Icom IC-7600 Service Manual page 44

[LOGIC UNIT]
REF PARTS
DESCRIPTION
NO. NO.
R135 7030003200 S.RES ERJ3GEYJ 100 V (10)
R136 7030003200 S.RES ERJ3GEYJ 100 V (10)
R139 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R140 7410000990 S.ARR EXB-V8V 470JV (47)
R141 7410000990 S.ARR EXB-V8V 470JV (47)
R142 7410000990 S.ARR EXB-V8V 470JV (47)
R143 7410000990 S.ARR EXB-V8V 470JV (47)
R144 7410000990 S.ARR EXB-V8V 470JV (47)
R145 7410000990 S.ARR EXB-V8V 470JV (47)
R146 7030003280 S.RES ERJ3GEYJ 470 V (47)
R147 7030003280 S.RES ERJ3GEYJ 470 V (47)
R148 7410000990 S.ARR EXB-V8V 470JV (47)
R149 7410000990 S.ARR EXB-V8V 470JV (47)
R150 7410000990 S.ARR EXB-V8V 470JV (47)
R151 7410000990 S.ARR EXB-V8V 470JV (47)
R152 7410000990 S.ARR EXB-V8V 470JV (47)
R153 7030003200 S.RES ERJ3GEYJ 100 V (10)
R154 7410000990 S.ARR EXB-V8V 470JV (47)
R155 7410000990 S.ARR EXB-V8V 470JV (47)
R156 7410000990 S.ARR EXB-V8V 470JV (47)
R157 7410000800 S.ARR EXB-V8V 103JV (10K)
R158 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R159 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R161 7030003300 S.RES ERJ3GEYJ 680 V (68)
R164 7030003280 S.RES ERJ3GEYJ 470 V (47)
R171 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R172 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R173 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R174 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R175 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R176 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R177 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R178 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R179 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R180 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R181 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R182 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R183 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R184 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R185 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R186 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R187 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R188 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R189 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R190 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R191 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R201 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R202 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R203 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R204 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R205 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R206 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R207 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R208 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R209 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R210 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R211 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R212 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R213 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R218 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R219 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R220 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R221 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R225 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R226 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R227 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R228 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R229 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R230 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R231 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R232 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R233 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R234 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R235 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R236 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R237 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R238 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R239 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R240 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R241 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R242 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R243 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R244 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R245 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R246 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R247 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R248 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R249 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R250 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R251 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R252 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R253 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R254 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R255 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R256 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R257 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R258 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R259 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R260 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R261 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R262 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R263 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R264 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R265 7030003560 S.RES ERJ3GEYJ 103 V (10K)
[LOGIC UNIT]
H/V REF PARTS
M.
LOCATION NO. NO.
T 78.8/19 R266 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 84/19 R267 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 60/47.4 R268 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 66.2/47.5 R269 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 62.5/47.5 R270 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 73.6/47.5 R271 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 81/47.5 R272 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 69.9/47.5 R273 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 77.3/47.5 R274 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 87.2/47.4 R275 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 88.5/47.4 R276 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 84.7/47.5 R277 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 87.6/19.5 R278 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 87.6/23.2 R279 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 87.6/26.9 R280 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 87.6/30.6 R281 