Before you can use the printer, you must set up the hardware and install the driver. Please
read this 'Quick Setup Guide' for proper set up and installation instructions.
How to use the printer, see the User's Guide in the CD-ROM.
Keep this 'Quick Setup Guide' and the supplied CD-ROM in a convenient place for quick and
easy reference at all times.
Note: Not all models are available in all countries.
STEP 1
Setting Up the Machine
STEP 2
Installing the Printer Driver
Setup is Complete!
Version 1

Advertisement

Table of Contents
loading

Related Manuals for Brother HL-4040CDN

Summary of Contents for Brother HL-4040CDN

  • Page 1 HL-4040CN HL-4040CDN HL-4050CDN Before you can use the printer, you must set up the hardware and install the driver. Please read this ‘Quick Setup Guide’ for proper set up and installation instructions. Setting Up the Machine Installing the Printer Driver Setup is Complete! How to use the printer, see the User’s Guide in the CD-ROM.

  • Page 2: Symbols Used In This Guide

    Network User's Guide Indicates reference to the User's Guide or Network User's Guide which is on the CD-ROM we have supplied. Caution Cautions specify procedures you must follow or avoid to prevent possible damage to the printer or other objects.

  • Page 3: Table Of Contents

    Supplied CD-ROM ... 9 STEP 1— Setting Up the Machine Put the CD-ROM into the CD-ROM drive... 10 Remove the packing materials from the printer ... 11 Installing the toner cartridges ... 12 Load paper in the paper tray ... 12 Print a test page ...

  • Page 4: Safety Precautions

    To Use the Printer Safely Warning There are high voltage electrodes inside the printer. Before you clean the inside of the printer, make sure that you have turned off the power switch and unplugged the printer from the AC power outlet.
  • Page 5 If the printer becomes hot, blows smoke, or generates obscure odor, immediately turn off the power switch and unplug the printer from the AC power outlet. Call your Brother dealer or Brother Customer Service. If metal objects, water or other liquids get inside the printer, immediately turn off the power switch and unplug the printer from the AC power outlet.

  • Page 6: Regulations

    A shielded interface cable should be used in order to ensure compliance with the limits for a Class B digital device. Changes or modifications not expressly approved by Brother Industries, Ltd. could void the user's authority to operate the equipment. Industry Canada Compliance Statement (For Canada This Class B digital apparatus complies with Canadian ICES-003.
  • Page 7 EC Declaration of Conformity Laser Safety (110 to 120 volt Model Only) This printer is certified as a Class 1 laser product as defined in IEC 60825-1+A2: 2001 specifications under the U.S. Department of Health and Human Services (DHHS) Radiation Performance Standard according to the Radiation Control for Health and Safety Act of 1968.
  • Page 8 Der höchste Schalldruckpegel beträgt 70 dB(A) oder weniger gemäß EN ISO 7779. Disconnect device You must install this printer near a power outlet that is easily accessible. In case of an emergency, you must disconnect the power cord from the power outlet to shut off the power completely.

  • Page 9: Getting Started

    What is in the box? Carton components may vary from one country to another. Save all packing materials and the printer carton in case for any reason you must ship your printer. 1 Front cover release button 2 Control panel...

  • Page 10: Control Panel

    Choose a menu (control panel menu, reprint menu or Direct Print menu) or Pause LCD messages The message on the LCD shows the current printer status during normal operation. The o marks indicate the status of the toner in the toner cartridges.When the o mark blinks (n), the indicated toner is...

  • Page 11: Supplied Cd-Rom

    FAQs and troubleshooting tips, or learn about printer solutions. Supplies Information Visit our web site for original/genuine Brother supplies at http://www.brother.com/original/ Note For visually impaired users, we have prepared an HTML file on the supplied CD-ROM: readme.html.

  • Page 12: Step 1 Setting Up The Machine

    Administrator rights.) Put the supplied CD-ROM into your CD-ROM drive. The opening screen will appear automatically. Choose your printer model and the language. Click Initial Setup on the menu screen. You can view the initial setup instructions and follow along with the steps on the next page.

  • Page 13: Remove The Packing Materials From The Printer

    Remove the packing materials from the printer Important Save all packing material and the carton in case you have to ship your machine. Improper Setup DO NOT plug in the AC power cord yet. Press the front cover release button and open the front cover.

  • Page 14: Installing The Toner Cartridges

    Put the drum unit into the printer. Close the front cover of the printer. Load paper in the paper tray Pull the paper tray completely out of the printer. While pressing the green paper-guide release lever (1), slide the paper guides to fit the paper size.

  • Page 15: Print A Test Page

    Put paper in the paper tray. Make sure that the paper is flat in the tray and below the maximum paper mark. Put the paper tray firmly back into the printer. Make sure that it is completely inserted into the printer.

