Icom IC-706MKIIG Service Manual page 32

[MAIN BOARD]
REF ORDER
NO. NO.
R992 7030003750 S.RESISTOR
R993 7030003670 S.RESISTOR
R994 7030003670 S.RESISTOR
R995 7030003450 S.RESISTOR
R996 7030003440 S.RESISTOR
R998 7030003600 S.RESISTOR
R999 7310002740 S.TRIMMER
R1000 7030003410 S.RESISTOR
R1001 7030003660 S.RESISTOR
R1002 7310002720 S.TRIMMER
R1003 7030003660 S.RESISTOR
R1004 7030003560 S.RESISTOR
R1011 7030003320 S.RESISTOR
R1012 7030003620 S.RESISTOR
R1013 7030003580 S.RESISTOR
R1014 7030003830 S.RESISTOR
R1015 7030003280 S.RESISTOR
R1016 7030003640 S.RESISTOR
R1017 7030003560 S.RESISTOR
R1018 7030003680 S.RESISTOR
R1019 7030003480 S.RESISTOR
R1020 7030003760 S.RESISTOR
R1021 7030003320 S.RESISTOR
R1022 7030003680 S.RESISTOR
R1023 7030003680 S.RESISTOR
R1024 7030003340 S.RESISTOR
R1025 7030003320 S.RESISTOR
R1026 7030003680 S.RESISTOR
R1027 7030003440 S.RESISTOR
R1028 7030003440 S.RESISTOR
R1029 7030003560 S.RESISTOR
R1030 7030003560 S.RESISTOR
R1031 7030003560 S.RESISTOR
R1041 7030003320 S.RESISTOR
R1042 7310002790 S.TRIMMER
R1043 7030005680 S.RESISTOR
R1044 7030005680 S.RESISTOR
R1045 7310002720 S.TRIMMER
R1046 7030003440 S.RESISTOR
R1047 7030003440 S.RESISTOR
R1048 7030003430 S.RESISTOR
R1049 7030003450 S.RESISTOR
R1050 7030003380 S.RESISTOR
R1051 7030003550 S.RESISTOR
R1052 7030003380 S.RESISTOR
R1054 7030003420 S.RESISTOR
R1055 7030003560 S.RESISTOR
R1057 7030003440 S.RESISTOR
R1061 7030003400 S.RESISTOR
R1062 7030003440 S.RESISTOR
R1070 7030003650 S.RESISTOR
R1071 7030003640 S.RESISTOR
R1072 7030003760 S.RESISTOR
R1073 7030003800 S.RESISTOR
R1074 7030003840 S.RESISTOR
R1075 7030003560 S.RESISTOR
R1076 7030003680 S.RESISTOR
R1077 7030003720 S.RESISTOR
R1079 7030003380 S.RESISTOR
R1080 7310002800 S.TRIMMER
R1082 7310002800 S.TRIMMER
R1084 7310002800 S.TRIMMER
R1086 7310002800 S.TRIMMER
R1088 7310002800 S.TRIMMER
R1091 7030003380 S.RESISTOR
R1092 7030003400 S.RESISTOR
R1093 7030003560 S.RESISTOR
R1094 7030003340 S.RESISTOR
R1095 7030004710 S.RESISTOR
R1096 7030003600 S.RESISTOR
R1097 7030003560 S.RESISTOR
R1098 7030003560 S.RESISTOR
R1099 7030003560 S.RESISTOR
R1100 7030003360 S.RESISTOR
R1101 7030003360 S.RESISTOR
R1102 7030003440 S.RESISTOR
R1103 7030003200 S.RESISTOR
R1104 7030003320 S.RESISTOR
R1111 7030003440 S.RESISTOR
R1112 7030003800 S.RESISTOR
R1113 7030003680 S.RESISTOR
R1114 7030003560 S.RESISTOR
DESCRIPTION
ERJ3GEYJ 394 V (390 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
RV-150 (RH03A3A14X0FC) 103
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 683 V (68 kΩ)
RV-148 (RH03A3AS3X0DA) 472
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 185 V (1.8 MΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 101 V (100 Ω)
RV-155 (RH03A3AE5) 154
RR0816R-473-D (47 kΩ)
RR0816R-473-D (47 kΩ)
RV-148 (RH03A3AS3X0DA) 472
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 331 V (330 Ω)
RV-156 (RH03A3AJ5) 224
RV-156 (RH03A3AJ5) 224
RV-156 (RH03A3AJ5) 224
RV-156 (RH03A3AJ5) 224
RV-156 (RH03A3AJ5) 224
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 475 V (4.7 MΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
[MAIN BOARD]
REF ORDER
NO. NO.
