Icom IC-7600 Service Manual page 158

Apr. 2009
[RF UNIT]
REF PARTS
DESCRIPTION
NO. NO.
C1242 4030011600 S.CER C1608 JB 1E 104K-T
C1243 4030009920 S.CER C1608 CH 1H 050B-T
C1245 4030017810 S.CER C1608 CH 1H 102J-T
C1246 4030007010 S.CER C1608 CH 1H 100D-T
C1247 4550007650 S.TAN F931V105MAABMA
C1301 4030006900 S.CER C1608 JB 1H 103K-T
C1302 4030006900 S.CER C1608 JB 1H 103K-T
C1303 4030006900 S.CER C1608 JB 1H 103K-T
C1304 4030007040 S.CER C1608 CH 1H 180J-T
C1305 4030006980 S.CER C1608 CH 1H 070D-T
C1306 4030008560 S.CER C1608 CH 1H 300J-T
C1307 4030007020 S.CER C1608 CH 1H 120J-T
C1308 4030007060 S.CER C1608 CH 1H 270J-T
C1310 4030006900 S.CER C1608 JB 1H 103K-T
C1311 4030011600 S.CER C1608 JB 1E 104K-T
C1313 4030006900 S.CER C1608 JB 1H 103K-T
C1314 4030006900 S.CER C1608 JB 1H 103K-T
C1400 4030011600 S.CER C1608 JB 1E 104K-T
C1401 4030011600 S.CER C1608 JB 1E 104K-T
C1402 4030011600 S.CER C1608 JB 1E 104K-T
C1403 4030011600 S.CER C1608 JB 1E 104K-T
C1404 4030011600 S.CER C1608 JB 1E 104K-T
C1405 4030007120 S.CER C1608 CH 1H 820J-T
C1406 4030007040 S.CER C1608 CH 1H 180J-T
C1407 4030007130 S.CER C1608 CH 1H 101J-T
C1408 4030007110 S.CER C1608 CH 1H 680J-T
C1409 4030007100 S.CER C1608 CH 1H 560J-T
C1452 4030009920 S.CER C1608 CH 1H 050B-T
C1453 4030011600 S.CER C1608 JB 1E 104K-T
C1454 4030011600 S.CER C1608 JB 1E 104K-T
C1501 4030006900 S.CER C1608 JB 1H 103K-T
C1502 4030006900 S.CER C1608 JB 1H 103K-T
C1550 4030017810 S.CER C1608 CH 1H 102J-T
C1551 4030007100 S.CER C1608 CH 1H 560J-T
C1552 4030006980 S.CER C1608 CH 1H 070D-T
C1553 4030007100 S.CER C1608 CH 1H 560J-T
C1556 4030006900 S.CER C1608 JB 1H 103K-T
C1557 4030007010 S.CER C1608 CH 1H 100D-T
C1558 4030011600 S.CER C1608 JB 1E 104K-T
C1559 4030006970 S.CER C1608 CH 1H 060D-T
C1560 4030017810 S.CER C1608 CH 1H 102J-T
C1561 4030017810 S.CER C1608 CH 1H 102J-T
C1563 4030017810 S.CER C1608 CH 1H 102J-T
C1601 4030007170 S.CER C1608 CH 1H 221J-T
C1603 4030006900 S.CER C1608 JB 1H 103K-T
C1604 4030006900 S.CER C1608 JB 1H 103K-T
C1651 4030009920 S.CER C1608 CH 1H 050B-T
C1701 4030006900 S.CER C1608 JB 1H 103K-T
C1704 4030006900 S.CER C1608 JB 1H 103K-T
C1705 4030006900 S.CER C1608 JB 1H 103K-T
C1706 4030006900 S.CER C1608 JB 1H 103K-T
C1707 4030006900 S.CER C1608 JB 1H 103K-T
C1708 4030006900 S.CER C1608 JB 1H 103K-T
C1709 4030006900 S.CER C1608 JB 1H 103K-T
C1710 4030006900 S.CER C1608 JB 1H 103K-T
C1901 4030011600 S.CER C1608 JB 1E 104K-T
C2001 4030006900 S.CER C1608 JB 1H 103K-T
C2002 4030011600 S.CER C1608 JB 1E 104K-T
C2003 4030006900 S.CER C1608 JB 1H 103K-T
C9001 4030006900 S.CER C1608 JB 1H 103K-T
