Installation
Installation, cont'd
Installation Overview
Install an SW RGB or SW YUV A Series switcher as follows:
1
2
3
4
5
6
7
Mounting the Switcher
Rack mounting the switcher
The SW2 switcher models are housed in half-rack width 1U high metal enclosures
that can be rack mounted with an optional 1U Universal Rack Mount Kit or 1U
Basic Rack Shelf (part #60-190-01 or 60-604-01). The SW4 and SW6 switcher models
are housed in rack-mountable, 1U high, 17" wide metal enclosures. The
appropriate rack mount kit is included with the SW4 and SW6 switchers. Rack
mount the switcher as follows:
SW2 models
1.
2.
3.
4.
5.
SW4 and SW6 models
1.
2.
3.
4.
2-2
SW RGB and YUV A Switchers • Installation
Turn off the input and output devices, and unplug their power cables.
If desired, mount the switcher in a rack, under furniture, or through furniture.
See Mounting the Switcher below.
Connect the input and output devices to the switcher (see Cabling and Rear
Panel Views on page 2-6).
If desired, connect a computer, RS-232 control system, or contact closure
device to the Remote connector (see Remote connection on page 2-9).
Plug the switcher and, if appropriate, the input devices and output devices
into a grounded AC source.
Turn on the input and output devices.
The image from each input device should appear on the output devices, and
you should be able to switch from one input device to another. If this does
not happen, double check steps 3 through 5 and make adjustments as needed.
If rubber feet were installed on the bottom of the switcher, remove them.
Place the switcher on one half of the optional 1U (one unit high, 19" wide)
rack shelf (part #60-190-01). Align the front of the switcher with the front of
the shelf, and align the threaded holes on the bottom of the switcher with the
holes in the rack shelf (figure 2-1).
Secure the switcher to the rack shelf with the two provided 4-40 x 3/16"
machine screws. Insert the screws from the underside of the shelf, and
securely fasten them through diagonally opposite corners as shown in
figure 2-1.
Fasten the false front panel (provided with the rack shelf) to the unoccupied
side of the rack (as shown in figure 2-1), or install a second half-rack-width
device in that side by repeating steps 1 through 3.
Secure the rack shelf to the rack using four 10-32 x ¾" bolts. Insert the bolts
through #10 beveled washers, then through the holes in the rack ears.
If rubber feet were installed on the bottom of the switcher, remove them.
Attach the rack mount brackets to the switcher with eight #8 machine screws,
provided (figure 2-2).
Insert the switcher into the rack, align the holes in the mounting bracket with
those of the rack.
Secure the switcher to the rack using the supplied machine screws.