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 83.1/32.7 R282 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 83.2/35.2 R283 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 83.2/38.9 R284 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 83.2/42.6 R285 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 115.8/29.9 R286 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 115.9/38.6 R287 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 115.9/32.4 R288 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 101.2/14.4 R289 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 94.3/17 R290 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 56.6/25.6 R291 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 56.6/26.8 R292 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 56.6/28 R293 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 56.6/31.6 R294 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 56.6/29.2 R295 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 53.6/32.8 R296 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 56.6/32.8 R297 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 56.6/30.4 R298 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 53.6/34 R299 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 56.6/34 R300 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 53.6/35.2 R301 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 56.6/31.6 R302 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 56.6/36.4 R303 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 56.6/34 R304 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 56.6/35.2 R305 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 56.6/35.2 R306 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 56.6/32.8 R307 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 56.6/36.4 R308 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 53.6/42.6 R309 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 56.6/42.6 R310 7030003860 S.RES ERJ3GE JPW V
T 56.6/43.8 R311 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 23.3/71.5 R312 7030003860 S.RES ERJ3GE JPW V
T 23.3/72.7 R315 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 32.9/63.3 R316 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 31.7/63.3 R317 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 30.5/63.3 R318 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 26.5/73.9 R319 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 29.3/63.3 R320 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 34.1/63.3 R322 7030003250 S.RES ERJ3GEYJ 270 V (27)
B 28.1/66.3 R323 7030003250 S.RES ERJ3GEYJ 270 V (27)
T 54.9/73.4 R324 7030003580 S.RES ERJ3GEYJ 153 V (15K)
T 54.9/75.8 R325 7030003580 S.RES ERJ3GEYJ 153 V (15K)
T 54.9/74.6 R330 7030003560 S.RES ERJ3GEYJ 103 V (10K)
T 57.9/78.2 R331 7030003560 S.RES ERJ3GEYJ 103 V (10K)
B 30.3/95.7 R332 7030003640 S.RES ERJ3GEYJ 473 V (47K)
B 47.3/75.7 R333 7030003640 S.RES ERJ3GEYJ 473 V (47K)
B 44/84.5 R334 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 54.9/82.9 R335 7030003280 S.RES ERJ3GEYJ 470 V (47)
B 44/79.3 R336 7030003640 S.RES ERJ3GEYJ 473 V (47K)
B 44/78 R337 7030003640 S.RES ERJ3GEYJ 473 V (47K)
B 48.4/65.6 R338 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 48.4/62.6 R339 7030003280 S.RES ERJ3GEYJ 470 V (47)
T 49.6/65.6 R340 7030003280 S.RES ERJ3GEYJ 470 V (47)
T 47.2/62.6 R341 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 48.4/65.6 R344 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
B 44.7/75.7 R347 7030003860 S.RES ERJ3GE JPW V
B 47.2/65.6 R348 7030003860 S.RES ERJ3GE JPW V
T 47.2/65.6 R350 7030003860 S.RES ERJ3GE JPW V
T 46/62.6 R351 7030003860 S.RES ERJ3GE JPW V
B 46/65.6 R361 7030003580 S.RES ERJ3GEYJ 153 V (15K)
B 43.4/75.7 R362 7030003580 S.RES ERJ3GEYJ 153 V (15K)
T 46/65.6 R601 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 44.8/62.6 R602 7030003640 S.RES ERJ3GEYJ 473 V (47K)
B 44.8/65.6 R606 7030003640 S.RES ERJ3GEYJ 473 V (47K)
B 42.1/75.7 R607 7030003350 S.RES ERJ3GEYJ 181 V (180)
T 44.8/65.6 R608 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
B 40.8/75.7 R609 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 51.4/95.7 R610 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 57.4/95.7 R611 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 58.6/98.7 R612 7030003440 S.RES ERJ3GEYJ 102 V (1K)
B 41.4/84.5 R613 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 56.2/95.7 R614 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 61/95.7 R615 7030003440 S.RES ERJ3GEYJ 102 V (1K)
T 59.8/95.7 R618 7030003800 S.RES ERJ3GEYJ 105 V (1M)
T 57.4/98.7 R619 7030003800 S.RES ERJ3GEYJ 105 V (1M)
T 59.8/98.7 R620 7030003800 S.RES ERJ3GEYJ 105 V (1M)
B 47.6/95.7 R621 7030003800 S.RES ERJ3GEYJ 105 V (1M)
T 58.6/95.7 R622 7030003800 S.RES ERJ3GEYJ 105 V (1M)
T 61/98.7 R623 7030003800 S.RES ERJ3GEYJ 105 V (1M)
B 41.4/81.9 R624 7030003800 S.RES ERJ3GEYJ 105 V (1M)
T 55/95.7 R626 7030003600 S.RES ERJ3GEYJ 223 V (22K)
B 41.4/80.6 R627 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 55/98.7 R628 7030003640 S.RES ERJ3GEYJ 473 V (47K)
B 41.4/79.3 R629 7030003640 S.RES ERJ3GEYJ 473 V (47K)
T 52.6/98.7 R630 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
B 41.4/78 R631 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
B 43.5/95.7 R632 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
B 41.4/86.4 R633 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
T 51.4/98.7 R634 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5 - 2
DESCRIPTION M.
LOCATION
T 53.8/98.7
T 52.6/95.7
B 44.7/95.7
T 53.8/95.7
T 56.2/98.7
B 46.4/95.7
B 32.7/95.7
T 27.7/98.7
B 38.2/78
B 33.9/95.7
T 27.7/95.7
B 35.3/95.7
T 28.9/98.7
B 38.2/79.3
B 31.5/95.7
B 37.5/83.8
B 38.8/83.8
T 32.5/98.7
T 32.5/95.7
B 38.2/80.6
T 30.1/98.7
T 30.1/95.7
T 31.3/98.7
T 31.3/95.7
B 38.2/81.9
T 28.9/95.7
B 44/83.2
B 44/81.9
B 44/80.6
B 41.4/83.2
T 26.5/70.3
T 26.5/66.7
B 34.1/66.3
T 26.5/67.9
T 23.3/66.7
B 32.9/66.3
T 23.3/65.5
B 31.7/66.3
T 23.3/67.9
T 26.5/69.1
T 26.5/72.7
T 23.3/70.3
B 30.5/66.3
T 23.3/69.1
T 54.9/77
B 36.5/95.7
T 57.9/77
T 26.5/65.5
T 26.5/64.3
T 23.3/64.3
B 38.9/95.7
B 37.7/95.7
T 26.5/95.7
T 44.9/99.3
T 48.3/99.3
T 46.1/99.3
T 49.5/99.3
T 66.4/100.2
T 65.1/100.2
B 87.3/5.4
B 94.2/8
T 90.9/8
B 87.3/9.5
B 73.2/5.4
B 80.1/8
T 76.8/8
B 73.2/9.5
B 62.5/9.5
B 67.9/11.3
B 68.7/2.1
B 42.3/95.7
B 41/95.7
B 29.1/95.7
T 26.5/71.5
T 42.4/96.6
T 43.7/96.6
B 149.4/82.4
B 150.6/82.4
B 126.6/64.6
B 126.6/65.8
B 126.5/62.2
T 132.6/83.1
T 133.8/83.1
T 135/83.1
T 136.2/83.1
T 137.4/83.1
T 138.6/83.1
T 139.8/83.1
T 139.8/86
T 138.6/86
T 137.4/86
T 136.2/86
T 135/86
T 133.8/86
T 132.6/86
B 148.2/82.4
B 153/82.4
B 151.8/82.4
B 154.2/82.4
T 116.1/52.4
T 116.1/51.2
T 116.1/50
T 116.1/48.8
T 116.1/47.6
S.=Surface mount
H/V
