V7122 gateway completes the restart, Ready and LAN LEDs on the front panel are lit
green.
10 After the gateway is reset, configure the V7122 gateway trunk parameters. For
information about configuring the trunk parameters, see
SIP users should continue with Section
The following sections from here, up to the end of this Guide, apply equally to H.323,
and SIP.

Configuring the Trunk Settings

To configure the trunk settings, follow these 14 steps:
Access the Embedded Web Server (see
1
Open the Trunk Settings screen (Advanced Configuration menu > Trunk Settings); the
2
Trunk Settings screen is displayed.
Initially, the screen appears with the parameters fields grayed (indicating read-only). The
Stop Trunk button appears at the bottom of the screen. The Trunk Status indicators
appear colored. Table 7
Trunk Settings Screen
Figure 15
V7122 Digital Gateway Installation Guide
Configuring the Trunk
Accessing the Embedded Web
shows the possible indicators and their descriptions.
Configuring the Trunk Settings.
Settings.
Server).
33
