• PA UNIT

Idling current J571
pre-setting

• MAIN AND FILTER UNITS

W16
SWR detection
check point
4 - 7
R214
Drive idling
adjustment
R162
R174
Final idling
R231
adjustment
R175
C58 SWR detection
adjustment
CP1071
SWR detection
pre-setting
