C AUTI ON These servicing instructions are for use by qualifi ed service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualifi ed to do so. In USA and Canada, Use Class 2 Power Supply Only...
Contents Caution IMPORTANT SAFETY INSTRUCTIONS 1. Overview 1.1 Features guration 1.3 Termination Settings 2. Installation and Connection 2.1 Package Contents 2.2 Surface Mounting 2.3 Mounting Accessories 2.4 Connection Interface and Wiring Cables 2.5 Setting Dome Camera 3. Program and Operation OSD Menu Structure 3.1 Getting Started 3.2 Main Menu...
Caution This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions; 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. Note This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
Page 5
Caution Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicate that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
2. Installation and Connection 2.2 Surface Mounting Mounting 1 - Select a location that can support the weight Template of the camera. 2 - Use the mounting template to create holes for the mounting screws and cable. Insert the anchors(4). Anchors(4) 3 - Run the cables through the cable hole and connect the cables as shown in...
2. Installation and Connection 2.4 Connection Interface and Wiring Cables Caution Remove the protection sheet (PE form) before connecting power to the camera. Do not connect the power cable until all other connections have been completed. 2.4.1 Connecting the RS-485 lines The dome camera can be controlled remotely by an external device or control system such as a controller using RS-485 half duplexer (RS-485 Connection).
2. Installation and Connection 2.5 Setting Dome Camera The device can communicate with external switching devices such as multiplexers or DVR’s by setting the Rotary switch and Dip switch. Refer to tables below for setting the dome camera ID and protocol selection. Total length of the cable for communication should not exceed 1km. 2.5.1 Setting the address (ID) of dome camera To prevent wrong operation and malfunction, each dome camera has a unique address (ID).
3. Program and Operation [OSD Menu Structure] - Main Menu/Editing Title MAIN MENU TITLE S Y S T E M S E T U P ABCDEFGHIJKLMNOPQRSTUVWXYZ D I S P LA Y S E T U P 0123456789/+-=:?!#.,"~() C A ME R A S E TU P D O M E M O TI O N P R E S E T S E T U P SELECT: (MOVE)
Page 14
3. Program and Operation REFRESH MODE : ON REFRESH TIME: PROP PAN/TILT : ON PRESET MASK : OFF...
3. Program and Operation 3.1 Getting Started Before installing and operating the dome camera, please read this Instruction Manual carefully. This dome camera can be operated using two methods: - Use hot keys [See Appendix] - Use OSD Menu on the monitor You should install and connect the dome to an interface device before using this operating guide.
3. Program and Operation 3.2.2 Editing TITLE TITLE ABCDEFGHIJKLMNOPQRSTUVWXYZ 0123456789/+-=;?#.,"~0 SELECT : (MOVE) SET/CLEAR: (TELE/WIDE) SAVE : (NEAR) EXIT : (FAR) The Title edit menu can be used in the setup titles for Presets, Patterns, Tours, and Scans. - Select {Title} in the appropriate menu and move the joystick to the right. - Move the joystick right, left, up or down to select a character.
Page 18
3. Program and Operation 3.3.2 Reboot REBOOT C O N T I N U E ? Y E S : N E A R NO : FAR Reboot the system if operation becomes unstable or encounters errors. Rebooting the system will turn the camera on and off without changing settings. - Enter into {Main Menu} - Select {System Setup} then {Reboot} using the joystick.
3. Program and Operation 3.3.4 Entering a Password * Note: 0000 is the default password. PASSWORD C U R R E N T : . . . E N A B L E : D I S A B L E N E W : .
3. Program and Operation 3.4.2 OSD Setup OSD SETUP - TITLE - MODE - - DT I ME - LA B E L P OS IT I ON : O F F E RR O R M SG T I M E : O N - EXIT : FAR Z O OM...
3. Program and Operation 3.4.4 Image Setup IMAGE SETUP M IR R O R : N O RM AL S A VE : O PE N B A CK : C L O S E This menu allows you to mirror the image horizontally, vertically, or both. - Enter into {Main Menu} - Select {Display Setup} and then select {Image Setup} using the joystick[ ].
3. Program and Operation 3.5 Camera Setup Menu CAMERA SETUP FO C U S/ZO O M W-BALANCE EXPO SU R E D AY/N I G H T ADVANCE WDR/DNR EXIT : move joystick up and down to select items. : move joystick left and right to change settings. / [Open]/ [Near]: move joystick right to enter sub-menus.
Page 23
3. Program and Operation 3.5.3 AE Setup (Auto Exposure Setup) AE SETUP MO D E : F U LL A U TO SHUT AG C G AI N : AG C MA X : H I G H D SS : O FF BR I G H T : 0 6...
3. Program and Operation 3.5.5 Advanced Setup ADVANCED SETUP S H AR P N E SS : 10 B AC K LIG H T : O F F S AV E : O P E N B AC K : C LO S E The Backlight Compensation function increases the brightness of the overall screen to compensate for a loss of dark detail when subjects are shot in a backlit environment.
3. Program and Operation 3.6 Dome Motion Menu DOME MOTION SETUP G EN E R A L SET UP MOTION SETUP H O M E A C T I O N C A LI BR A T I O N EXIT / : move joystick up and down to select items.
3. Program and Operation 3.6.2 Motion Setup MOTION SETUP PR O P. PAN / TILT : ON AU TO FI LP : O N OVER TILT : MODE 1 SAVE : O PEN BAC K : C LO SE Proportional Pan/Tilt (Prop. Pan/Tilt) adjusts the manual pan/tilt speed according to the zoom level. - Highlight {Prop.
3. Program and Operation 3.6.4 Calibration Setup C ON TI NU E? CALIBRATION SETUP YES : N EAR AU TO CA L : AU TO NO : FAR ER RO R M SG D I SP : O F F CA LI BR ATI ON SA VE : OP EN BA CK : CLOS E...
3. Program and Operation 3.7.1 Saving Presets PRESET SETUP PRESET SETUP PR E SS M OVE K EY N O. 001 : NOT U SED EDI T SA VE : N E AR TI TLE BACK : FAR D TIME C LEAR SAVE : OPEN BACK : CLOSE...
3. Program and Operation Use the following steps to program a Pattern. PTIME: 022 PATTERN SETUP START POSITION SETUP N O.001 : NOT USED PATTERN SETUP EDI T TI TLE P R ESS M OV E KEY TIME S T AR T : ( N EAR ) C LEAR SAVE : (NEAR) E XI T : (F A R )
3. Program and Operation 3.10 Auto Scan Setup SCAN SETUP NO. 001 : NOT USED ED IT SPEED DTIME D IR EC TIO N : MO D E C LEAR SAVE : O PEN BAC K : C LO SE / : move joystick up and down to select items.
3. Program and Operation 3.11 Alarm Setup The Alarm Setup menu allows you to configure alarm inputs and outputs. ALARM SETUP N O . 001 : N OT U SE D O U T PR IO R ITY AC TI O N N U MBER A TIME SAVE : O PEN...
4. Troubleshooting Guide If problems occur, please consult the following steps before contacting Digimerge Technical Support. Problem S olution - Verify that power is connected to all components in the system - Verify that the power switches are ON No video on the screen...
APPENDIX. Pelco Protocol Function List LCD DISPLAY Function Keys > F1(PSET), F2(TOUR), F3(PATT), F4(SCAN) ESC/POWER Joystick Camera Focus control Number Controller > NER / FAR, TELE / WIDE Function Keys Based on WTX1200A Function Preset No. Operation e.g. 1 e.g. 2 1~59, Preset Preset...
