User's Manual
FSD-804PS
8-Port 10/100Mbps with
4-Port PoE
Web Smart Ethernet Switch
- 1 -

Advertisement

Table of Contents
loading

Related Manuals for Planet FSD-804PS

Summary of Contents for Planet FSD-804PS

  • Page 1 User's Manual FSD-804PS 8-Port 10/100Mbps with 4-Port PoE Web Smart Ethernet Switch - 1 -...

  • Page 2: Fcc Warning

    PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims liability for any inaccuracies or omissions that may have occurred.

  • Page 3: Table Of Contents

    VERVIEW 3.2 R ............................16 EQUIREMENTS 3.3 M ..........................16 ANAGEMENT ETHOD 3.3.1 Web Management ............................16 3.3.2 PLANET Smart Discovery Utility........................18 4. WEB CONFIGURATION ....................20 4.1 M ............................20 ANIN 4.2 W ............................. 21 ANEL 4.3 S ..............................
  • Page 4 User’s Manual of FSD-804PS 4.8 M ..........................56 ONFIGURATION 4.9 P ..........................58 ONFIGURATION 4.10 L ..............................60 OGOUT 5. SWITCH OPERATION....................61 5.1 A ............................61 DDRESS ABLE 5.2 L ..............................61 EARNING 5.3 F & F ........................61...

  • Page 5: Introduction

    With 4 PoE interfaces, the FSD-804PS is ideal for small business and workgroups requiring to deploy the PoE for the wireless access points, IP-based surveillance camera or IP phones in any places easily, efficiently and cost effective.
  • Page 6 PD classification detection Management Web interface for remote management Firmware upgrade through Web interface PLANET Smart Discovery utility automatically finds PLANET devices on the network SNMP Trap for alarm notification of events Switching Hardware based 10/100Mbps auto-negotiation Flow control for full duplex operation and back pressure for half duplex operation...

  • Page 7: Specification

    User’s Manual of FSD-804PS 1.4 Specification Model FSD-804PS Hardware Specification 8-Port RJ-45 for 10/100Base-TX Network Connector 4-Port with PoE injector function, Port-1 to Port-4 PoE Inject Port One power, 1-4 port PoE in-use, LNK/ACT LED Display 5-8 port LNK/ACT Store and Forward switch architecture Switch Architecture 1.6Gbps...
  • Page 8 User’s Manual of FSD-804PS 5% to 90% , relative humidity, non-condensing Operating Humidity 5% to 90% , relative humidity, non-condensing Storage Humidity IEEE 802.3 Ethernet Standard Compliance IEEE 802.3u Fast Ethernet IEEE 802.3x Flow Control IEEE 802.3af Power over Ethernet IEEE 802.1p...

  • Page 9: Hardware Description

    Front panel illustrations in this chapter display the unit LED indicators. Before connecting any network device to the FSD-804PS, read this chapter carefully. In the following section, the term “PoE Switch” means the Web Smart PoE switch device, ie. FSD-804PS; term of “switch” can be any third switches.

  • Page 10: Rear Panel

    2.2 Rear Panel The rear panel of the FSD-804PS indicates an AC inlet power socket, which accepts input power from 100 to 240VAC, 50-60Hz. And have a fan hole on the rear panel. Figure 2-3 FSD-804PS Switch rear panel The device is a power-required device, it means, it will not work till it is powered.

  • Page 11: Hardware Installation

    Users only need to plug a working network device into one of the 100Base-TX ports, and then turn on the FSD-804PS. The port will automatically runs in 10Mbps, 20Mbps, 100Mbps or 200Mbps after the negotiation with the connected device.

  • Page 12: Desktop Installation

    User’s Manual of FSD-804PS 2.4 Desktop Installation To install the Switch on desktop, simply follow the next steps: Step1: Attach the rubber feet to the recessed areas on the bottom of the Switch, as shown in Figure 2-4. Figure 2-4 Attaching the rubber feet to the Switch Step2: Place the Switch on desktop near an AC power source.

  • Page 13: Rack Mounting (Optional Rack Kits)

    User’s Manual of FSD-804PS 2.5 Rack Mounting (Optional Rack Kits) To install the Switch in a 10-inch or 19-inch standard rack, PLANET provides the optional rack mount kits RKE-10A / RKE-10B for different need. Follow the instructions described below. Step1: Place your Switch on a hard flat surface, with the front panel positioned towards your front side.

  • Page 14: Product Application

    19” rack. Connect the power cord to the power inlet socket of FSD-804PS and the other end into the local power source outlet. When the Switch receives power, the Power LED should remain solid Green.

