Icom IC-7600 Service Manual page 51

[MAIN UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R3303 7030003800 S.RES ERJ3GEYJ 105 V (1M)
R3304 7030003360 S.RES ERJ3GEYJ 221 V (220)
R3305 7030003360 S.RES ERJ3GEYJ 221 V (220)
R3306 7030005321 S.RES ERA3YED 103V (10K)
R3307 7030005321 S.RES ERA3YED 103V (10K)
R3308 7030005321 S.RES ERA3YED 103V (10K)
R3309 7030009591 S.RES ERA3YED 472V (4.7K)
R3310 7030005321 S.RES ERA3YED 103V (10K)
R3311 7030009591 S.RES ERA3YED 472V (4.7K)
R3312 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3313 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3401 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3402 7030003280 S.RES ERJ3GEYJ 470 V (47)
R3403 7030007230 S.RES ERA3YED 102V (1K)
R3405 7030007230 S.RES ERA3YED 102V (1K)
R3406 7030007230 S.RES ERA3YED 102V (1K)
R3407 7030007230 S.RES ERA3YED 102V (1K)
R3408 7030007230 S.RES ERA3YED 102V (1K)
R3409 7030009591 S.RES ERA3YED 472V (4.7K)
R3410 7030007230 S.RES ERA3YED 102V (1K)
R3411 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3412 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3413 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R3414 7030003410 S.RES ERJ3GEYJ 561 V (560)
R3501 7030003400 S.RES ERJ3GEYJ 471 V (470)
R3502 7030003630 S.RES ERJ3GEYJ 393 V (39K)
R3503 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R3504 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R3505 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R3506 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R3507 7030003460 S.RES ERJ3GEYJ 152 V (1.5K)
R3508 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3509 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3510 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3511 7030003360 S.RES ERJ3GEYJ 221 V (220)
R3512 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3513 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R3514 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3515 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3516 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R3517 7030003400 S.RES ERJ3GEYJ 471 V (470)
R3518 7030003490 S.RES ERJ3GEYJ 272 V (2.7K)
R3519 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3520 7310005400 S.TRI EVM-3VSX50 BE4 (223)
R3521 7030003400 S.RES ERJ3GEYJ 471 V (470)
R3522 7030003550 S.RES ERJ3GEYJ 822 V (8.2K)
R3523 7030003530 S.RES ERJ3GEYJ 562 V (5.6K)
R3524 7030003500 S.RES ERJ3GEYJ 332 V (3.3K)
R3601 7030003860 S.RES ERJ3GE JPW V
R3602 7030003320 S.RES ERJ3GEYJ 101 V (100)
R3603 7030003200 S.RES ERJ3GEYJ 100 V (10)
R3604 7030003200 S.RES ERJ3GEYJ 100 V (10)
R3605 7030003280 S.RES ERJ3GEYJ 470 V (47)
R3606 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R3607 7030003550 S.RES ERJ3GEYJ 822 V (8.2K)
R3608 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R3609 7030003200 S.RES ERJ3GEYJ 100 V (10)
R3610 7030003300 S.RES ERJ3GEYJ 680 V (68)
R3611 7030003200 S.RES ERJ3GEYJ 100 V (10)
R3612 7030003550 S.RES ERJ3GEYJ 822 V (8.2K)
R3614 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R3616 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R3617 7030003400 S.RES ERJ3GEYJ 471 V (470)
