Audio Connections

The iStomp has stereo 1/4" audio inputs and outputs.The pedal that is loaded into the iStomp
will determine which inputs and outputs are active. For mono in pedals, only IN 1 is active and
can be used – IN 2 is disabled on all mono in pedals. From the Stomp Shop app, tap the INFO
button for the pedal to view its cable connection requirements.When using mono in
pedals, both outputs will be active and can be used.
When stereo pedals are loaded into the iStomp, you have the option of using the pedal in a
mono or stereo configuration.Therefore, you can use the IN 1 and OUT 1 connections (mono),
the IN 1 and both OUT 1 and OUT 2 connections (mono in/stereo out), or both IN 1/IN 2
and OUT 1/OUT 2 connections (stereo in/stereo out). Connection diagrams are provided on
the proceeding pages.
9
