Icom IC-706MKIIG Service Manual page 27

[DISPLAY BOARD]
REF ORDER
NO. NO.
R116 7030003430 S.RESISTOR
R117 7030003420 S.RESISTOR
R118 7030003460 S.RESISTOR
R119 7030003420 S.RESISTOR
R120 7030003460 S.RESISTOR
R121 7030003470 S.RESISTOR
R122 7030003420 S.RESISTOR
R123 7030003390 S.RESISTOR
R124 7030003390 S.RESISTOR
R125 7030003390 S.RESISTOR
R126 7030003390 S.RESISTOR
R127 7030003390 S.RESISTOR
R128 7030003390 S.RESISTOR
R129 7030003390 S.RESISTOR
R130 7030003390 S.RESISTOR
R131 7030003450 S.RESISTOR
R132 7030003450 S.RESISTOR
R133 7030003450 S.RESISTOR
R134 7030003450 S.RESISTOR
R135 7030003450 S.RESISTOR
R136 7030003450 S.RESISTOR
R137 7030003450 S.RESISTOR
R138 7030003450 S.RESISTOR
R140 7030003430 S.RESISTOR
R141 7030003430 S.RESISTOR
R142 7030003680 S.RESISTOR
C1 4030006880 S.CERAMIC
C2 4030006880 S.CERAMIC
C4 4030006880 S.CERAMIC
C5 4030012610 S.CERAMIC
C7 4030006880 S.CERAMIC
C8 4030006880 S.CERAMIC
C9 4030006880 S.CERAMIC
C10 4030007020 S.CERAMIC
C11 4030007020 S.CERAMIC
C12 4030011600 S.CERAMIC
C13 4030011600 S.CERAMIC
C14 4030011600 S.CERAMIC
C15 4030006860 S.CERAMIC
C16 4030006860 S.CERAMIC
C18 4030015170 S.CERAMIC
C19 4030011600 S.CERAMIC
C20 4030015170 S.CERAMIC
C21 4550002980 S.TANTALUM
C22 4030011600 S.CERAMIC
C23 4030011600 S.CERAMIC
C24 4550002980 S.TANTALUM
C25 4030011600 S.CERAMIC
C26 4030011600 S.CERAMIC
C27 4550002980 S.TANTALUM
C28 4550002980 S.TANTALUM
C29 4030011600 S.CERAMIC
C30 4030006880 S.CERAMIC
C31 4030006880 S.CERAMIC
C32 4030006880 S.CERAMIC
C33 4030006880 S.CERAMIC
C34 4030006850 S.CERAMIC
C35 4030006860 S.CERAMIC
C36 4030006860 S.CERAMIC
C37 4030011600 S.CERAMIC
C38 4030008890 S.CERAMIC
C39 4030011600 S.CERAMIC
C40 4030011600 S.CERAMIC
C41 4030011600 S.CERAMIC
C42 4030006880 S.CERAMIC
J1 6510019120 S.CONNECTOR
J2 6450001630 CONNECTOR
J3 6510018890 S.CONNECTOR
DS1 5040002020 S.LED
DS2 5040002010 S.LED
DS3 5040002020 S.LED
DS4 5030001670 LCD
DS5 5030001290 LED
S1 2260002250 S.SWITCH
DESCRIPTION
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 182 V (1.8 kΩ)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 104 V (100 kΩ)
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C2012 JB 1C 474K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 120J-T-A
C1608 CH 1H 120J-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C3216 JB 0J 475M-T-N
C1608 JB 1C 104KT-N
C3216 JB 0J 475M-T-N
TEMSVA 1C 225M-8L
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
TEMSVA 1C 225M-8L
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
TEMSVA 1C 225M-8L
TEMSVA 1C 225M-8L
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 472K-T-A
C1608 JB 1H 471K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 273K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1C 104KT-N
C1608 JB 1H 472K-T-A
S8B-PH-SM3-TB
HSJ1406-01-050
52559-1390
CL-170UR-CD-T
CL-170PG-CD-T
CL-170UR-CD-T
DLC-8309YBGF
D2264
LS22BB-2SD-PG-T
[DISPLAY BOARD]
REF ORDER
NO. NO.
