- Page 1 ® Intel Core i7-620LE/UE, i7-610E, ® ® i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
- Page 2 Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order. Copies of documents which have an order number and are referenced in this document, or other Intel literature may be obtained by calling 1-800-548-4725 or by visiting Intel's website at http://www.intel.com.
-
Page 3: Table Of Contents
CL6 - Cache Line Size ................90 6.2.8 HDR6 - Header Type ................90 6.2.9 PBUSN6 - Primary Bus Number ..............91 ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... - Page 4 VC0RCAP - VC0 Resource Capability ............135 6.3.6 VC0RCTL - VC0 Resource Control ............136 6.3.7 VC0RSTS - VC0 Resource Status............. 137 ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
- Page 5 Figures ® Intel CoreTM i7-620LE/UE, i7-610E, i5-520E and Intel® Celeron® Processor P4500, P4505 ® Series on the Intel CoreTM i7 processor based low-power platform ......... 9 ® Intel Flex Memory Technology Operation..............17 Dual-Channel Symmetric (Interleaved) and Dual-Channel Asymmetric Modes ....18 PCI Express* Related Register Structures in the ®...
- Page 6 VC0RCAP - VC0 Resource Capability................135 VC0RCTL - VC0 Resource Control................137 VC0RSTS - VC0 Resource Status ................138 ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
-
Page 7: Revision History
Revision Description January 2010 • Initial release of this document. • Added information for the Intel® Celeron® Processor P4500 and P4505 Series. April 2010 • Corrected first bullet in Section 2.1.1 to “No support for mixed ECC and non-ECC DIMM configurations.”... -
Page 8: Introduction And Features Summary
ICH). The two-chip platform consists of a processor and the Platform Controller Hub (PCH) and enables higher performance, lower cost, easier validation, and improved x-y footprint. The PCH may also be referred to as Mobile Intel® 5 Series Chipset (formerly ®... -
Page 9: I7-620Le/Ue, I7-610E, I5-520E And Intel
Introduction and Features Summary ® Figure 1. Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel® Celeron® Processor ® P4500, P4505 Series on the Intel Core i7 processor based low-power platform Dual-core Processor Intel C ore i7/i5 and C eleron Discrete G raphics... -
Page 10: Interfaces
• PCI Express Port 0 is mapped to PCI Device 1. • PCI Express Port 1 is mapped to PCI Device 6. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 11: Package
Introduction and Features Summary Package The Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series are available on a 34 x 28 mm BGA package (BGA1288). ® Note: Although the BGA1288 package is shared with Intel Core... -
Page 12: Terminology
This feature can prevent some classes of viruses or worms that exploit buffer overrun vulnerabilities and can thus help improve the overall security of the system. See the Intel® 64 and IA-32 Architectures Software Developer's Manuals for more detailed information. -
Page 13: Related Documents
Mobile Processor Series Datasheet http://www.intel.com ® Intel Core i7-620LE/UE, i7-610E and i5-520E Processor Series Datasheet http://www.intel.com Addendum Specification Update ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 14: Pch Documents
Introduction and Features Summary Table 2. PCH Documents Document Number/ Document Location Intel® 5 Series Chipset and Intel® 3400 Series Chipset Datasheet http://www.intel.com Table 3. Public Specifications Document Number/ Document Location Advanced Configuration and Power Interface Specification 3.0 http://www.acpi.info/ http://www.pcisig.com/ PCI Local Bus Specification 3.0... -
Page 15: Interfaces
512 MB 1 Gb 64 M x 8 13/10 1 GB 2 Gb 128 M x 16 14/10 ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 16: System Memory Timing Support
Channel A or Channel B DIMM connectors are populated in any order, but not both. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 17: Flex Memory Technology Operation
® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 18: Rules For Populating Memory Slots
Interfaces ® This mode is used when Intel Flex Memory Technology is disabled and both Channel A and Channel B DIMM connectors are populated in any order with the total amount of memory in each channel being different. Figure 3. -
Page 19: Dram Clock Generation
Section 3.2 2.2.1 PCI Express* Configuration Mechanism The PCI Express* link is mapped through a PCI-to-PCI bridge structure. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 20: Pci Express Port Bifurcation