R3618 7030003340 S.RES ERJ3GEYJ 151 V (150)
R3619 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R3620 7030003360 S.RES ERJ3GEYJ 221 V (220)
R3651 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R3701 7030003360 S.RES ERJ3GEYJ 221 V (220)
R3702 7030003430 S.RES ERJ3GEYJ 821 V (820)
R3703 7030004030 S.RES ERJ3GEYJ 5R6 V (5.6)
R3704 7030003430 S.RES ERJ3GEYJ 821 V (820)
R3705 7030003370 S.RES ERJ3GEYJ 271 V (270)
R3706 7030003400 S.RES ERJ3GEYJ 471 V (470)
R3707 7030003430 S.RES ERJ3GEYJ 821 V (820)
R3708 7030004030 S.RES ERJ3GEYJ 5R6 V (5.6)
R3709 7030003430 S.RES ERJ3GEYJ 821 V (820)
R3710 7030003230 S.RES ERJ3GEYJ 180 V (18)
R3711 7030003370 S.RES ERJ3GEYJ 271 V (270)
R3715 7030003370 S.RES ERJ3GEYJ 271 V (270)
R3716 7030003230 S.RES ERJ3GEYJ 180 V (18)
R3717 7030003370 S.RES ERJ3GEYJ 271 V (270)
R3718 7030003200 S.RES ERJ3GEYJ 100 V (10)
R4001 7030003320 S.RES ERJ3GEYJ 101 V (100)
R4002 7030003320 S.RES ERJ3GEYJ 101 V (100)
R4003 7030003490 S.RES ERJ3GEYJ 272 V (2.7K)
R4004 7030003490 S.RES ERJ3GEYJ 272 V (2.7K)
R4005 7030003320 S.RES ERJ3GEYJ 101 V (100)
R4006 7030003320 S.RES ERJ3GEYJ 101 V (100)
R4007 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R4008 7030006601 S.RES ERA3YED 272V (2.7K)
R4009 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R4010 7030006601 S.RES ERA3YED 272V (2.7K)
R4011 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R4012 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R4013 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R4014 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R4015 7030003540 S.RES ERJ3GEYJ 682 V (6.8K)
R4016 7030003320 S.RES ERJ3GEYJ 101 V (100)
R4017 7030003320 S.RES ERJ3GEYJ 101 V (100)
R4018 7030003690 S.RES ERJ3GEYJ 124 V (120K)
R4019 7030003380 S.RES ERJ3GEYJ 331 V (330)
R4020 7410001090 S.ARR EXB-V8V 101JV
R4021 7030003320 S.RES ERJ3GEYJ 101 V (100)
R4022 7030003560 S.RES ERJ3GEYJ 103 V (10K)
[MAIN UNIT]
H/V REF PARTS
M.
LOCATION NO. NO.
B 132.7/39.3 R4101 7030003440 S.RES ERJ3GEYJ 102 V (1K)
B 125.4/35.8 R4102 7030003620 S.RES ERJ3GEYJ 333 V (33K)
B 125.4/25.6 R4103 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 122.6/25.6 R4104 7030003460 S.RES ERJ3GEYJ 152 V (1.5K)
B 123.2/37.3 R4105 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 124.6/30.7 R4106 7030003620 S.RES ERJ3GEYJ 333 V (33K)
B 119.2/25.6 R4107 7030003440 S.RES ERJ3GEYJ 102 V (1K)
B 120.1/36.6 R4108 7030003680 S.RES ERJ3GEYJ 104 V (100K)
B 116.7/33.8 R4109 7030003380 S.RES ERJ3GEYJ 331 V (330)
T 121.7/38.8 R4201 7030003320 S.RES ERJ3GEYJ 101 V (100)
T 123.5/36.9 R4202 7030003320 S.RES ERJ3GEYJ 101 V (100)
T 106/41.6 R4203 7030003400 S.RES ERJ3GEYJ 471 V (470)
T 104.7/41.6 R4204 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 94.1/33.3 R4205 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
B 95.6/34.6 R4206 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 97.7/38.2 R4207 7030003440 S.RES ERJ3GEYJ 102 V (1K)
B 104.4/38.5 R4208 7030006601 S.RES ERA3YED 272V (2.7K)
B 109.2/36.9 R4209 7030003860 S.RES ERJ3GE JPW V
T 107.3/41.6 R4210 7030006601 S.RES ERA3YED 272V (2.7K)
