(3) Release the six Hooks in the order of 3a to 3f. Then, incline the Top cover ASSY 45° to 90°
to the left hand side and remove it from the Frame unit.
3c
Hooks
8.36 Top Cover Panel ASSY
(1) Disconnect the Flat cable and connector (5pin) from the LCD panel PCB ASSY and the
connector (6pin) from the USB host relay PCB ASSY.
LCD panel PCB ASSY
Hooks
3e
3f
<Left side>
Flat cable
3a
Top cover ASSY
Hooks
3d
Fig. 3-112
Connector (5pin)
Fig. 3-113
3-83
3b
Frame unit
Connector (6pin)
USB host relay PCB ASSY
Top cover panel ASSY