C9002 4030006900 S.CER C1608 JB 1H 103K-T
C9007 4030006900 S.CER C1608 JB 1H 103K-T
C9008 4030006900 S.CER C1608 JB 1H 103K-T
C9011 4030006900 S.CER C1608 JB 1H 103K-T
C9012 4030006900 S.CER C1608 JB 1H 103K-T
C9015 4030006900 S.CER C1608 JB 1H 103K-T
C9016 4030006900 S.CER C1608 JB 1H 103K-T
C9018 4030006900 S.CER C1608 JB 1H 103K-T
C9020 4030006900 S.CER C1608 JB 1H 103K-T
C9021 4030006900 S.CER C1608 JB 1H 103K-T
C9024 4030006900 S.CER C1608 JB 1H 103K-T
C9026 4030006900 S.CER C1608 JB 1H 103K-T
C9027 4030006900 S.CER C1608 JB 1H 103K-T
C9031 4030006900 S.CER C1608 JB 1H 103K-T
C9035 4030006900 S.CER C1608 JB 1H 103K-T
C9036 4030006900 S.CER C1608 JB 1H 103K-T
C9061 4030006900 S.CER C1608 JB 1H 103K-T
C9062 4030006900 S.CER C1608 JB 1H 103K-T
C9065 4030006900 S.CER C1608 JB 1H 103K-T
C9066 4030006900 S.CER C1608 JB 1H 103K-T
C9071 4030006900 S.CER C1608 JB 1H 103K-T
C9072 4030006900 S.CER C1608 JB 1H 103K-T
C9075 4030006900 S.CER C1608 JB 1H 103K-T
C9076 4030006900 S.CER C1608 JB 1H 103K-T
C9081 4030006900 S.CER C1608 JB 1H 103K-T
C9082 4030006900 S.CER C1608 JB 1H 103K-T
C9085 4030006900 S.CER C1608 JB 1H 103K-T
C9086 4030006900 S.CER C1608 JB 1H 103K-T
RL101 6330001860 REL UA2-12NU
RL102 6330001860 REL UA2-12NU
RL103 6330001860 REL UA2-12NU
RL104 6330001860 REL UA2-12NU
RL105 6330001860 REL UA2-12NU
RL161 6330000540 REL 2-1419131-2(OMR-109F)
J101 6510007020 CON TMP-J01X-V6
J102 6450001130 CON JPJ2042-01-110
J103 6450001800 CON JPJ1044-01-010
J161 6450001130 CON JPJ2042-01-110
J201 6510007020 CON TMP-J01X-V6
J451 6510022581 S.CON 24FMN-BMTTR-A-TBT(LF)(SN)
[RF UNIT]
H/V REF PARTS
M.
LOCATION NO. NO.
B 93/55.8 J801 6910016430 CON
T 112.1/44 J802 6910016430 CON
B 106/61.5 J803 6910016430 CON
T 99.1/58.2 J804 6910016430 CON
B 106.9/53.5 J805 6910016430 CON
T 96.7/57.5 J807 6910016430 CON
B 102.9/61.2 J809 6910016430 CON
T 96.4/64.1 J951 6510007020 CON
T 92.8/59.7 J1101 6510007020 CON
T 91.8/62 J1301 6510007020 CON
T 91/58.6 J1651 6510007020 CON
T 89.1/59 J1701 6510007020 CON
T 91/59.8 J1702 6910004741 CON
T 82.2/60.8 J1703 6910004741 CON
T 77/58.5 J1704 6910004741 CON
T 79.9/64.3 J1705 6910004741 CON
B 70.1/61.2 J1706 6910004741 CON
T 49.5/46.2 J1707 6910004741 CON
T 54.5/38.1 J1708 6910004741 CON
T 50.7/37.6 J1709 6910004741 CON
T 52.9/41.9 J2001 6510007020 CON
T 54.8/42.4
T 54/44.3
T 51.4/48.6 EP451 6910015970 S.BEA
T 54/48.6 EP452 6910015970 S.BEA
T 53.6/50.5 EP453 6910015970 S.BEA
T 54.1/52.4 EP454 6910015970 S.BEA
T 82.6/71 EP455 6910015970 S.BEA
B 86/72 EP456 6910015970 S.BEA
B 91.1/68.2 EP457 6910015970 S.BEA
T 98.4/68.6 EP458 6910015970 S.BEA