  • Page 15: Power Over Ethernet Powered Device

    User’s Manual of FSD-804PS 2.6.2 As a department / workgroup PoE Switch Providing up to 4 PoE, in-line power interface, the Switch can easily build a power central-controlled IP phone system, IP Camera system, AP group for the enterprise. For instance, 4 camera / AP can be easily installed around the corner in the company for surveillance demands or build a wireless roaming environment in the office.

  • Page 16: Management

    User’s Manual of FSD-804PS 3 MANAGEMENT This chapter describes how to manage the PoE Switch. Topics include: - Overview - Management method - Logging on to the Web Smart Switch 3.1 Overview The Web Smart PoE Switch provides a user-friendly, Web interface. Using this interface, you can perform various device...
  • Page 17 User’s Manual of FSD-804PS Use Internet Explorer 5.0 or above Web browser. Enter IP address http://192.168.0.100 (the factory-default IP ad- dress or that you have changed via console) to access the Web interface. Figure 3-1 Web Management over Ethernet When the following login screen appears, please enter the default username "admin" and password “admin” (or the password you have changed via console) to login the main screen of PoE Switch.

  • Page 18: Planet Smart Discovery Utility

    User’s Manual of FSD-804PS 3.3.2 PLANET Smart Discovery Utility For easily list the Switch in your Ethernet environment, the Planet Smart Discovery Utility from user’s manual CD-ROM is an ideal solution. The following install instructions guiding you for run the Planet Smart Discovery Utility.
  • Page 19 To click the “Control Packet Force Broadcast” function, it can allow assign new setting value to the Switch under different IP subnet address. Press “Connect to Device” button then the Web login screen appears in Figure 3-2. Press “Exit” button to shutdown the planet Smart Discovery Utility. - 19 -...

  • Page 20: Web Configuration

    User’s Manual of FSD-804PS 4. WEB CONFIGURATION The Switch provide Web interface for PoE smart function configuration and make the Switch operate more effectively - They can be configured through the Web Browser. A network administrator can manage and monitor the Switch from the local LAN.

  • Page 21: Web Panel

    User’s Manual of FSD-804PS 4.2 Web Panel At the top of the Web management page, the active panel displays the link status of management port and PoE ports. Figure 4-2 Main menu screen Green lit is the port link up.

  • Page 22: System Information

    User’s Manual of FSD-804PS 4.3.1 System Information The System information allows viewing system MAC Address, Software Version, Hardware Version, IP Address, Subnet Mask and Gateway. As showed in Figure 4.4 Figure 4-4 System Information screen The page includes the following fields:...

  • Page 23: Password Setting

    Description 4.3.3 Password Setting This section provides password change Configuration of FSD-804PS, please input the old password in “Old Password” space and input the new password in “New Password” space then input the new password in “Confirm”. After setup completed, please press “Apply” button to take effect and the Switch will logout automatically. Please login web interface with new password, the screen in Figure 4.6...

  • Page 24: Firmware Upgrade

    User’s Manual of FSD-804PS The page includes the following configurable data: Object Description Displays the login user name. Login Name Enter the old password is required before entering the new password. Old Password Specifies the new password. The password is not displayed. As it entered an “ ” corresponding New Password to each character is displayed in the field.
  • Page 25 Or the system won’t apply the new firmware. Users have to repeat the firmware upgrade processes again. Do not use Firefox or Windows Vista platform for FSD-804PS firmware upgrade or it might cause the firmware upgrade fail. It is due to the short “HTTP respond time” for Firefox and Windows Vista.

  • Page 26: Configuration Setting

    User’s Manual of FSD-804PS 4.3.5 Configuration Setting This function allows backup and restore the current configuration of PoE Switch, or reset the converter to factory default. The description of the three items as follow and screen in Figure 4-10 appears.

  • Page 27: Factory Reset

    User’s Manual of FSD-804PS Figure 4-12 Configuration backup successes screen Restore The PoE Switch will restore to previous backup/saved configuration while the “Restore” button be pressed. And please note that once the Restore button be pressed, Web interface will disconnected for a while. Reload the Web browser to re-login the system.

  • Page 28: Alert Trap Configuration

    User’s Manual of FSD-804PS 4.3.6 Alert Trap Configuration This function displays the Switch alert trap configuration; include “enable” or “disable” the trap mode and set the alert IP address. As showed in Figure 4-16. Figure 4.16 Alert Trap Configuration screen...

