Pll Unit - Icom IC-706MKIIG Service Manual

[HPF BOARD]
REF ORDER
NO. NO.
L121 6200002040 S.COIL
L122 6200007170 S.COIL
L123 6200003550 S.COIL
L124 6200002040 S.COIL
L131 6200004920 S.COIL
L132 6200004660 S.COIL
L133 6200004660 S.COIL
L134 6200002040 S.COIL
L141 6200003960 S.COIL
L142 6200003960 S.COIL
L143 6200003960 S.COIL
L144 6200002040 S.COIL
L151 6200002040 S.COIL
L152 6200001700 S.COIL
L153 6200001200 S.COIL
L154 6200001210 S.COIL
L155 6200001060 S.COIL
L161 6200002040 S.COIL
L162 6200001170 S.COIL
L163 6200001180 S.COIL
L164 6200002040 S.COIL
L171 6200005010 S.COIL
L172 6200001090 S.COIL
L173 6200001100 S.COIL
L174 6200001870 S.COIL
L175 6200001130 S.COIL
L176 6200005010 S.COIL
L191 6200005010 S.COIL
L192 6200003840 S.COIL
L193 6200001170 S.COIL
L194 6200003280 S.COIL
L195 6140002810 S.COIL
L196 6200001500 S.COIL
L197 6200004150 S.COIL
R101 7030003760 S.RESISTOR
R102 7030003760 S.RESISTOR
R111 7030003320 S.RESISTOR
R171 7030003720 S.RESISTOR
R172 7030003320 S.RESISTOR
R191 7030003720 S.RESISTOR
R192 7030003280 S.RESISTOR
R193 7030003340 S.RESISTOR
R194 7030004050 S.RESISTOR
R195 7030003280 S.RESISTOR
R211 7030003560 S.RESISTOR
R212 7030003520 S.RESISTOR
R213 7030003560 S.RESISTOR
R214 7030003560 S.RESISTOR
C101 4030007110 S.CERAMIC
C102 4030007060 S.CERAMIC
C103 4030007150 S.CERAMIC
C104 4030007010 S.CERAMIC
C105 4030007120 S.CERAMIC
C111 4030010210 S.CERAMIC
C121 4030011600 S.CERAMIC
C122 4030008470 S.CERAMIC
C123 4030008860 S.CERAMIC
C124 4030009980 S.CERAMIC
C125 4030011600 S.CERAMIC
C126 4030006880 S.CERAMIC
C131 4030011600 S.CERAMIC
C132 4030009580 S.CERAMIC
C133 4030009980 S.CERAMIC
C134 4030009580 S.CERAMIC
C135 4030008470 S.CERAMIC
C136 4030006860 S.CERAMIC
C141 4030011600 S.CERAMIC
C142 4030010240 S.CERAMIC
C143 4030010030 S.CERAMIC
C144 4030010760 S.CERAMIC
C145 4030006860 S.CERAMIC
C146 4030009580 S.CERAMIC
C147 4030011600 S.CERAMIC
C151 4030011600 S.CERAMIC
C152 4030007160 S.CERAMIC
C153 4030006860 S.CERAMIC
C154 4030007150 S.CERAMIC
C155 4030011330 S.CERAMIC
DESCRIPTION
NL 252018T-101J
MLF1608A 3R3K-T
MLF1608A 4R7K-T
NL 252018T-101J
MLF1608A 2R2K-T
MLF1608A 1R8K-T
MLF1608A 1R8K-T
NL 252018T-101J
MLF1608A 1R0K-T
MLF1608A 1R0K-T
MLF1608A 1R0K-T
NL 252018T-101J
NL 252018T-101J
MLF2012D R47K-T
MLF2012D R56M-T
MLF2012D R68M-T
MLF2012D 47NM-T
NL 252018T-101J
MLF2012D R33M-T
MLF2012D R39K-T
NL 252018T-101J
NL 252018T-100J
MLF2012D 68NM-T
MLF2012D 82NM-T
MLF2012D R27K-T
MLF2012D R15M-T
NL 252018T-100J
NL 252018T-100J
MLF2012D R22K-T
MLF2012D R33M-T
NL 252018T-2R2J
LR-317
MLF2012D R12K-T
MLF1608D 47NM-T
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 1R0 V (1 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
C1608 CH 1H 680J-T-A
C1608 CH 1H 270J-T-A
C1608 CH 1H 151J-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 820J-T-A
C3216 JB 1C 105M-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 272K-T-A
C1608 JB 1C 153K-T-A
C1608 JB 1H 152K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 681K-T-A
C1608 JB 1H 152K-T-A
C1608 JB 1H 681K-T-A
C1608 JB 1H 272K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 391K-T-A
C1608 SL 1H 511J-T-A
C1608 CH 1H 331J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 681K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 CH 1H 181J-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 151J-T-A
C1608 CH 1H 391J-T-A
[HPF BOARD]
REF ORDER
NO. NO.
C156 4030007170 S.CERAMIC
C161 4030011600 S.CERAMIC
C162 4030007170 S.CERAMIC
C163 4030010020 S.CERAMIC
C164 4030007130 S.CERAMIC
C165 4030010760 S.CERAMIC
C166 4030006880 S.CERAMIC
C171 4030006900 S.CERAMIC
C172 4030007080 S.CERAMIC
C173 4030011540 S.CERAMIC
C174 4030007150 S.CERAMIC
C175 4030009650 S.CERAMIC
C176 4030007150 S.CERAMIC
C177 4030007140 S.CERAMIC
C178 4030007110 S.CERAMIC
C179 4030007090 S.CERAMIC
C180 4030010760 S.CERAMIC
C181 4030007120 S.CERAMIC
C182 4030006900 S.CERAMIC
C191 4030006880 S.CERAMIC
C192 4030006900 S.CERAMIC
C193 4030007100 S.CERAMIC
C194 4030007160 S.CERAMIC
C195 4030007070 S.CERAMIC
C196 4030006900 S.CERAMIC
C197 4030006900 S.CERAMIC
C198 4030007080 S.CERAMIC
C199 4030007030 S.CERAMIC
C200 4030007080 S.CERAMIC
J101 6510021270 S.CONNECTOR
EP1 0910050954 PCB