  • Page 16: Setting Your Language On The Control Panel

    Press Go. The printer prints a test page. Check that the test page has printed correctly. Note • If you press Reprint, the printer prints a duplex test page. (For HL-4050CDN) • This function will not be available after the first print job you send from your computer.

  • Page 17: Step 2 Installing The Printer Driver

    Follow the instructions on this page for your operating system and interface cable. For the latest drivers, documentation, and to find the best solution for your problem, access the Brother Solution Center directly from the CD-ROM / Driver or visit http://solutions.brother.com.

  • Page 18: Windows

    For USB interface cable users Note If the Found New Hardware Wizard appears on your computer, click Cancel. Installing the driver and connecting the printer to your computer Make sure the USB interface cable is NOT connected to the printer, and then begin installing the driver.
  • Page 19 Click Next. Click Finish. Note • If you want to register your product on-line, check On-Line Registration. • If you do not want to set your printer as Default printer, uncheck Set as Default Printer. Setup is now complete. ® Windows...

  • Page 20: For Parallel Interface Cable Users (Hl-4050Cdn Users)

    Note • If you want to register your product on-line, check On-Line Registration. • If you do not want to set your printer as Default printer, uncheck Set as Default Printer. Turn off the printer power switch. Connect the parallel interface cable to your computer, and then connect it to your printer.

  • Page 21: For Network Interface Cable Users

    TCP/IP 1 Router 2 Network printer Note • If you are going to connect the printer to your network, we recommend that you contact your system administrator prior to installation or see the Network User’s Guide on the CD-ROM. • Before installation, if you are using Personal Firewall software (e.g.
  • Page 22 Choose your printer, and then click Next. Click Finish. Note • If you want to register your product on-line, check On-Line Registration. • If you do not want to set your printer as Default printer, uncheck Set as Default Printer. Setup is now complete. ® Windows...

  • Page 23: For Shared Network Printer Users

    3 Printer 4 TCP/IP, USB or Parallel Note If you are going to connect to a shared printer on your network, we recommend that you ask your system administrator about the queue or share name for the printer prior to installation.
  • Page 24 Click Finish. Note • If you want to register your product on-line, check On-Line Registration. • If you do not want to set your printer as Default printer, uncheck Set as Default Printer. Setup is now complete. ® Windows...

  • Page 25: Macintosh

    For Mac OS X 10.3 or greater users: Go to step 5. ® The Brother software will search for the Brother printer. During this time the following screen will appear. Note If more than one printer is available, the following list appears.
  • Page 26 STEP 2 Installing the Printer Driver Choose USB. Choose your printer, and then click Add. Click Print Center, then Quit Print Center. ® For Mac OS X 10.2.4 to 10.2.8 users: Setup is now complete. ® Macnintosh...

  • Page 27: For Network Interface Cable Users

    For Mac OS X 10.3 or greater users: Go to step 5. ® The Brother software will search for the Brother printer. During this time the following screen will appear. Note If more than one printer is available, the following list appears.
  • Page 28 Installing the Printer Driver Make the following selection. Choose your printer, and then click Add. Note If there is more than one of the same printer model connected on your network, the Ethernet address (MAC address) will be displayed after the model name.

  • Page 29: For Network Users

    BRAdmin Light utility (For Windows The BRAdmin Light is a utility for initial setup of Brother network connected devices. It can also search for Brother products on your network, view the status and configure basic network settings, such as IP address.

  • Page 30: Bradmin Light Utility (For Mac Os ® X Users)

    BRAdmin Light utility (For Mac OS The BRAdmin Light is a utility for initial setup of Brother network connected devices. It can also search for Brother products on your network, view the status and configure basic network settings, such as IP address from a computer running Mac OS The BRAdmin Light software will be installed automatically when you install the printer driver.

  • Page 31: Web Based Management (Web Browser)

    Web Based Management (web browser) The Brother print server is equipped with a web server that allows you to monitor its status or change some of its configuration settings, using HTTP (Hyper Text Transfer Protocol). Note • The User Name is ‘admin’ and the default password is ‘access’.

  • Page 32: Consumables And Options

    800 sheets. Consumables When the time comes to replace consumable items, an error message will be indicated on the LCD. For more information about the consumables for your printer, visit us at http://solutions.brother.com or contact your local Brother reseller. Toner Cartridge Belt Unit (BU-100CL) See Chapter 6 of the User’s Guide on the CD-ROM.

  • Page 33: Other Information

    Shipment of the printer Caution • Once your printer has been set up and used, we do not recommend that it be moved or shipped unless absolutely necessary. • Color laser printers are complex printing devices. Moving the printer or shipping it without properly removing the installed supplies can result in SEVERE damage to the printer.
  • Page 34 The contents of this manual and the specifications of this product are subject to change without notice. Brother reserves the right to make changes without notice in the specifications and materials contained herein and shall not be responsible for any damages (including consequential) caused by reliance on the materials presented, including but not limited to typographical and other errors relating to the publication.
