- Page 1 ™ Habu 180 DF Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni...
-
Page 2: Safety Precautions And Warnings
NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, Inc. For up-to-date product literature, visit www.horizonhobby.com and click on the support tab for this product. Meaning of Special Language: The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury. -
Page 3: Table Of Contents
EDF sport jet design, you get exhilarating performance, plus handling that’s been custom engineered to meet the specifi c needs of the RC sport pilot. With the UMX Habu 180 DF, you can expect impressive maneuverability and agility at a variety of speeds and the stability to hold almost any attitude. Breakthrough ultra micro electric ducted fan technology features fi... -
Page 4: Prefl Ight Checklist
Prefl ight Checklist 1. Charge fl ight battery. 6. Set dual rates and expos. 2. Install fl ight battery in aircraft (once it 7. Adjust center of gravity. has been fully charged). 8. Perform a radio system Range Check. 3. Bind aircraft to transmitter. 9. -
Page 5: Transmitter And Receiver Binding
Transmitter and Receiver Binding Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identifi er) ™ code of a single specifi c transmitter. You need to ‘bind’ your chosen Spektrum DSM2/DSMX technology equipped aircraft transmitter to the receiver for proper operation. Any full range Spektrum DSM2/DSMX transmitter can bind to the DSM2/DSMX receiver. -
Page 6: Esc/Receiver Arming, Battery Installation And Center Of Gravity
ESC/Receiver Arming, Battery Installation and Center of Gravity NOTICE: Always keep material or debris away from the intake. When armed, the rotor will turn in response to the throttle movement and could ingest in any loose objects. Arming the ESC/receiver also occurs after binding as previously described, but subsequent connection of a fl... -
Page 7: Control Centering
Control Centering Before the fi rst fl ights, or in the event of an accident, make sure the fl ight control surfaces are centered. Adjust the linkages mechanically if the control surfaces are not centered. Use of the transmitter sub-trims may not correctly center the aircraft control surfaces due to the mechanical limits of linear servos. -
Page 8: Dual Rates And Expos
Dual Rates and Expos To obtain the best fl ight performance, we recommend using a DSM2/DSMX radio capable of Dual Rates Expos Dual Rates and Expo. The suggested settings shown High High here are the recommended starting settings. Adjust according to the individual preferences after the Aileron 100% initial fl... -
Page 9: Landing Gear Removal
Landing Gear Removal If desired, remove the landing gear for belly landing the aircraft in a soft landing area. 1. Lift the end of the main gear wire above the stop. 2. Gently pull the main gear away from the fuselage and away from the clips. -
Page 10: Flying Tips And Repairs
Flying Tips and Repairs Range Check your Radio System Landing After fi nal assembly, range check the radio system Always land into the wind. Fly the landing pattern with the aircraft. Refer to your specifi c transmitter with a slightly nose high attitude. Use throttle instruction manual for range test information. -
Page 11: Power Components Service
Power Components Service Disassembly CAUTION: DO NOT handle the rotor or motor while the fl ight battery is connected. Personal injury could result. 1. The canopy hatch is secured to the fuselage using double-sided tape under the outside edge. Carefully remove the canopy hatch; replacing the double-sided tape as needed. -
Page 12: Troubleshooting Guide
Troubleshooting Guide AS3X Problem Possible Cause Solution Control surfaces not at Control surfaces may not have been Center control surfaces mechanically by neutral position when mechanically centered from factory adjusting the U-bends on control linkages transmitter controls are Aircraft was moved after the fl ight battery Disconnect and reconnect the fl... -
Page 13: Troubleshooting Guide (Continued)
Troubleshooting Guide (Continued) Problem Possible Cause Solution LED on receiver fl ashes Less than a 5-second wait between fi rst Leaving transmitter on, disconnect and rapidly and aircraft will powering on transmitter and connecting reconnect fl ight battery to aircraft not respond to transmit- fl... - Page 14 of purchase is required for all warranty claims. until it arrives and is accepted at our facility. An SERVICE OR REPLACEMENT AS PROVIDED UNDER Online Service Request is available at http://www. THIS WARRANTY IS THE PURCHASER’S SOLE AND horizonhobby.com/content/_service-center_render- EXCLUSIVE REMEDY. service-center.
-
