TABLE OF CONTENTS 1. INTRODUCTION............................4 1.1 C ..............................4 HECKLIST 1.2 H ........................4 OW TO ANUAL 1.3 F ..............................4 EATURES 1.4 S ............................5 PECIFICATION 2. HARDWARE DESCRIPTION ........................6 2.1 P ..........................6 RODUCT ESCRIPTION 2.2 F ............................
This chapter contains troubleshooting of FSD-804P Appendix This chapter contains cable information of FSD-804P In the following section, the term “Switch” means the Switch device, ie. FSD-804P; term of “switch” can be any third switches 1.3 Features 8-Port 10/100Mbps Fast Ethernet ports ◆...
1.4 Specification Model FSD-804P Hardware Specification Network Connector 8-Port RJ-45 for 10/100TX PoE Inject Port 4-Port with PoE injector function, Port-1 to Port-4 One power, LED Display 1-4 port PoE in-use, LNK/ACT, 100, 5-8 port LNK/ACT, 100 PoE Output power budget...
Furthermore, it is the ideal device for bridging among Ethernet, Fast Ethernet workgroups and networks. With 4 PoE interfaces, the FSD-804P is ideal for small business and workgroups requiring to deploy the PoE for the wireless access points, IP-based surveillance camera or IP phones in any places easily, efficiently and cost effective.
2.3 Rear Panel The rear panel of the FSD-804P indicates an AC inlet power socket, which accepts input power from 100 to 240VAC, 50-60Hz, 1A max. Figure 2-2: FSD-804P Switch rear panel Power Notice: 1. The device is a power-required device, it means, it will not work till it is powered. If your networks should active all the time, please consider using UPS (Uninterrupted Power Supply) for your device.
2.5 Desktop Installation To install the Switch on desktop, simply follow the next steps: Step1: Attach the rubber feet to the recessed areas on the bottom of the Switch, as shown in Figure 2-3. Figure 2-3 Attaching the rubber feet to the Fast Ethernet Switch Step2: Place the Switch on desktop near an AC power source.
2.6 Rack Mounting To install the Switch in a 10-inch standard rack, follow the instructions described below. Step1: Place your Fast Ethernet Switch on a hard flat surface, with the front panel positioned towards your front side. Step2: Attach a rack-mount bracket to each side of the Switch with supplied screws attached to the package. Figure 2-4 shows how to attach brackets to one side of the Switch.
Place the FSD-804P on a smooth surface or fasten the mounting brackets purchased separately with the provided screws in a standard 19” rack. Connect the power cord to the power inlet socket of FSD-804P and the other end into the local power source outlet. When the Switch receives power, the Power LED should remain solid Green.
Page 11
2.7.2 Department/ Workgroup PoE Switch: Providing up to 4 PoE, in-line power interfaces, the Switch can easily build a power central-controlled IP phone system, IP camera system, AP group for the enterprise. For instance, 4 camera / AP can be easily install around the cornerin the company for surveillance demands or build a wireless roaming environment in the offices.
No packet loss will occur. 3.5 Auto-Negotiation The STP ports on the FSD-804P switch have built-in "Auto-negotiation". This technology automatically sets the best possible bandwidth when a connection is established with another network device (usually at Power On or Reset).
Check the LNK/ACT LED on the switch Try another port on the Switch Make sure the cable is installed properly Make sure the cable is the right type Turn off the power. After a while, turn on power again. Why I connect my PoE device to FSD-804P and it cannot power on? Solution: Please check the cable type of the connection from FSD-804(port 1 to port 4) to the other end.
APPENDIX A NETWORKING CONNECTION A.1 Switch‘s RJ-45 Pin Assignments Contact MDI-X 1 (TX +) 2 (TX -) 3 (RX +) 6 (RX -) 4, 5, 7, 8 Not used Not used A.2 RJ-45 cable pin assignment There are 8 wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of straight cable and crossover cable connection: Figure A-1: Straight-Through and Crossover Cable Please make sure your connected cables are with same pin assignment and color as above picture before deploying the...
