Package Mechanical Specifications
3.6

Processor Mass Specification

The typical mass of the processor is 35g. This mass [weight] includes all the
components that are included in the package.
3.7

Processor Materials

Table 3-3
Table 3-3.

Processor Materials

Integrated Heat Spreader (IHS)
3.8

Processor Markings

Figure 3-4
identification of the processor.
Figure 3-4.

Processor Top-Side Markings

Datasheet
lists some of the package components and associated materials.
Component
Substrate
Substrate Lands
shows the topside markings on the processor. This diagram is to aid in the
INTEL
BRAND
SLxxx [COO]
SPEED/CACHE/INTC/FMB
[FPO]
Material
Nickel Plated Copper
Fiber Reinforced Resin
Gold Plated Copper
©'07 PROC#
M
e
4
35