Interfaces Figure 4. PCI Express* Related Register Structures in the ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series PCI-PCI Bridge PCI Compatible Port 0 PCI Express representing root Host Bridge Device Device PCI Express port... -
Page 21: Signal Description
Signalling Environment AC Specifications and are AC coupled. The buffers are not 3.3- V tolerant. Refer to the PCIe specification. Intel Flexible Display interface signals. These signals are compatible with PCI Express 2.0 Signaling Environment AC Specifications, but are DC coupled. The buffers are not 3.3-V tolerant. -
Page 22: I7-620Le/Ue, I7-610E, I5-520E And Intel
SDRAM components during the active state. There DDR3 is one Chip Select for each SDRAM rank. SA_ODT[1:0] On Die Termination: Active Termination Control. DDR3 ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 23: Memory Channel B
Chip Select: (1 per rank) Used to select particular SB_CS#[1:0] SDRAM components during the active state. There DDR3 is one Chip Select for each SDRAM rank. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 24: Reset And Miscellaneous Signals
Embedded Display Port — 0: An external Display Port device is connected to the Embedded Display Port • CFG[17:5]: Reserved configuration lands. Intel does not recommend a test point on the board for these lands. § § ® ®... -
Page 25: Electrical Specifications
. However, input signal drivers must comply with the signal quality specifications. is the termination on the DIMM and in not controlled by the processor. VTT_TERM ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... - Page 26 . However, input signal drivers must comply with the signal quality specifications. is the termination on the DIMM and in not controlled by the processor. VTT_TERM ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
-
Page 27: Processor Ball And Signal Information
Intel Celeron Processor P4500, P4505 Series package respectively. ® • Figure Figure Figure 7, and Figure 8 show the Top-Down view of the Intel ® ® Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series ballmap ® ®... - Page 28 Processor Ball and Signal Information ® ® ® Figure 5. Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Ballmap (Top View, Upper-Left Quadrant) DC_TES DC_TES DC_TES SB_DQS SB_DQ[4 SB_DQ[4 SB_DM[5 SB_DQS SB_DQ[3 SB_DQ[3 SB_DQ[3 SB_DQ[3 SB_DM[4...
- Page 29 Processor Ball and Signal Information ® ® ® Figure 6. Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Ballmap (Top View, Upper-Right Quadrant) SB_CK#[ SM_RCO SB_MA[4 SB_MA[2 SB_MA[8 SB_MA[1 SB_BS[2 SB_DQ[2 SB_DQ[3 SB_DQ[2 SB_DQ[2 SB_DQ[1 SB_DQS...
- Page 30 Processor Ball and Signal Information ® ® ® Figure 7. Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Ballmap (Top View, Lower-Left Quadrant) COMP3 COMP1 VCAP2 VCAP2 VTT0 VTT0 RSVD COMP2 RSVD VCAP2 VCAP2 RSVD RSVD...
-
Page 31: (Top View, Lower-Right Quadrant)
Processor Ball and Signal Information ® ® ® Figure 8. Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Ballmap (Top View, Lower-Right Quadrant) CFG[13] VTT0 VTT0 VTT0 VTT0 VAXG VAXG VAXG VAXG VAXG VAXG VAXG VTT1... -
Page 32: Processor P4500, P4505
Intel Core i7-620LE/ ® UE, i7-610E, i5-520E Table 12. Intel Core i7-620LE/ ® ® and Intel Celeron UE, i7-610E, i5-520E ® ® Processor P4500, P4505 and Intel Celeron Series Ball List by Ball Processor P4500, P4505 Name Series Ball List by Ball... - Page 33 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
-
Page 34: Series
Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer... - Page 35 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
- Page 36 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
- Page 37 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
- Page 38 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
- Page 39 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
- Page 40 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
- Page 41 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
- Page 42 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
- Page 43 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
- Page 44 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
- Page 45 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
-
Page 46: Processor P4500, P4505
Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer... - Page 47 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
- Page 48 Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Name Name Buffer...