  • Page 29: System Reboot

    User’s Manual of FSD-804PS 4.3.7 System Reboot This section provides reboot FSD-804PS, after choose this function and the following screen appears in Figure 4-17. Please press “OK” button to take effect and the PoE Switch will reboot and ask you to re-login web interface with correct username “admin”...

  • Page 30: Port Management

    Port Configuration Port Status Port Security 4.4.1 Port Configuration This section introduces detail settings of per port of FSD-804PS, the screen in Figure 4-20 appears and table 4-2 de- scriptions the Port Setup objects of PoE Switch. Figure 4-20 Port Setup Web Page screen...

  • Page 31: Port Status

    When the ports are being set as fixed 100M Full, 100M Half, 10M Full, and 10M Half-speed modes, the Auto-MDIX function will disable. 4.4.2 Port Status This section provides current status of each port from FSD-804PS, the screen in Figure 4-21 appears and Table 4-3 de- scribes the port status object of PoE Switch.

  • Page 32: Port Security

    Speed Display half or full duplex mode of each port on FSD-804PS. Duplex Display the flow control Disable or Enable state of each port on FSD-804PS. Flow Control Table 4-3 Descriptions of the Port Status screen Objects 4.4.3 Port Security The Layer 2 MAC address learning function can be per-port disable for security management purposes.
  • Page 33 User’s Manual of FSD-804PS Object Description Which selecting this option locks the specified interface. Port Enable Source MAC address lock function on specified port. By which locks the Port Security port using the classic lock mechanism. The port is immediately locked without Enable permission of address learning.

  • Page 34: Vlan

    User’s Manual of FSD-804PS 4.5 VLAN A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain. It allows you to isolate network traffic so only members of the VLAN receive traffic from the same VLAN members. Basically, creating a VLAN from a switch is logically equivalent of reconnecting a group of network devices to another Layer 2 switch.
  • Page 35 User’s Manual of FSD-804PS 802.1Q VLAN Tags The figure below shows the 802.1Q VLAN tag. There are four additional octets inserted after the source MAC address. Their presence is indicated by a value of 0x8100 in the Ether Type field. When a packet's Ether Type field is equal to 0x8100, the packet carries the IEEE 802.1Q/802.1p tag.
  • Page 36 User’s Manual of FSD-804PS Tag-aware switches must keep a table to relate PVID within the switch to VID on the network. The switch will compare the VID of a packet to be transmitted to the VID of the port that is to transmit the packet. If the two VID are different the switch will drop the packet.

  • Page 37: Vlan Group

    User’s Manual of FSD-804PS 4.5.1 VLAN Group The VLAN Group page contains fields for managing VLAN mode of the Switch and setting ports that are part of a VLAN. The port default VLAN ID (PVID) is configured on the VLAN Port Configuration page. All untagged packets arriving to the device are tagged by the ports PVID.
  • Page 38 User’s Manual of FSD-804PS 4.5.1.1 Port-Based VLAN By setting the VLAN Type with Port-Based, Port-Based VLAN is enabled and 802.1Q VLAN tagging is ignored. The VLAN group classification of an incoming packet on a Port-Based VLAN is defined by the VLAN group table.
  • Page 39 User’s Manual of FSD-804PS Specifies the management VLAN ID of the Switch. It may be configured to any Management VLAN value in the range of 1 - 16. The management VLAN is used for management of the Switch. At Port-Based VLAN mode, up to 8 VLAN groups can be configured.
  • Page 40 User’s Manual of FSD-804PS The page includes the following fields: Object Description There’re two VLAN mode support – 802.1Q VLAN and Port-Bas VLAN VLAN Type • 802.1Q – Packets income will be tagged with VID as the PVID setting. All ports on the switch belong to default VLAN (VID 1).

  • Page 41: Vlan Per Port Setting

    User’s Manual of FSD-804PS 4.5.2 VLAN Per Port Setting The PoE Switch inserts or removes a tag of frame if Tag / UnTag function is enabled. The operation is illustrated as follows. Understand nomenclature of the 802.1Q VLAN aware Switch Tagging and Untagging Every port on an 802.1Q compliant switch can be configured as tagging or untagging.
  • Page 42 User’s Manual of FSD-804PS The page includes the following fields: Object Description Indicate the physical interface for which you want to display or configure data. Port Link Type Allow 802.1Q Untagged or Tagged VLAN for selected port. When adding a VLAN to selected port, it tells the switch whether to keep or remove the tag from a frame on egress.

