QuickSpecs
Overview
W h a t ' s N e w
Mobile Intel Pentium 4
processors-M –– up to 1.7 GHz
400-MHz bus
ATI Mobility Radeon 7500
Graphics Controller
MultiPort wireless communication
options
Dual Pointing Device
Common Port Replicator,
Advanced Port Replicator, and
External MultiBay Options
A t A G l a n c e
Mobile Intel Pentium 4 processors
–– up to 1.7 GHz
15-inch XGA
Configurations as light as
6.82 lb/3.10 kg weight
256 MB DDR SDRAM (266
MHz), Upgradeable to 1024 MB
Up to 30-GB SMART hard drives
Mini PCI modem and integrated
NIC
Full-size keyboard
Microsoft Windows XP Pro and
Microsoft Windows 2000
Protected by a Three-year,
Worldwide Limited Warranty —
certain restrictions and exclusions
apply. Consult the Compaq
Customer Support Center for
details.
W h a t ' s S p e c i a l
Intel Pentium 4 processors
All-in-one convenient design
Latest USB interface
Wireless features through \award-
winning MultiPort
New Common Docking Options
DA-11408
North America — Version 4 — July 9, 2002
Compaq Evo Notebook N1000c
1
Advertisement
Table of Contents
Related Manuals for Compaq N1000c
Summary of Contents for Compaq N1000c
- Page 1 W h a t ’ s S p e c i a l Intel Pentium 4 processors All-in-one convenient design Latest USB interface Wireless features through \award- winning MultiPort New Common Docking Options DA-11408 North America — Version 4 — July 9, 2002 Compaq Evo Notebook N1000c...
-
Page 2: Standard Features
E a s y A c c e s s I n t e r n e t The Evo Notebook N1000c comes with three Easy Access Buttons (EAB) designed to increase customer B u t t o n s productivity by providing one-touch access to helpful Compaq information, favorite Internet destinations, or default e-mail application. - Page 3 Reference Guide Norton Internet Security Compaq Easy Access Button Software Each unit is shipped with a CD kit for quick recovery (erases hard disk and restores manufacturer installed image) S y s t e m R e c o v e r y...
- Page 4 B a t t e r y Standard 8-cell Lithium-Ion battery. The Evo Notebook N1000c provides over 3 hours of battery life using the standard 8-cell Lithium-Ion battery. NOTE: Actual results may vary with product model, configuration, and individual usage. Compaq results of 3:07 NOTE: This test was performed without independent verification by eTesting Labs Inc.
- Page 5 QuickSpecs Compaq Evo Notebook N1000c Standard Features The Etymology of a Model name: N a m i n g C o n v e n t i o n DA-11408 North America — Version 4 — July 9, 2002...
- Page 6 Video Memory Audio Operating System Warranty DA-11408 North America — Version 4 — July 9, 2002 Compaq Evo Notebook N1000c 15-inch color TFT XGA 1.7 GHz Intel Pentium 4 processor-M 512KB, L2 Cache Standard 256 MB (266 MHz) DDR SDRAM...
-
Page 7: Wireless Connectivity
USB Diskette Drive Wireless Connectivity 802.11b MultiPort Wireless LAN module Bluetooth MultiPort module Compaq WL110 Wireless LAN PC Card Compaq WL510 Wireless Enterprise Access Point Compaq WL410 Wireless SMB Access Point Compaq WL310 Home Office Access Point Compaq Range Extender Antenna CDPD WWAN PC Card (U.S. -
Page 8: Input Devices
External 10-Key Numeric Keypad (carbon) USB EZ Access Keyboard Wireless Keyboard and Mouse Security Biometric PC Card Security Cable Lock Compaq Smart Card PC Card Reader Invaluable Accessories Parallel port cable for diskette drive MP1200 Microportable Projector MP3800 Microportable Projector MP4800 Microportable Projector... - Page 9 NOTE: This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only Compaq branded memory modules to ensure compatibility. Following are memory options available from Compaq:...
- Page 10 DVD-ROM Drive CD-ROM Drive 1.44-MB Diskette Drive Hard Drives 30-GB SMART Hard Drive DA-11408 North America — Version 4 — July 9, 2002 Compaq Evo Notebook N1000c Dedicated optical drive Primary Hard drive Dedicated disk drive Drive Supported Dedicated optical drive...
-
Page 11: System Unit
Backlight Character Display Total Power Consumption DA-11408 North America — Version 4 — July 9, 2002 Compaq Evo Notebook N1000c 15-inch panel displays 1.55 x 12.89 x 10.53 in/3.95 x 32.75 x 26.75 cm 15-inch LCD, DVD/CD-RW, 7.09 lb/3.22 kg... -
Page 12: Hard Drives
Sectors per track Tracks per side Read/Write heads Access Times DA-11408 North America — Version 4 — July 9, 2002 Compaq Evo Notebook N1000c 0.22 lb/99 g 30 GB 0.374 in / 9.5 mm 2.75 in / 70 mm ATA-5... -
Page 13: External Ac Adapter
Data Transfer Rate (typical, including settling) Start-up Time Stop Time DA-11408 North America — Version 4 — July 9, 2002 Compaq Evo Notebook N1000c 0.85 lb/0.385 kg Operating Watts Operating Voltage 110 to 240 VAC RMS Operating Current 1.5 A RMS... - Page 14 Media Access Protocol OS Support Protocols Supported LED Activity DA-11408 North America — Version 4 — July 9, 2002 Compaq Evo Notebook N1000c Compaq MultiPort 0.22 lb/100 g (maximum) Operating, 14 to 149 F/–10 to 65 C Non-operating –40 to 176 F/–40 to 80 C...
-
Page 15: Operating Distance
Data Rates and throughput Antenna type Range Profile Support DA-11408 North America — Version 4 — July 9, 2002 Compaq Evo Notebook N1000c Data Rate Operating Distance 11 Mbps 1000 feet – Open sight 100 feet – Closed space (Steel Space) 5.5 Mbps... -
Page 16: Protocols Supported
OS Support Protocols Supported LED Activity Certifications DA-11408 North America — Version 4 — July 9, 2002 Compaq Evo Notebook N1000c Service Discovery (determine what Bluetooth devices are within range and support authorization) Synchronization: PDAs to PCs Portable to Desktop File Transfer: File and directory browsing and navigation on another Bluetooth device. - Page 17 Technical Specifications Form Factor Type III Mini PCI 56K (V.92) Modem Power Management Support APM Revision 1.2, ACPI, Compaq Power Management Extensions for Microsoft Approvals/Certifications Modem Device Driver Name Data Mode Capabilities Fax Mode Capabilities Command Set DA-11408 North America — Version 4 — July 9, 2002...
-
Page 18: Software Support
U.S. and other countries. All other product names mentioned herein may be trademarks of their respective companies. Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information is provided as is without warranty of any kind and is subject to change without notice.