-
Page 49: Series Ball List By Ball Number
Processor Ball and Signal Information ® Table 12. Intel Core i7-620LE/ UE, i7-610E, i5-520E ® ® and Intel Celeron ® Table 13. Intel Core i7-620LE/ Processor P4500, P4505 UE, i7-610E, i5-520E Series Ball List by Ball ® ® and Intel... - Page 50 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 51 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 52 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 53 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 54 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 55 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 56 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 57 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 58 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 59 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 60 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 61 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
-
Page 62: Processor P4500, P4505
Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer... - Page 63 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 64 Table 13. Intel Core i7-620LE/ UE, i7-610E, i5-520E UE, i7-610E, i5-520E ® ® ® ® and Intel Celeron and Intel Celeron Processor P4500, P4505 Processor P4500, P4505 Series Ball List by Ball Series Ball List by Ball Number Number Buffer...
- Page 65 TDI_M CMOS FDI_TX[3] FDI_TX#[5] FDI_TX[5] VSS_SENSE_VTT Analog VTT1 VTT1 VTT1 VTT1 VTT0 VTT0 VTT0 VTT0 VTT0 VTT0 VTT0 ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002...
- Page 66 VCAP2 RSVD RSVD RSVD RSVD FDI_TX[6] FDI_TX#[6] CMOS CMOS TDO_M CMOS CMOS RSVD VTT1 VTT1 VTT1 VTT1 VTT1 ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
- Page 67 VTT0 VCCPLL VCAP2 VCAP2 PREQ# Async GTL PRDY# Async GTL RSVD DPLL_REF_SSCLK# DIFF CLK FDI_TX#[7] FDI_TX[7] VTT1 VTT1 ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002...
- Page 68 VCCPLL VCCPLL VCAP2 VCAP2 RSVD RSVD DBR# DPLL_REF_SSCLK DIFF CLK VCCPWRGOOD_0 Async CMOS TAPPWRGOOD Async CMOS § § ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
-
Page 69: Processor Configuration Registers
Processor Configuration Registers Processor Configuration Registers This chapter is an Addendum to the Intel® Core i7-600, i5-500 and i3-300 Mobile Processor Series Datasheet. Contained in this chapter is any register information that is ® ® ® specific to the Intel... - Page 70 Write transactions to these bits go to both agents. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
-
Page 71: Deven - Device Enable
Allows for enabling/disabling of PCI devices and functions that are within the processor. The table below the bit definitions describes the behavior of all combinations of transactions to devices controlled by this register. All the bits in this register are Intel TXT Lockable. -
Page 72: Errsts - Error Status
1: Indicates that a DRAM Throttling condition occurred. 0: Software has cleared this flag since the most recent throttling event. Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 73: Errcmd - Error Command
ERRSTS register. The actual generation of the SERR message is globally enabled for Device #0 via the PCI Command register. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 74: Error Command Registers
0: Reporting of this condition via SERR messaging is disabled. For systems that do not support ECC this bit must be disabled. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 75: Smicmd - Smi Command
0: Reporting of this condition via SMI messaging is disabled. For systems that do not support ECC this bit must be disabled. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 76: C0Wrdatactrl - Channel 0 Write Data Control
ECC bits, during writes to DRAM. 0: The diagnostic feature is turned off. 14:0 4110h Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 77: Coeccerrlog - Channel 0 Ecc Error Log
This bit is cleared when it receives an indication that the CPU has cleared the corresponding bit in the ERRSTS register. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... - Page 78 This bit is cleared when it receives an indication that the CPU has cleared the corresponding bit in the ERRSTS register. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
-
Page 79: C1Wrdatactrl - Channel 1 Write Data Control
MERR on QW1 MERR on QW2 MERR on QW3 CERR on QW0 CERR on QW1 CERR on QW2 CERR on QW3. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 80: Pci Device 6
The PCI Express based specification defines two types of reserved bits. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 81: Pci Device 6 Register
RO; RW Address Memory Limit MLIMIT6 0000h RO; RW Address Prefetchable PMBASE6 FFF1h RO; RW Memory Base Address ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... - Page 82 Link Capabilities LCAP 03214C81h RO; RW-O Link Control LCTL 0000h RO; RW; RW- Link Status LSTS 1000h RWC; RO ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
- Page 83 LCTL2 0001h RO; RW-S; RW Link Status 2 LSTS2 0000h PCI Express-G PEGLC 00000000h RO; RW Legacy Control ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002...