S2 2260002250 S.SWITCH
S3 2260002540 S.SWITCH
S4 2260002540 S.SWITCH
S5 2260002540 S.SWITCH
S6 2260002540 S.SWITCH
S7 2260002540 S.SWITCH
S8 2260002540 S.SWITCH
S9 2260002540 S.SWITCH
S10 2260002540 S.SWITCH
S11 2260002550 S.SWITCH
S12 2260002550 S.SWITCH
S13 2260002250 S.SWITCH
S14 2260001680 S.SWITCH
W1 7030003860 S.JUMPER
W2 7120000470 JUMPER
WS1 8970023320 M.OTHER
EP1 0910050925 PCB
EP2 8930039790 LCD CONTACT
[VR BOARD]
REF ORDER
NO. NO.
R1 7210002780 VARIABLE
R2 7210002940 VARIABLE
J1 6510018890 S.CONNECTOR
S1 2220000540 SWITCH
EP1 0910050931 PCB
[MIAN BOARD]
REF ORDER
NO. NO.
IC151 1110003970 S.IC
IC221 1110004100 S.IC
IC222 1110004090 S.IC
IC231 1110004080 S.IC
IC281 1110004080 S.IC
IC351 1160000160 S.IC
IC521 1110003310 S.IC
IC571 1110003960 S.IC
IC631 1110003140 IC
IC791 1110003490 S.IC
IC811 1110003780 S.IC
IC841 1110004870 S.IC
IC861 1130009100 S.IC
IC891 1110003780 S.IC
IC931 1140005280 S.IC
IC971 1130006220 S.IC
IC981 1110003870 S.IC
IC1011 1130007660 S.IC
IC1041 1110004840 S.IC
IC1091 1110003780 S.IC
IC1141 1130009100 S.IC
IC2001 1140008070 S.IC
IC2101 1130009100 S.IC
IC2121 1130009020 S.IC
IC2122 1130007110 S.IC
IC2131 1130003760 S.IC
IC2161 1130009110 S.IC
IC2201 1110004310 S.IC
IC2202 1110003780 S.IC
5 - 2
DESCRIPTION
LS22BB-2SD-PG-T
SKQHFC
SKQHFC
SKQHFC
SKQHFC
SKQHFC
SKQHFC
SKQHFC
SKQHFC
SKQHFH
SKQHFH
LS22BB-2SD-PG-T
SKQDPB
ERJ3GE JPW V
ERDS2T0
SX2177 J LEAD SET (1)/DI
B 5207E
SRCN-1691-ZSS-505
DESCRIPTION
RV-300 (RK0972210) 10KB/10KB
TP96D231E20-20F-10KB-1897
52559-1390
SW-162 (SSSS22-2-11)
B 5208A
DESCRIPTION
µPC1658G-E1
TA4001F (TE85L)
TA4002F (TE85R)
µPC2709T-E3
µPC2709T-E3
TD62783AFN (S,EL)
µPC1688G-T1
µPC2713T-E3
LA1150N
TA31136FN (D,EL)
NJM2902V-TE1
TA4101F (TE12L)
BU4052BCFV-E2
NJM2902V-TE1
µPC5023GS-077-E1
TC4W53FU (TE12L)
NJM2058M-T1
LC7153M-TLM
NJM1496V-TE1
NJM2902V-TE1
BU4052BCFV-E2
HD6433337YA56F
BU4052BCFV-E2
X25650S8I-2.5T6
TC7W04FU (TE12L)
TC4S81F (TE85R)
S-80942ANMP-DD6-T2
M62352GP 75EC
NJM2902V-TE1
S.=Surface mount
