HP ProCurve 3500yl Release Notes page 108

Enhancements
Release K.13.16 Enhancements
ProCurve
==========================- CONSOLE - MANAGER MODE -============================
Authorized Manager IP
----------------------
10.10.240.2
10.10.245.3
10.10.246.200
10.10.245.30
Actions-> Back
Figure 7. Example of Menu Showing Authorized Managers with Access Method
ProCurve
==========================- CONSOLE - MANAGER MODE -============================
Authorized Manager IP: 10.10.245.3
IP Mask [255.255.255.255]:255.255.255.255
Access Level:Operator
Access Method:ssh
Actions-> Back
Figure 8. Example of Edit Menu for IP Managers
Setting the Management Access Method—Web Interface
To set the management access method in the Web interface, click on the Security tab, and then click
on the Authorized Addresses button. Fill in the fields with the correct information and click Add.
The Authorized Managers IP list in the Web interface is the same list that was configured with the
ip authorized-managers command in the CLI.
97
Switch Configuration - IP Managers
IP Mask
----------------------
255.255.255.255
255.255.255.255
255.255.255.255
255.255.255.0
Add Edit Delete
Switch Configuration - IP Managers
Add Edit Delete
22-Apr-2008
Access Level Access Method
------------ -------------
Manager all
Operator ssh
Operator tftp
Operator ssh
Help
22-Apr-2008
Help
20:17:53
20:17:53