T 99.7/71.3 EP459 6910015970 S.BEA
B 125.1/64.3 EP460 6910019900 S.BEA
B 96.3/70.1 EP461 6910019900 S.BEA
B 98.7/70.9 EP462 6910019900 S.BEA
B 101.1/71 EP463 6910019900 S.BEA
B 116.6/66.7 EP464 6910019900 S.BEA
B 117.1/69.9 EP465 6910019900 S.BEA
B 119.2/67.4 EP466 6910019900 S.BEA
B 124/66.7 EP467 6910019900 S.BEA
B 125.9/66.7 EP1001 6910015970 S.BEA
B 129.1/68.7 EP1009 6910019900 S.BEA
B 124.9/58.9 EP1201 6910015970 S.BEA
T 130.3/33.1 EP1406 6910015970 S.BEA
T 127.4/32.7 EP1551 6910015970 S.BEA
T 128.2/30.7 EP1701 6910015970 S.BEA
B 125.8/25.4 EP1702 6910015970 S.BEA
B 128.3/30.2 EP1703 6910015970 S.BEA
B 149.7/84.4 EP1901 6910015970 S.BEA
B 159/43.2
B 127.6/35.4
T 140.2/36.7 MP1 8930065741 SPR
B 138.1/71.3 MP2 8930065741 SPR
B 130.6/71 MP3 8930065741 SPR
B 147.2/73.1
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
T 128.2/29.5
T 104.5/71.4
T 103/77.1
T 109.7/77
T 4.6/59.4
T 7.4/59.4
T 42/38.9
T 42/36.1
T 26/82.4
T 26/79.6
T 54.6/67.5
T 57.4/67.5
T 20.6/17.5
T 23.4/17.5
T 49.4/17.5
T 46.6/17.5
T 44.1/42.9
T 44.1/40.1
T 154.9/54.3
T 142.9/62.7
T 146.3/62.7
T 150.6/77.8
T 149/74.4
T 148.9/42.2
T 150.6/38.8
T 137.9/77.8
T 137.9/74.4
T 137.9/42.2
T 136.1/38.8
T 125.2/77.8
T 125.2/74.4
T 125.2/42.2
T 125.2/38.8
T 151.7/24.3
23
DESCRIPTION M.
IMSA-9210B-1-05Z869-PT1
IMSA-9210B-1-05Z869-PT1
IMSA-9210B-1-05Z869-PT1
IMSA-9210B-1-05Z869-PT1
IMSA-9210B-1-05Z869-PT1
IMSA-9210B-1-05Z869-PT1
IMSA-9210B-1-05Z869-PT1
TMP-J01X-V6
TMP-J01X-V6
TMP-J01X-V6
TMP-J01X-V6
TMP-J01X-V6
IMSA-9202B-1-03Z041-PT1
IMSA-9202B-1-03Z041-PT1
IMSA-9202B-1-03Z041-PT1
IMSA-9202B-1-03Z041-PT1
IMSA-9202B-1-03Z041-PT1
IMSA-9202B-1-03Z041-PT1
IMSA-9202B-1-03Z041-PT1
IMSA-9202B-1-03Z041-PT1
TMP-J01X-V6
MMZ1608B 301CT-AS T
MMZ1608B 301CT-AS T
MMZ1608B 301CT-AS T
MMZ1608B 301CT-AS T
MMZ1608B 301CT-AS T
MMZ1608B 301CT-AS T
MMZ1608B 301CT-AS T
MMZ1608B 301CT-AS T
MMZ1608B 301CT-AS T
MPZ1608S601AT T
MPZ1608S601AT T
MPZ1608S601AT T
MPZ1608S601AT T
MPZ1608S601AT T
MPZ1608S601AT T
MPZ1608S601AT T
MPZ1608S601AT T
MMZ1608B 301CT-AS B
MPZ1608S601AT T
MMZ1608B 301CT-AS B
MMZ1608B 301CT-AS T
MMZ1608B 301CT-AS B
MMZ1608B 301CT-AS B
MMZ1608B 301CT-AS B
MMZ1608B 301CT-AS T
MMZ1608B 301CT-AS T
2590 D-EARTH SPRING-1 B
2590 D-EARTH SPRING-1 B
2590 D-EARTH SPRING-1 B
S.=Surface mount
H/V
LOCATION
145.6/35.8
156.3/36.2
145.6/33.8
157.6/32.8
145.6/31.8
157.6/30.8
145.6/29.8
145.6/27.8
157.5/26.8
157.5/24.8
145.6/21.8
145.6/19.8
157.4/18.8
145.6/17.8
35.5/7.5
32.6/4.2
157.5/22.8
112.5/32.4
120.6/9.9
106/63
50.7/44.3
127.5/65.1
158.2/41
129.9/36.2
137.2/35.5
133.6/30
100.3/94.8
68.3/94.8
26.3/94.8
