Bionaire BAP825RC Instruction Leaflet

BAP825RC-LA_07ESM1.qxd 6/13/07 10:56 Page 1
AIR PURIFIER SAFETY
PLEASE READ AND SAVE
THESE IMPORTANT
Air Purifier
SAFEGUARDS
IMPORTANT INSTRUCTIONS
When using electrical appliances, basic safety precautions
BAP825RC
should always be taken including the following:
1. Read all instructions before using appliance.
2. To avoid fire and shock hazard, plug the appliance
directly into an electrical outlet with the same voltage
as that indicated on the rating plate on your product.
3. If the filter is covered by a bag when shipped, remove
plastic bag before use.
4. Keep the cord out of heavy traffic areas. To avoid fire
hazard NEVER put the cord under rugs, near heat
registers, radiators, stoves or heaters.
5. To protect against electrical hazards DO NOT immerse
in water or other liquids. Do not use near water.
6. Close supervision is necessary when any appliance is
used by, or near children or disabled persons. Children
should be supervised to ensure that they do not play
with the appliance.
7. Always unplug the air purifier before moving it, opening
the grill, changing the filters or whenever the air purifier is
not in use. Be sure to pull by the plug and not the cord.
8. NEVER drop or insert any object into any openings.
9. Do not operate any appliance with a damaged cord or
plug, if motor fan fails to rotate, after the appliance
malfunctions, or if it has been dropped or damaged in
any manner. Return appliance to manufacturer for
examination, electrical or mechanical adjustment or repair.
10.Use appliance only for the intended household use as
described in this manual. Any other use not recommended
by the manufacturer may cause fire, electric shock or injury
to persons. The use of attachments not recommended or
sold by the manufacturer may cause hazards.
11.Do not use outdoors.
12.Never block the air openings, or place on soft surface,
such as bed or sofa, as this could cause the unit to
tip over thus blocking the air intake opening.
13.Keep unit from heated surfaces and open flames.
14.DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void
the warranty. The inside of the unit contains no user
Read instructions before operating.
serviceable parts. All servicing should be performed
Retain for future reference.
by qualified personnel only.
Instruction Leaflet
15.WARNING: To reduce the risk of fire or electrical
shock, DO NOT use this air purifier with any solid
state speed control device.
16.DO NOT place anything on top of the unit.
17.The ionizer on the three pronged plug unit may cause
Figure 4 Figure 5
a static charge to build up on the air output grill. A
static-charged electric shock may be felt if the unit is
E
not properly grounded. To avoid a shock, plug the F
K
unit's three-prong plug into a grounded outlet, or
properly install a ground adaptor. (Not apply to 220V
G
products)
18.To reduce the risk of electric shock, some plug
H
versions may have a grounding type plug that has a
third (grounding) pin. This plug will only fit into a
grounding type power outlet. If the plug does not fit
into the outlet, contact qualified personnel to install
the proper outlet. Do not alter the plug in any way.
I
PLEASE SAVE THESE G
J
INSTRUCTIONS
PLEASE READ AND SAVE THESE IMPORTANT
INSTRUCTIONS.
Figure 1
With proper care and use, this Bionaire
give you fresh, clean air for many years.
NOTE: Before reading these instructions, please view the
corresponding illustrations.
DESCRIPTIONS (SEE FIG. 1/4/5)
A
A. Inlet Grill
B. Washable Foam Pre-Filter
C. 99% HEPA-Type/Carbon Filter
D
D. Filtered Air Outlet
E. Filter Indicator Light
F. Ionizer Light
G. Ionizer Control
H. Power Button
I. Speed Control
B
J. Power Indicator Light
K. Infrared
C
L. Operation Indicator Light
HOW THE AIR PURIFIER WORKS
Dirty, dust laden air is drawn through the rear of the air
Figure 2 Figure 3
purifier and through the multi-stage filtration system.
1. The carbon filter will help clear odors making the air
cleaner and fresher.
2. The HEPA-type filter entraps 99% of all smaller visible
and non-visible particles down to 2 microns in size.
PRODUCT FEATURES
Filter Life Indicator
Your air purifier has an indicator light (E) that illuminates
when its time to change the filters.
Ionizer OPERATING INSTRUCTIONS FOR THE CONTROL
PANEL AND REMOTE CONTROL
L
Your Bionaire ® Air Purifier has an independently controlled
1. Plug into electrical outlet with the same voltage as
I ionizer, which when turned on, releases negative ions into
that indicated on the rating plate on your product.
the outgoing filtered air. Ions are tiny particles that carry
either a positive or negative charge. 2. Press the Power button (
H
These ions exist naturally all around us in the air, water
high and the power light (J) will illuminate letting you
and ground. Both positive and negative ions are
know the power is on.
colorless, odorless and completely harmless. Negative
3. You can then select the desired speed setting. This air
ions help the air purification process by attaching
purifier has three speed settings. You can select from
themselves to very small airborne particles in the room.
HIGH (
These particles take on a negative charge and may join
desired operating speed button on the control panel
with positively charged particles, such as dust, pollen,
or the remote control.
smoke and pet dander to form larger particles that are
4. To release negative ions into the filtered air, press the
then more readily captured by the filter system, or they
ionizer button (
may be attracted to positively charged surfaces like walls
or floors. 5. For optimum air filtration, it is recommended to
operate the air purifier continuously. Its rugged motor
You may also note, after extended use, that dust may
has been designed to give many years of use.
have collected around the grills or front panel.