  • Page 43: Vlan Setting Example

    User’s Manual of FSD-804PS 4.5.3 VLAN setting example: 4.5.3.1 Two separate 802.1Q VLAN The diagram shows how the switch handle Tagged and Untagged traffic flow for two VLANs. VLAN Group 2 and VLAN Group 3 are separated VLAN. Each VLAN isolate network traffic so only members of the VLAN receive traffic from the same VLAN members.
  • Page 44 User’s Manual of FSD-804PS Untagged packet entering VLAN 3 While [PC-4] transmit an untagged packet enters Port-4, the switch will tag it with a VLAN Tag=3. [PC-5] and [PC-6] will received the packet through Port-5 and Port-6. While the packet leaves Port-5, it will be stripped away it tag becoming an untagged packet.
  • Page 45 User’s Manual of FSD-804PS Remember to remove the Port 1 – Port 6 from VLAN 1 membership, since the Port 1 – Port 6 had been assigned to VLAN 2 and VLAN 3. It’s import to remove the VLAN members from VLAN 1 configuration. Or the ports would become overlap setting.
  • Page 46 User’s Manual of FSD-804PS 4.5.3.2 Two VLANs with overlap area Follow the example of 4.5.3.1. There’re two exist separate VLANs – VLAN 2 and VLAN 3, and the PCs of each VLANs are not able to access each other of different VLANs. But they all need to access with the same server. The screen in...
  • Page 47 User’s Manual of FSD-804PS Define a VLAN 1 as a “Public Area” that overlapping with both VLAN 2 members and VLAN 3 members. Figure 4-32 VLAN 1 – The public area member assigning Setup Port-8 with “PVID=1” at VLAN per Port Configuration page. The screen in Figure 4-28 appears.
  • Page 48 User’s Manual of FSD-804PS 4.5.3.3 Port-based VLAN setting example: VLAN scenario is the file server port for all the workstations Port-8 is different devices that do not need to see each other Port-1 Port-7 Setup steps 1. Port Setting 1.1 Assign VLAN 2 for the second VLAN group with...

  • Page 49: Quality Of Service

    User’s Manual of FSD-804PS 4.6 Quality of Service Quality of Service (QoS) is an advanced traffic prioritization feature that allows you to establish control over network traffic. QoS enables you to assign various grades of network service to different types of traffic, such as multi-media, video, protocol-specific, time critical, and file-backup traffic.

  • Page 50: 802.1P Tag Priority Mode

    User’s Manual of FSD-804PS 4.6.1 802.1p Tag Priority Mode QoS settings allow customization of packet priority in order to facilitate delivery of data traffic that might be affected by latency problems. When 802.1p Tag Priority is applied, the PoE Switch recognizes 802.1Q VLAN tag packets and extracts the VLAN tagged packets with User Priority value.
  • Page 51 User’s Manual of FSD-804PS Weighted Round Robin ratio setting of priority queue. Weighted Round Robin Ratio The frame service rate of High-Priority queue to Low-Priority queue options are shown as below: • Highest:Lowest=4:1 • Highest:Lowest=8:1 The PoE Switch had define the VLAN tagged packets with User Priority value 4~7 are treated as high priority packets, and the other User Priority values (0~3) as low priority packets.

  • Page 52: Dscp Qos Mode

    User’s Manual of FSD-804PS 4.6.2 DSCP QoS Mode DiffServ Code Point (DSCP) － is the traffic prioritization bits within an IP header that are encoded by certain applications and/or devices to indicate the level of service required by the packet across a network.
  • Page 53 User’s Manual of FSD-804PS The page includes the following fields: • Object • Description • QoS Mode The draw menu allows customization of QoS mode for Traffic classifiers. • 802.1p Tag Priority • IP DSCP • Port-Base Priority Weighted Round Robin ratio setting of priority queue.

  • Page 54: Port-Based Priority Mode

    User’s Manual of FSD-804PS 4.6.3 Port-Based Priority Mode When Port-Based priority is applied, any packets received from a high priority port will be treated as a high priority packet. Select the QoS mode to Port-Based Priority, the Port ID to queue mapping configuration page appears, as the Figure 4-40 shows.

  • Page 55: Storm Control

    User’s Manual of FSD-804PS 4.7 Storm Control The Storm Control function enables each port to drop broadcast packets (Destination MAC Address is “FF-FF-FF-FF-FF-FF) after a continuous received broadcast packets counter count of the defined value of rate threshold.. This function is to control the Broadcast Storm and Multicast storm packet on each port. The screen Figure 4-41 appears.

