Configuration Menu
Figure 4 represents the OC-3 MUX Configuration
menu. This read-only screen displays configuration data
pertaining to the OC-3 MUX. Information such as
software revision will change and reflect new software
as upgrades are performed.
Shelf:
1
Slot:
Unacknowledged Alarms: None
Shelf:
1
Slot:
Unacknowledged Alarms: None
8
B
Total Access System
Configuration
Unit Name
CLEI Code
Part Number
Serial Number
Product Revision
Software Revision : A00.21
'?' - System Help Screen
Figure 4. Configuration Menu
B
Total Access System
Provisioning
1.
OC-3 Provisioning
2.
DS3 Provisioning
3.
Mux Provisioning
Selection:
'?' - System Help Screen
Figure 5. Provisioning Menu
Provisioning Menu
Figure 5 represents the top level of the Provisioning
menu. Traffic-affecting provisioning changes can only
be made when the Service State of the OC-3 MUX is in
the "Out of Service, Maintenance" mode or the "Out of
Service, Unassigned" mode. DS3 Line Build Out can
also be changed while the related DS3 is out of service
regardless of the OC-3 MUX service state.
: OC-3 L3 MUX
: M3C3BBGAAA
: 1181031L3
: 01/03/02
: A
01/06/03 12:07
01/06/03 16:46
61181031L3-5A