[PLL UNIT]

REF ORDER
NO. NO.
IC101 1140003641 S.IC
IC201 1110003300 S.IC
IC231 1110003090 IC
IC271 1180000420 S.IC
IC281 1110002030 IC
IC291 1180001070 S.IC
IC461 1130009230 S.IC
IC541 1110003320 S.IC
IC901 1140004550 S.IC
Q1 1560000330 S.FET
Q10 1530002570 S.TRANSISTOR
Q21 1530002060 S.TRANSISTOR
Q51 1530002060 S.TRANSISTOR
Q71 1530002060 S.TRANSISTOR
Q141 1590001330 S.TRANSISTOR
Q142 1590001330 S.TRANSISTOR
Q143 1590001330 S.TRANSISTOR
Q144 1590001330 S.TRANSISTOR
Q145 1590001330 S.TRANSISTOR
Q161 1530002560 S.TRANSISTOR
Q232 1590000680 S.TRANSISTOR
Q251 1590000720 S.TRANSISTOR
Q261 1590002310 S.TRANSISTOR
Q301 1560000490 S.FET
Q321 1530003090 S.TRANSISTOR
Q322 1590000720 S.TRANSISTOR
Q331 1560000490 S.FET
Q351 1530003090 S.TRANSISTOR
Q352 1590000720 S.TRANSISTOR
Q361 1560000490 S.FET
Q362 1530002690 S.TRANSISTOR
Q381 1530003090 S.TRANSISTOR
Q391 1530002690 S.TRANSISTOR
Q461 1590000720 S.TRANSISTOR
Q491 1560000540 S.FET
Q521 1590002480 S.TRANSISTOR
5 - 12
DESCRIPTION
C1608 CH 1H 221J-T-A
C1608 JB 1C 104KT-N
C1608 CH 1H 221J-T-A
C1608 JB 1H 122K-T-A
C1608 CH 1H 101J-T-A
C1608 CH 1H 331J-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1E 103K-T-A
C1608 CH 1H 390J-T-A
C1608 CH 1H 750J-T-A
C1608 CH 1H 151J-T-A
C1608 CH 1H 240J-T-A
C1608 CH 1H 151J-T-A
C1608 CH 1H 121J-T-A
C1608 CH 1H 680J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 331J-T-A
C1608 CH 1H 820J-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1E 103K-T-A
C1608 CH 1H 560J-T-A
C1608 CH 1H 181J-T-A
C1608 CH 1H 330J-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 CH 1H 390J-T-A
C1608 CH 1H 150J-T-A
C1608 CH 1H 390J-T-A
AXK5S20045P
B 5222D
DESCRIPTION
SC-1246
M5282FP 70CD
LA4425A
TA78L05F (TE12R)
TA7808S
TA7805F (TE16L)
LMX2306TMX
µPC2710T-E3
M65343FP/SC1287
2SK210-GR (TE85R)
2SC4405-3-TL
2SC4081 T107 R
2SC4081 T107 R
2SC4081 T107 R
DTA114EUA T106
DTA114EUA T106
DTA114EUA T106
DTA114EUA T106
DTA114EUA T106
2SC4403-3-TL
DTC114EUA T106
DTA144EUA T106
DTC114EE TL
2SK508 K52 T2B
2SC4213-B (TE85R)
DTA144EUA T106
2SK508 K52 T2B
2SC4213-B (TE85R)
DTA144EUA T106
2SK508 K52 T2B
2SC4116-GR (TE85R)
2SC4213-B (TE85R)
2SC4116-GR (TE85R)
DTA144EUA T106
2SK880-Y (TE85R)
UMC3N TR
S.=Surface mount