For continuous use, it's recommended to operate the air
This is from the ionization effect caused by the negative
® air purifier will ions exiting from the air outlet.This dust does not come purifier at the MEDIUM setting. For quieter operation or
from the air output, but is drawn out of the uncleaned air use in a bedroom, select the LOW setting. When high
going past the air outlet. levels of air pollution are present, select the HIGH setting
to quickly circulate and filter the room air.
This is additional evidence of the air cleaning
effectiveness of negative ions. The dust can be easily
REMOTE CONTROL
removed with a clean, dampened cloth or soft brush.
Your remote control requires (2) AAA batteries for
NOTE: it is important to change the HEPA-type filter at
operation. To install the batteries, simply depress and
recommended intervals. Using the ionizer in conjunction
slide the back of the remote control with your thumb on
with dirty filters may result in dirty particles exiting the air
the arrow indentation. Insert batteries according to the
purifier and being attracted to walls, carpets, furniture
diagram shown inside and replace cover.
and other household objects. These dirty particles may
prove very difficult to remove. • DO NOT mix old and new batteries.
• DO NOT mix alkaline, standard (carbon-zinc) or
PRE-OPERATING INSTRUCTIONS
rechargeable (nickel-cadmium) batteries.
1. After removing the unit from the box, remove the plastic
covering from the unit.
CLEANING AND MAINTENANCE
2. Select a firm level place where there are no obstructions
1. Turn the air purifier off and unplug it before cleaning.
to the air inlet (rear grill) (A) or filtered air outlet (D).
2. The outside of the air purifier can be cleaned with a
3. Remove the inlet grill by pulling the grill (A) towards you.
soft, clean dampened cloth.
4. Remove both HEPA-type filters (C) by gripping on
3. The filtered air outlet on the top of the unit can be
both sides and pulling forward.
cleaned of dust with a small, soft brush.
5. Remove protective plastic bag from each filter
4. If you wish to clean the inside of the air purifier, please
cartridge. Install the filter clip to the HEPA-type filters.
only use a dry, soft cloth to wipe it down.
The filter clip can only be attached to the hang tabs
on the filter one way (see Fig. 2). The filter clip should
FILTER REPLACEMENT
easily slide onto the filter hang tabs. Do not use force
IMPORTANT: IN ORDER TO RETAIN THE EFFICIENCY
whilst attaching the filter clip to the filter. Align the clip
OF YOUR AIR PURIFIER, THE HEPA-TYPE FILTER
on the HEPA-type filter with the rails on the inside of
NEEDS TO BE CHANGED EVERY 6-9 MONTHS.
the unit (see Fig. 3).
1. Every few weeks check the condition of the pre-filter (B).
NOTE: The pleated material and rubber gasket should
be facing towards the unit when applied. 2. Remove the inlet grill (A). If the foam pre-filter has
6. Replace the inlet grill by sliding back on to the unit. collected a noticeable amount of dust, remove it from
Make sure that it snaps securely into position (the grill the inlet of the grill and wash it in warm soapy water.
only goes on one way).
Rinse and dry the pre-filter thoroughly before replacing
NOTE: Do not point outlet towards wall. it in the inlet of the grill.
3. With the inlet grill (A) removed, remove the HEPA-type
filter (C) and dispose in the dustbin. DO NOT try to
wash and re-use the HEPA-type filter. Replace with a
new HEPA-type filter-BAPF30, removing the protective
plastic bag before inserting into the air purifier.
). The unit will turn onto
4. Install the filter clip to the HEPA-type filters. The filter
clip can only be attached in one direction (see Fig. 2).
The filter clip should easily slide onto the filter hang
tabs. Do not use force while attaching the filter clip to
the filter. Align the clip on the side of your HEPA-type
), MEDIUM ( ), or LOW ( ) by pushing the
filter with the rails on the inside of the unit.
NOTE: The pleated material and rubber gasket should
be facing towards the unit when applied.
5. Align the clips on the side of your HEPA-type filter with
) to ON and the light will illuminate.
the rails on the inside of the unit. Gently slide the filter
onto the rails (see Fig. 3).
6. Replace the inlet grill by sliding back on to the unit.
Make sure that it snaps securely into position (the grill
only goes on one way).
NOTE: Do not point outlet towards wall.
7. The filter life indicator light (E) should be reset once
the HEPA-type filters have been replaced. Reset the
indicator by pressing the Power button ( ) on the
control panel for 2 seconds.
REPLACEMENT FILTERS
BAPF30 HEPA-type Filter (usage 2 pcs)
TROUBLESHOOTING
Problem Solution
Unit will not Check to make sure the unit is
operate plugged in.
Check to make sure the unit is on
by pressing the Power button.
Make sure the filters are properly
installed and firmly close the door.
Decreased air If the filters have not been
flow changed for 6 months or more,
change the HEPA-type filters.
Check to ensure nothing is
blocking the air inlet and filtered
air outlet.
Noisy Ensure all plastic bags have been
removed from the filters.
How To Obtain Warranty Service: Please see the country
specific warranty insert or contact your local authorized
distributor for Bionaire ® appliances.
PLEASE DO NOT RETURN THIS PRODUCT TO THE
PLACE OF PURCHASE
© 2007 Sunbeam Products, Inc. doing business as Jarden
Consumer Solutions. All rights reserved. Distributed by
Sunbeam Latin America, LLC, 5200 Blue Lagoon, Suite
470, Miami, FL 33126.