T 108.6/41.6 R4211 7030006601 S.RES ERA3YED 272V (2.7K)
T 102.2/34.2 R4212 7030006601 S.RES ERA3YED 272V (2.7K)
T 105.8/34.3 R4213 7030005321 S.RES ERA3YED 103V (10K)
T 110.7/48.5 R4214 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 114.2/48.4 R4215 7030005321 S.RES ERA3YED 103V (10K)
B 109.4/55.5 R4216 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 108.6/52.4 R4217 7030005321 S.RES ERA3YED 103V (10K)
T 111.8/56.3 R4218 7030003320 S.RES ERJ3GEYJ 101 V (100)
T 111.8/55 R4219 7030005321 S.RES ERA3YED 103V (10K)
T 111.8/53.7 R4220 7030009591 S.RES ERA3YED 472V (4.7K)
T 108.6/53.7 R4221 7030009591 S.RES ERA3YED 472V (4.7K)
T 111.8/57.6 R4222 7030009591 S.RES ERA3YED 472V (4.7K)
T 102.6/57.6 R4223 7030009591 S.RES ERA3YED 472V (4.7K)
T 112.6/75.4 R4224 7030009591 S.RES ERA3YED 472V (4.7K)
T 112.6/78.2 R4225 7030009691 S.RES ERA3YED 101V (100)
T 105.4/53.7 R4226 7030009691 S.RES ERA3YED 101V (100)
B 111.7/60.4 R4227 7030009691 S.RES ERA3YED 101V (100)
T 111.8/58.9 R4228 7030009691 S.RES ERA3YED 101V (100)
T 104.1/60.5 R4229 7030003860 S.RES ERJ3GE JPW V
T 107.5/75.4 R4230 7030009591 S.RES ERA3YED 472V (4.7K)
T 102/59.8 R4231 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 111.2/83.8 R4232 7030003680 S.RES ERJ3GEYJ 104 V (100K)
B 114.3/83.8 R4233 7030003570 S.RES ERJ3GEYJ 123 V (12K)
T 114.6/81.1 R4234 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 112.1/82.9 R4235 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 110.6/86.5 R4236 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 110.1/77.2 R4241 7030003450 S.RES ERJ3GEYJ 122 V (1.2K)
B 111.6/65.2 R4242 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
B 112.3/68.4 R4301 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 153.8/71 R4302 7410001090 S.ARR EXB-V8V 101JV
B 166.6/79.7 R4303 7410001090 S.ARR EXB-V8V 101JV
B 152.3/79.9 R4401 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 156.5/79.7 R4402 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 156.4/76 R4403 7030003490 S.RES ERJ3GEYJ 272 V (2.7K)
B 166.2/82.5 R4404 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
B 162.4/81.9 R4405 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 156.9/82.4 R4406 7030009591 S.RES ERA3YED 472V (4.7K)
B 159.1/84.6 R4407 7030009591 S.RES ERA3YED 472V (4.7K)
B 156.8/87.4 R4408 7030009591 S.RES ERA3YED 472V (4.7K)
T 161.7/89.3 R4409 7030005341 S.RES ERA3YED 332V (3.3K)
T 164.4/82.8 R4410 7030005341 S.RES ERA3YED 332V (3.3K)
B 163.1/84.3 R4411 7030005341 S.RES ERA3YED 332V (3.3K)
T 163/84.6 R4412 7030003680 S.RES ERJ3GEYJ 104 V (100K)
T 165/88.5 R4413 7030009591 S.RES ERA3YED 472V (4.7K)
T 165.6/84.6 R4414 7030009961 S.RES ERA3YED 221V (220)
T 165/89.8 R4415 7030009961 S.RES ERA3YED 221V (220)
B 157.4/96.8 R4416 7030005341 S.RES ERA3YED 332V (3.3K)
T 167.4/77.8 R4417 7030009861 S.RES ERA3YED 471V (470)
B 150.5/91.1 R4418 7030009861 S.RES ERA3YED 471V (470)
B 124.8/86 R4419 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 126.4/88 R4420 7030003460 S.RES ERJ3GEYJ 152 V (1.5K)
B 125.7/90.4 R4421 7030003650 S.RES ERJ3GEYJ 563 V (56K)
B 132.2/90.3 R4422 7030003470 S.RES ERJ3GEYJ 182 V (1.8K)
