Icom IC-7600 Service Manual page 66

[BPF UNIT]
REF PARTS
DESCRIPTION
NO. NO.
D3201 1750000581 S.DIO 1SV307(TPH3,F)
D3202 1750000581 S.DIO 1SV307(TPH3,F)
D3301 1750000581 S.DIO 1SV307(TPH3,F)
D3302 1750000581 S.DIO 1SV307(TPH3,F)
D3401 1750000581 S.DIO 1SV307(TPH3,F)
D3402 1750000581 S.DIO 1SV307(TPH3,F)
D3501 1750000581 S.DIO 1SV307(TPH3,F)
D3502 1750000581 S.DIO 1SV307(TPH3,F)
D3601 1750000581 S.DIO 1SV307(TPH3,F)
D3602 1750000581 S.DIO 1SV307(TPH3,F)
L3201 6180003540 COI SP0406-3R9K-6
L3202 6180003580 COI SP0406-120K-6
L3203 6180003580 COI SP0406-120K-6
L3204 6180003540 COI SP0406-3R9K-6
L3205 6180003580 COI SP0406-120K-6
L3301 6180003550 COI SP0406-4R7K-6
L3302 6180003560 COI SP0406-5R6K-6
L3303 6180003560 COI SP0406-5R6K-6
L3304 6180003550 COI SP0406-4R7K-6
L3305 6180003560 COI SP0406-5R6K-6
L3401 6180003410 COI SP0406-2R2K-6
L3402 6180003510 COI SP0406-6R8K-6
L3403 6180003510 COI SP0406-6R8K-6
L3404 6180003410 COI SP0406-2R2K-6
L3405 6180003510 COI SP0406-6R8K-6
L3501 6180003410 COI SP0406-2R2K-6
L3502 6180003570 COI SP0406-3R3K-6
L3503 6180003570 COI SP0406-3R3K-6
L3504 6180003410 COI SP0406-2R2K-6
L3505 6180003570 COI SP0406-3R3K-6
L3601 6180003390 COI SP0406-1R2K-6
L3602 6180003490 COI SP0406-2R7K-6
L3603 6180003490 COI SP0406-2R7K-6
L3604 6180003390 COI SP0406-1R2K-6
L3605 6180003490 COI SP0406-2R7K-6
R3201 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3202 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3301 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3302 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3401 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3402 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3501 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3502 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3601 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3602 7030003320 S.RES ERJ3GEYJ 101 V (100)
C3201 4030017810 S.CER C1608 CH 1H 102J-T
C3202 4030011600 S.CER C1608 JB 1E 104K-T
C3203 4030017810 S.CER C1608 CH 1H 102J-T
C3204 4030010760 S.CER C1608 CH 1H 331J-T
C3205 4030007140 S.CER C1608 CH 1H 121J-T
C3206 4030007160 S.CER C1608 CH 1H 181J-T
C3207 4030007060 S.CER C1608 CH 1H 270J-T
C3208 4030010760 S.CER C1608 CH 1H 331J-T
C3209 4030007090 S.CER C1608 CH 1H 470J-T
C3210 4030007160 S.CER C1608 CH 1H 181J-T
C3211 4030007060 S.CER C1608 CH 1H 270J-T
C3212 4030010760 S.CER C1608 CH 1H 331J-T
C3213 4030007140 S.CER C1608 CH 1H 121J-T
C3214 4030017810 S.CER C1608 CH 1H 102J-T
C3215 4030011600 S.CER C1608 JB 1E 104K-T
C3216 4030017810 S.CER C1608 CH 1H 102J-T
C3301 4030017800 S.CER C1608 CH 1H 561J-T
C3302 4030011600 S.CER C1608 JB 1E 104K-T
C3303 4030010760 S.CER C1608 CH 1H 331J-T
C3304 4030007080 S.CER C1608 CH 1H 390J-T
C3305 4030010760 S.CER C1608 CH 1H 331J-T
C3306 4030010760 S.CER C1608 CH 1H 331J-T
C3307 4030007100 S.CER C1608 CH 1H 560J-T
C3308 4030007090 S.CER C1608 CH 1H 470J-T
C3309 4030010760 S.CER C1608 CH 1H 331J-T
C3310 4030010760 S.CER C1608 CH 1H 331J-T
C3311 4030007100 S.CER C1608 CH 1H 560J-T
C3312 4030007080 S.CER C1608 CH 1H 390J-T
C3313 4030010760 S.CER C1608 CH 1H 331J-T
C3314 4030017800 S.CER C1608 CH 1H 561J-T
C3315 4030011600 S.CER C1608 JB 1E 104K-T
C3316 4030010760 S.CER C1608 CH 1H 331J-T
C3401 4030011330 S.CER C1608 CH 1H 391J-T
C3402 4030011600 S.CER C1608 JB 1E 104K-T
C3403 4030017800 S.CER C1608 CH 1H 561J-T
C3404 4030007160 S.CER C1608 CH 1H 181J-T
C3405 4030007070 S.CER C1608 CH 1H 330J-T
C3406 4030007120 S.CER C1608 CH 1H 820J-T
C3407 4030007030 S.CER C1608 CH 1H 150J-T
C3408 4030007140 S.CER C1608 CH 1H 121J-T
C3409 4030007100 S.CER C1608 CH 1H 560J-T
C3410 4030007120 S.CER C1608 CH 1H 820J-T
C3411 4030007030 S.CER C1608 CH 1H 150J-T
C3412 4030007160 S.CER C1608 CH 1H 181J-T
C3413 4030007070 S.CER C1608 CH 1H 330J-T
C3414 4030011330 S.CER C1608 CH 1H 391J-T
C3415 4030011600 S.CER C1608 JB 1E 104K-T
C3416 4030017800 S.CER C1608 CH 1H 561J-T
C3501 4030010760 S.CER C1608 CH 1H 331J-T
C3502 4030011600 S.CER C1608 JB 1E 104K-T
C3503 4030007150 S.CER C1608 CH 1H 151J-T
C3504 4030007060 S.CER C1608 CH 1H 270J-T
C3505 4030007150 S.CER C1608 CH 1H 151J-T
[BPF UNIT]
H/V REF PARTS
M.
