Icom IC-706MKIIG Service Manual page 49

[MAIN BOARD]
REF. NO. ORDER NO.
MP1 8510011950 2177 HPF case
MP2 8510005990 724 shield case cover
MP3 8510012400 1691 D/A case 2177 D/A case
MP4 8930014140 Earth spring (D)
MP5 8930014140 Earth spring (D)
MP6 8310045930 2177 shield plate
MP7 8510010460 1691 main shield plate
MP8 8930014140 Earth spring (D)
MP9 8930017200 752 earth spring
MP10 8930017200 752 earth spring
MP14 8510012410 2177 main S-plate
[DRIVER BOARD]
REF. NO. ORDER NO.
MP1 8410002270 2177 heatsink
[PLL UNIT]
REF. NO. ORDER NO.
MP1 8510012260 2177 PLL shield case
MP2 8510010850 1897 D/A case
MP5 8510005150 602 shield case
MP6 8510012140 2177 shield cover
MP7 8510005150 602 shield case
MP8 8510012140 2177 shield cover
MP9 8510005150 602 shield case
MP10 8510012140 2177 shield cover
MP11 8510010150 1691 D/A case
MP12 8510011980 2177 VCO case
MP13 8510011990 2177 VCO cover
MP14 8810009000 Screw PH No. 0 M2.6 x 5 ZK
MP15 8510011970 2177 OSC case
MP16 8930001170 Earth spring (A)
MP18 8510011250 1897 main shield plate
MP19 8510011960 2177 OSC cover
MP20 8930049151 2177 PLL spring-1
MP21 8930043100 Sponge (EU)
MP23 8930030220 Rubber sheet (L)
MP24 8930049460 2177 VCO angle
MP25 8930024170 Earth spring (G)
MP26 8930049470 Rubber sheet (AS)
MP27 8930049470 Rubber sheet (AS)
MP28 8930036870 Sponge (DZ)
MP29 8930014140 Earth spring (D)
MP30 8930017200 752 earth spring
MP31 8930017200 752 earth spring
MP32 890028380 SHEET (C)
[PA PARTS]
REF. NO. ORDER NO.
F591 5210000130 Fuse FGB 4A
J19 6510001920 Connector 1490R [TUNER]
J641 6450000140 Connector HSJ0807-01-010
P8 6510003780 Connector LLR-06 [DC 13.8V]
MP101 8930014140 Earth spring (D)
MP231 8860001130 2177 rug
MP232 8930049100 2177 PA spring
MP233 8930014140 Earth spring (D)
MP234 8860001130 2177 rug
MP451 8510012150 2177 PA shield plate
MP501 8930024170 Earth spring (G)
MP502 8930024170 Earth spring (G)
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
[FILTER BOARD]
REF. NO. ORDER NO.
1 J4 6450001490
1 J5 6450001640
1 J7 6450001650
1 J8 6450001660
1 J11 6510016170
1 J12 6510020080
1 J13 6510017150
1 J14 6450001840
1
1 MP1 8930017200
1 MP3 8930001170
[UNPACKING]
REF. NO. ORDER NO.
1
F1 5210000090
F2 5210000130
P1 5610000050
P2 5610000170
W1 8900006490
W2 8900006110
1
1
MC1 7700002000
1
1
MP1 8930007300
1
1
1
1
Screw abbreviations
1
1
1
4
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6 - 2
DESCRIPTION
Connector HLJ7001-01-3010 [ELEC-KEY]
Connector TCS5044-01-4111 [ACC]
Connector HSJ0836-01-500 [REMOTE]
Connector EX345GLB [RTTY]
Connector 52018-8835 [MIC]
Connector 52808-2090
Connector TMP-S01X-C1
Connector TCS7568-43-201 [DATA]
752 earth spring
Earth spring (A)
DESCRIPTION
Fuse FGB 30A
Fuse FGB 4A
Electronic keyer plug AP330
RTTY key plug AP370
DC power cable OPC-025D
ACC cable OPC-596
Hand microphone HM-103 ACC
Mic hunger
BT: Self-tapping PH: Pan head
NI: Nickel NI-ZU: Nickel-Zinc
BS: Brass ZK: Black
QTY.
1
1
1
1
1
1
1
1
1
1
QTY.
2
1
1
1
1
1
1
1
