIONING 18.0 - CONTROL UNIT SEALING 17.1 - RECEPTACLE FOR ELECTRONIC KEY The receptacle with buil in LED (or the only LED) must be set up where the user can easily see and access to it. Please remember that the LED represents the first deterrent against an ill- intentioned person.
  • Page 13: Summary Report For The Electrical Connections

    19.0 - UMMARY REPORT FOR THE ELECTRICAL 20.0 - ELECTRIC DIAGRAM CONNECTIONS CAUTION The tables below refer to the generic wiring harness (KITCA 417). Refere to installation sheets for available specific wiring harness (www- gemini-alarm.com private area). Pos. Wire colour Wire function - 1 - Brown...
  • Page 14: Engine Immobilisation Connecting Diagram (Ground Wire)

    21.0 - ENGINE IMMOBILISATION CONNECTING DIAGRAM 22.0 - ENGINE IMMOBILISATION CONNECTING DIAGRAM ENGINE BLOCK WITH GROUNDED WIRE ENGINE BLOCK WITH CUT WIRE Most small motorbikes with Most large motorcycles with two-stroke engines use four-stroke this system. engines use this system. White White White/Grey...
  • Page 15: Example Of Engine Immobilisation Connection With

    23.0 - EXAMPLE OF ENGINE IMMOBILISATION CONNECTION 23.0 - EXAMPLE OF ENGINE IMMOBILISATION CONNECTION WITH SPECIFIC WIRING HARNESS WITH SPECIFIC WIRING HARNESS Ignition key Insert the alarm Ignition key unit connector into the ignition key connector Alarm system Vehicle’s electrical equipment before the installing of the Insert the alarm specific wiring harness...
  • Page 16: Electric Al Connections With Specific Wiring

    24.0 - ELECTRICAL CONNECTIONS WITH SPECIFIC 25.0 - INSTRUCTIONS FOR DIODE APPLICATION WIRING HARNESS In order to verify if it must be installed on the vehicle, please follow the procedure below: Once the secure position of the system and its peripherals (receptacle for Switch on the turn signal switch of the direction indicator lights and arm the electronic key, under-saddle or trunk push-button) has been found, the system.
  • Page 17: Learning Of New Devices (With Ground Wire)

    26.0 - LEARNING OF NEW DEVICES 27.0 - LEARNING OF NEW DEVICES (BY BROWN/GREEN WIRE GROUND CONNECTION) (WITHOUT BROWN/GREEN WIRE GROUND CONNECTION) The system is supplied with two remote controls and an electronic key, but The system is supplied with two remote controls and an electronic key, but saving to memory or replacement of electronic keys or radio controls could be saving to memory or replacement of electronic keys or radio controls could be necessary...
  • Page 18: Extra Functions Programming

    If the seat/top case button has not been installed on the vehicle, Button N.1: ENABLE ground the GREEN/BROWN wire. ACOUSTIC SIGNALS Once terminated the (enabled by Gemini) Button N.2: DISABLE programming operations, unground this wire. Button N.1: ENABLE PANIC ALARM (enabled by Gemini) Button N.2: DISABLE...
  • Page 19: Example Of Programming

    Once the last function has been (or not) enabled, the programming procedure is automatically over. Th is will be signalled by t low-tone Entering the programming procedure resets the functions to Gemini acoustic signasl , a high-tone acoustic signal and the turning off of the default setting.
  • Page 20: Example Of Shock Sensor Adjustment

    FR, GR, IR, I, L, NL, P, SP, S, UK Turn the ignition key of the vehicle in “OFF” position. GEMINI Company responsible for placing on the market: The system confirm the end of the procedure by an optical signal of the TECHNOLOGIES Società...