LOCATION NO. NO.
B 39.6/48.2 C3506 4030007140 S.CER C1608 CH 1H 121J-T
B 48.2/9.2 C3507 4030007060 S.CER C1608 CH 1H 270J-T
B 33.9/45.3 C3508 4030007010 S.CER C1608 CH 1H 100D-T
B 30.9/3.5 C3509 4030007150 S.CER C1608 CH 1H 151J-T
B 21.7/44.3 C3510 4030007140 S.CER C1608 CH 1H 121J-T
B 27.5/5.7 C3511 4030007060 S.CER C1608 CH 1H 270J-T
B 36.5/48.4 C3512 4030007060 S.CER C1608 CH 1H 270J-T
B 40/10.5 C3513 4030007150 S.CER C1608 CH 1H 151J-T
B 26.6/41.6 C3514 4030010760 S.CER C1608 CH 1H 331J-T
B 27.5/3.9 C3515 4030011600 S.CER C1608 JB 1E 104K-T
C3516 4030007150 S.CER C1608 CH 1H 151J-T
C3601 4030007170 S.CER C1608 CH 1H 221J-T
C3602 4030011600 S.CER C1608 JB 1E 104K-T
C3603 4030007170 S.CER C1608 CH 1H 221J-T
C3604 4030007130 S.CER C1608 CH 1H 101J-T
C3605 4030007050 S.CER C1608 CH 1H 220J-T
C3606 4030007080 S.CER C1608 CH 1H 390J-T
C3607 4030007070 S.CER C1608 CH 1H 330J-T
C3608 4030007120 S.CER C1608 CH 1H 820J-T
C3609 4030007050 S.CER C1608 CH 1H 220J-T
C3610 4030007080 S.CER C1608 CH 1H 390J-T
C3611 4030007070 S.CER C1608 CH 1H 330J-T
C3612 4030007130 S.CER C1608 CH 1H 101J-T
C3613 4030007050 S.CER C1608 CH 1H 220J-T
C3614 4030007170 S.CER C1608 CH 1H 221J-T
C3615 4030011600 S.CER C1608 JB 1E 104K-T
C3616 4030007170 S.CER C1608 CH 1H 221J-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
B 54.2/39.5
B 56.9/25.8
B 31.3/39.2
B 30.2/12.7
B 6/32.5
B 6/17.5
B 47.4/42.4
B 45.2/23.4
B 22/40.5
B 20.2/11.1
B 53.6/41.5
B 51/41.6
B 53.6/43.3
B 50.4/39.2
B 50.4/37.4
B 48/33.6
B 48/35.4
B 49.4/31.8
B 49.4/30
B 47.9/27.3
B 49.7/27.3
B 49.4/24.6
B 49.4/22.8
B 53/20.3
B 53/24.8
B 53/22.1
B 29.2/34.8
B 31.2/31.2
B 29.2/33
B 31.2/29.4
B 31.2/27.6
B 34.4/25
B 32.6/25
B 30/24.4
B 30/22.6
B 32.6/21.3
B 34.4/21.3
B 30/20.6
B 31.2/18.8
B 32.2/12.9
B 29.3/16.7
B 34/12.9
B 10.2/32
B 10.2/30.2
B 10.2/33.8
B 10.2/26.6
B 10.2/28.4
B 12.9/27.4
B 14.7/27.4
B 11.5/22.8
B 11.5/24.6
B 15.9/20.7
B 14.1/20.7
B 13.5/16.4
B 13.5/18.2
B 13.8/11.3
B 12/14.7
B 12/11.3
B 45.4/42.4
B 41.8/40.8
B 43.6/42.4
B 40.8/38.2
B 40.8/36.4
5 - 24
DESCRIPTION M.
LOCATION
B 38/34.5
B 38/32.7
B 39.3/30.9
B 39.3/29.1
B 38.8/26.4
B 40.6/26.4
B 39.3/23.7
B 38.8/21.9
B 42.6/19.6
B 42.6/23.2
B 42.6/21.4
B 20.8/34.8
B 22/42.4
B 20.8/33
B 21.8/29.4
B 21.8/31.2
B 22/26.8
B 23.8/26.8
B 21.8/22.2
B 21.8/24
B 24.4/20.8
B 26.2/20.8
B 23/18.2
B 23/16.4
B 22.2/11.3
B 21.5/14.2
B 24/11.3
S.=Surface mount
H/V