B 152.4/95.5 R4423 7030003500 S.RES ERJ3GEYJ 332 V (3.3K)
B 144/92.7 R4424 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
B 145.5/90.4 R4425 7030003860 S.RES ERJ3GE JPW V
B 146.9/92.7 R4426 7030003340 S.RES ERJ3GEYJ 151 V (150)
B 135/89.6 R4428 7030003380 S.RES ERJ3GEYJ 331 V (330)
B 137.4/90.3 R4430 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 138.6/100.1 R4501 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 140.7/101.8 R4502 7030003200 S.RES ERJ3GEYJ 100 V (10)
B 141/99.8 R4503 7030003320 S.RES ERJ3GEYJ 101 V (100)
T 141.4/99 R4504 7030003320 S.RES ERJ3GEYJ 101 V (100)
B 83.6/24.4 R4505 7030003680 S.RES ERJ3GEYJ 104 V (100K)
B 75.2/18.5 R4506 7030003320 S.RES ERJ3GEYJ 101 V (100)
T 82.7/13.2 R4507 7030003320 S.RES ERJ3GEYJ 101 V (100)
T 79.2/17.7 R5001 7410000720 S.ARR EXB-V8V 473JV (47K)
B 77.3/6.8 R5002 7410000720 S.ARR EXB-V8V 473JV (47K)
B 83.5/14.3 R5003 7030003860 S.RES ERJ3GE JPW V
T 81.9/22.5 R5005 7030003860 S.RES ERJ3GE JPW V
T 77.8/12.4 R5006 7410000720 S.ARR EXB-V8V 473JV (47K)
T 77.8/9.4 R5007 7030003860 S.RES ERJ3GE JPW V
T 79.2/15.2 R5008 7410000720 S.ARR EXB-V8V 473JV (47K)
T 77.8/10.7 R5009 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 73.9/12.4 R5010 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 76.6/15.2 R5011 7030003720 S.RES ERJ3GEYJ 224 V (220K)
T 78.4/24.4 R5012 7030003860 S.RES ERJ3GE JPW V
T 81.9/25.1 R5013 7030003860 S.RES ERJ3GE JPW V
T 73.9/10.9 R5101 7410000720 S.ARR EXB-V8V 473JV (47K)
T 74.6/14.5 R5102 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 76.3/22.4 R5103 7410000720 S.ARR EXB-V8V 473JV (47K)
T 74.8/22.4 R5104 7410000720 S.ARR EXB-V8V 473JV (47K)
T 59/17.8 R5105 7410000720 S.ARR EXB-V8V 473JV (47K)
B 97/54.8 R5401 7410001100 S.ARR EXB-V8V 472JV (4.7K)
B 97/56.4 R5402 7410001100 S.ARR EXB-V8V 472JV (4.7K)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5 - 9
DESCRIPTION M.
LOCATION
T 78.2/67.6
T 93.3/69.2
B 97.5/73.3
B 84.3/80.1
B 97.5/71.7
B 84.5/68.8
B 84.5/66.2
B 84.5/70.4
B 97.8/64.6
B 75.2/57.3
B 83.8/54.6
T 95.2/65.8
B 76.7/40.4
T 93.9/63.2
B 82.6/39.3
T 91.9/63.2
B 71/51.9
B 71.4/54.4
T 82.6/52.8
B 73/51.1
T 81.2/52.8
T 74.5/45.6
B 65.4/49.4
T 67.3/45.6
B 97/61.2
T 78.2/44.7
T 76/50.8
T 81.1/44.7
B 62.5/41.7
T 73.9/43.5
T 70.2/45.7
T 78.2/41.9
T 81.1/41.9
T 71.7/45.7
T 68.7/43.5
T 76.1/41.9
T 79.5/41.9
B 73/54.4
B 65.3/41.7
T 84.1/72.5
T 80.7/71.8
T 78.8/72.7
B 84.5/72
B 81.2/79.5
B 80.4/66.3
B 71.1/72.4
T 71.9/76.1
T 60.1/36.3
T 60.2/39
T 72.2/62.9
B 83.5/29.7
B 83/36.6
T 94.5/59.7
T 91.9/59.7
B 85.4/56.9
T 74.7/28.4
T 74.7/29.7
T 74.7/31.1
T 76.5/35.4
T 76.5/36.8
T 79.3/38.1
T 90/60.4
T 79/26.7
T 79/27.9
T 77.5/31.1
T 79.3/35.4
T 76.5/34
T 76.5/38.1
T 81.6/60.8
T 84.5/56.6
B 84.4/63.2
T 85.8/59.3
T 89.7/57.1
T 87.7/56.6
T 82.4/29.9
T 87.8/63.8
T 89.7/55.8
B 97/59.6
B 62.8/88.5
T 67.3/83.6
B 69.8/84.4
B 70.4/87.1
T 67.3/88.7
T 69.3/91.3
T 66.4/90.5
T 27.7/13.3
T 25.4/9.1
B 46.7/33.3
B 55.6/30.2
T 54.1/10.8
B 55.7/32.4
T 18.6/9.1
T 14.7/9.2
T 62/13.1
B 51.1/26
B 54.7/28.7
T 50.7/10.3
T 28.2/48.6
T 24.2/48.6
T 37/52.7
T 37.1/48.5
T 32.7/44.6
T 14.4/37.1
T 42.9/84.7
S.=Surface mount
H/V
