Product Description
The external components on the bottom of the computer are
shown in Figure 1-6 and described in Table 1-8.
Figure 1-6. Bottom Components
Item Component
1 Hard drive retention screw
2 Hard drive bay
3 Mini PCI communications
compartment
1–20
Table 1-8
Bottom Components
Function
Secures the hard drive to the
computer.
Supports the primary hard drive.
The hard drive is secured to the
computer by one screw.
Contains the mini PCI modem
card.