  • Page 56: Misc Configuration

    User’s Manual of FSD-804PS 4.8 Misc Configuration This section provides Misc Configuration of FSD-804PS, it allows configuring Flow Control, MAC Address Aging time and etc for the PoE Switch. In a dynamic network topology, address aging allows the contents of the address table to always be the most recent and correct.
  • Page 57 User’s Manual of FSD-804PS • 300 sec - Enable MAC table aging function. A learned source address entry will be cleared with a period of time if it is not updated by the ad- dress learning process. IEEE 802.1D recommends a default of 300 seconds, which is the factory default.

  • Page 58: Poe Configuration

    User’s Manual of FSD-804PS 4.9 PoE Configuration Power Management: In a power over Ethernet system, operating power is applied from a power source (PSU-power supply unit) over the LAN infrastructure to powered devices (PDs), which are connected to ports. Under some conditions, the total output power required by PDs can exceed the maximum available power provided by the PSU.
  • Page 59 User’s Manual of FSD-804PS Object Description Allow to configure power limit mode of Web Smart Device. It can choose : Power limit mode Port Priority Deliver PoE power by port priority setting Total Limit. Set limit value of the total POE port provided power to the PDs.

  • Page 60: Logout

    User’s Manual of FSD-804PS 4.10 Logout Press this function; the Web interface will go back to login screen. The screens in Figure 4-44 Figure 4-45 appear. Figure 4-44 Logout dialogues screen Figure 4-45 Login screen - 60 -...

  • Page 61: Switch Operation

    User’s Manual of FSD-804PS 5. SWITCH OPERATION 5.1 Address Table The Switch is implemented with an address table. This address table composed of many entries. Each entry is used to store the address information of some node in network, including MAC address, port no, etc. This information comes from the learning process of Ethernet Switch.

  • Page 62: Power Over Ethernet Overview

    User’s Manual of FSD-804PS 6. POWER OVER ETHERNET OVERVIEW What is PoE? Based on the global standard IEEE 802.3af, PoE is a technology for wired Ethernet, the most widely installed local area network technology adopted today. PoE allows the electrical power necessary for the operation of each end-device to be carried by data cables rather than by separate power cords.
  • Page 63 User’s Manual of FSD-804PS The data pairs are used. Since Ethernet pairs are transformer coupled at each end, it is possible to apply DC power to the center tap of the isolation transformer without upsetting the data transfer. In this mode of operation the pair on pins 3 and 6 and the pair on pins 1 and 2 can be of either polarity.

  • Page 64: The Poe Provision Process

    User’s Manual of FSD-804PS 7. THE POE PROVISION PROCESS While adding PoE support to networked devices is relatively painless, it should be realized that power cannot simply be transferred over existing CAT-5 cables. Without proper preparation, doing so may result in damage to devices that are not designed to support provision of power over their network interfaces.

  • Page 65: Start-Up

    User’s Manual of FSD-804PS 7.3 Start-up Once line detection and optional classification stages are completed, the PSE must switch from low voltage to its full voltage capacity (44-57 Volts) over a minimal amount of time (above 15 microseconds). A gradual startup is required, as a sudden rise in voltage (reaching high frequencies) would introduce noise on the data lines.

  • Page 66: Troubleshooting

    Why I connect my PoE device to FSD-804PS and it cannot power on? Solution: 1. Please check the cable type of the connection from FSD-804PS (port 1 to port 4) to the other end. The cable should be an 8-wire UTP, Category 5 or above, EIA568 cable within 100 meters.

  • Page 67: Appendix A Networking Connection

    User’s Manual of FSD-804PS APPENDIX A NETWORKING CONNECTION A.1 DATA OUT PoE Switch RJ-45 Port Pin Assignments (Port 1 to Port-4) PIN NO RJ-45 SIGNAL ASSIGNMENT • Output Transmit Data + • Power + • Output Transmit Data – • Power + •...
  • Page 68 User’s Manual of FSD-804PS Straight Cable SIDE 1 SIDE2 1 = White / Orange 1 = White / Orange 2 = Orange 2 = Orange SIDE 1 3 = White / Green 3 = White / Green 4 = Blue...

  • Page 69: Power Over Ethernet Compatibility Test

    User’s Manual of FSD-804PS APPENDIX B B.1 Power over Ethernet Compatibility test PoE Output Note [PLANET POE-151S-12V] + [PLANET ICA-500] 9.6W [PLANET POE-151S-12V] + PLANET ICA310 6.4W Standby [PLANET POE-152S-12V] + [PLANET ICA-500] 7.3W [PLANET POE-151S-12] + CAM-IR338-NT 5.1W LED Off [PLANET POE-151S-12] + CAM-IR338-NT 13.5W~14.3W...
