Intel Core i7 Extreme Edition Datasheet page 38

Table 4-1. Land Listing by Land Name
(Sheet 3 of 36)
Land
Land Name
No.
DDR0_DQ[3] R42
DDR0_DQ[30] C38
DDR0_DQ[31] B38
DDR0_DQ[32] B5
DDR0_DQ[33] C4
DDR0_DQ[34] F1
DDR0_DQ[35] G3
DDR0_DQ[36] B6
DDR0_DQ[37] C6
DDR0_DQ[38] F3
DDR0_DQ[39] F2
DDR0_DQ[4] W40
DDR0_DQ[40] H2
DDR0_DQ[41] H1
DDR0_DQ[42] L1
DDR0_DQ[43] M1
DDR0_DQ[44] G1
DDR0_DQ[45] H3
DDR0_DQ[46] L3
DDR0_DQ[47] L2
DDR0_DQ[48] N1
DDR0_DQ[49] N2
DDR0_DQ[5] W42
DDR0_DQ[50] T1
DDR0_DQ[51] T2
DDR0_DQ[52] M3
DDR0_DQ[53] N3
DDR0_DQ[54] R4
DDR0_DQ[55] T3
DDR0_DQ[56] U4
DDR0_DQ[57] V1
DDR0_DQ[58] Y2
DDR0_DQ[59] Y3
DDR0_DQ[6] U41
DDR0_DQ[60] U1
DDR0_DQ[61] U3
DDR0_DQ[62] V4
DDR0_DQ[63] W4
DDR0_DQ[7] T42
38
Buffer
Direction
Type
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
Table 4-1. Land Listing by Land Name
(Sheet 4 of 36)
Land
Land Name
No.
DDR0_DQ[8] N41
DDR0_DQ[9] N43
DDR0_DQS_N[0] U43
DDR0_DQS_N[1] M41
DDR0_DQS_N[2] G41
DDR0_DQS_N[3] B40
DDR0_DQS_N[4] E4
DDR0_DQS_N[5] K3
DDR0_DQS_N[6] R3
DDR0_DQS_N[7] W1
DDR0_DQS_P[0] T43
DDR0_DQS_P[1] L41
DDR0_DQS_P[2] F41
DDR0_DQS_P[3] B39
DDR0_DQS_P[4] E3
DDR0_DQS_P[5] K2
DDR0_DQS_P[6] R2
DDR0_DQS_P[7] W2
DDR0_MA[0] A20
DDR0_MA[1] B21
DDR0_MA[10] B19
DDR0_MA[11] A26
DDR0_MA[12] B26
DDR0_MA[13] A10
DDR0_MA[14] A28
DDR0_MA[15] B29
DDR0_MA[2] C23
DDR0_MA[3] D24
DDR0_MA[4] B23
DDR0_MA[5] B24
DDR0_MA[6] C24
DDR0_MA[7] A25
DDR0_MA[8] B25
DDR0_MA[9] C26
DDR0_ODT[0] F12
DDR0_ODT[1] C9
DDR0_ODT[2] B11
DDR0_ODT[3] C7
DDR0_RAS# A15
Land Listing
Buffer
Direction
Type
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS I/O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
CMOS O