R1115 7030003470 S.RESISTOR
R1116 7030003400 S.RESISTOR
R1121 7030003640 S.RESISTOR
R1122 7030003640 S.RESISTOR
R1123 7030003620 S.RESISTOR
R1124 7030003620 S.RESISTOR
R1125 7310002740 S.TRIMMER
R1126 7030003800 S.RESISTOR
R1127 7030003400 S.RESISTOR
R1128 7030003640 S.RESISTOR
R1131 7030003560 S.RESISTOR
R1132 7030003440 S.RESISTOR
R1133 7030003680 S.RESISTOR
R1141 7030003640 S.RESISTOR
R1142 7030003640 S.RESISTOR
R1143 7030003760 S.RESISTOR
R1144 7030003760 S.RESISTOR
R1145 7030003520 S.RESISTOR
R1146 7030003760 S.RESISTOR
R1147 7030003760 S.RESISTOR
R1148 7030003760 S.RESISTOR
R1149 7030003540 S.RESISTOR
R1150 7030003520 S.RESISTOR
R1161 7030003680 S.RESISTOR
R1162 7030003680 S.RESISTOR
R1163 7030003580 S.RESISTOR
R1164 7030003590 S.RESISTOR
R1165 7030003680 S.RESISTOR
R1166 7030003740 S.RESISTOR
R1167 7030003680 S.RESISTOR
R1168 7030003680 S.RESISTOR
R1169 7030003700 S.RESISTOR
R1170 7030003680 S.RESISTOR
R2001 7030003360 S.RESISTOR
R2002 7030003440 S.RESISTOR
R2003 7030003440 S.RESISTOR
R2004 7030003640 S.RESISTOR
R2005 7030003640 S.RESISTOR
R2011 7030003320 S.RESISTOR
R2012 7030003440 S.RESISTOR
R2013 7030003440 S.RESISTOR
R2014 7030003440 S.RESISTOR
R2015 7030003440 S.RESISTOR
R2016 7030003440 S.RESISTOR
R2017 7030003440 S.RESISTOR
R2018 7030003440 S.RESISTOR
R2019 7030003440 S.RESISTOR
R2021 7030003640 S.RESISTOR
R2041 7030003440 S.RESISTOR
R2042 7030003440 S.RESISTOR
R2044 7030003440 S.RESISTOR
R2045 7030003640 S.RESISTOR
R2051 7030003440 S.RESISTOR
R2052 7030003440 S.RESISTOR
R2053 7030003440 S.RESISTOR
R2054 7030003440 S.RESISTOR
R2055 7030003440 S.RESISTOR
R2056 7030003440 S.RESISTOR
R2057 7030003440 S.RESISTOR
R2058 7030003440 S.RESISTOR
R2061 7030003320 S.RESISTOR
R2062 7030003320 S.RESISTOR
R2063 7030003320 S.RESISTOR
R2064 7030003320 S.RESISTOR
R2065 7030003320 S.RESISTOR
R2072 7030003440 S.RESISTOR
R2074 7030003440 S.RESISTOR
R2076 7030003800 S.RESISTOR
R2077 7030003640 S.RESISTOR
R2081 7030003520 S.RESISTOR
R2084 7030003520 S.RESISTOR
R2085 7030003520 S.RESISTOR
R2086 7030003440 S.RESISTOR
R2087 7030006560 S.RESISTOR
R2088 7030006560 S.RESISTOR
R2089 7030006560 S.RESISTOR
R2090 7030006560 S.RESISTOR
R2101 7030003520 S.RESISTOR
R2102 7030003520 S.RESISTOR
R2103 7030003520 S.RESISTOR
R2104 7030003520 S.RESISTOR
R2105 7030003520 S.RESISTOR
5 - 7
DESCRIPTION
ERJ3GEYJ 182 V (1.8 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
RV-150 (RH03A3A14X0FC) 103
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
RR0816P-223-D (22 kΩ)
RR0816P-223-D (22 kΩ)
RR0816P-223-D (22 kΩ)
RR0816P-223-D (22 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
S.=Surface mount