-
Page 84: Vid6 - Vendor Identification
Table 24. VID6 - Vendor Identification Register Default RST/ Access Description Value 15:0 8086h Core Vendor Identification (VID6) PCI standard identification for Intel. 6.2.2 DID6 - Device Identification B/D/F/Type: 0/6/0/PCI Address Offset: 2-3h Default Value: 0047h Access: Size: 16 bits This register combined with the Vendor Identification register uniquely identifies any PCI device. -
Page 85: Pcicmd6 - Pci Command
The status of SERRs generated is reported in the PCISTS6 register. Core Reserved Not Applicable or Implemented. Hard wired to 0. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... - Page 86 0 = All of Device 6's I/O space is disabled. 1 = Enable the I/O address range defined in the IOBASE6, and IOLIMIT6 registers. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
-
Page 87: Pcists6 - Pci Status
Command register is set. Core Fast Back-to-Back (FB2B) Not Applicable or Implemented. Hard wired to 0. Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... - Page 88 Note that INTA emulation interrupts received across the link are not reflected in this bit. 000b Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
-
Page 89: Rid6 - Revision Identification
Indicates the programming interface of this device. This value does not specify a particular register set layout and provides no practical use for this device. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 90: Cl6 - Cache Line Size
Header Type Register (HDR) Returns 01 to indicate that this is a single function device with bridge header layout. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 91: Pbusn6 - Primary Bus Number
Secondary Bus Number (BUSN) This field is programmed by configuration software with the bus number assigned to PCI Express-G. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 92: Subusn6 - Subordinate Bus Number
A[11:0] are treated as 0. Thus the bottom of the defined I/O address range is aligned to a 4-KB boundary. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 93: Iolimit6 - I/O Limit Address
Devices between this upper limit and IOBASE6 is passed to the PCI Express hierarchy associated with this device. Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 94: Ssts6 - Secondary Status
Not Applicable or Implemented. Hard wired to 0. Core Reserved Core 66-/60-MHz Capability (CAP66) Not Applicable or Implemented. Hard wired to 0. Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 95: Mbase6 - Memory Base Address
Corresponds to A[31:20] of the lower limit of the memory range that is passed to PCI Express-G. Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 96: Mlimit6 - Memory Limit Address
Memory Address Limit (MLIMIT) Corresponds to A[31:20] of the upper limit of the address range passed to PCI Express-G. Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 97: Pmbase6 - Prefetchable Memory Base Address
Indicates that the upper 32 bits of the prefetchable memory region base address are contained in the Prefetchable Memory base Upper Address register at 28h. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 98: Pmlimit6 - Prefetchable Memory Limit Address
Indicates that the upper 32 bits of the prefetchable memory region limit address are contained in the Prefetchable Memory Base Limit Address register at 2Ch ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 99: Pmbaseu6 - Prefetchable Memory Base Address Upper
Corresponds to A[63:32] of the lower limit of the prefetchable memory range that is passed to PCI Express-G. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 100: Pmlimitu6 - Prefetchable Memory Limit Address Upper
Corresponds to A[63:32] of the upper limit of the prefetchable Memory range that is passed to PCI Express-G. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 101: Capptr6 - Capabilities Pointer
The value indicates to which input of the system interrupt controller this device's interrupt pin is connected. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 102: Intrpin6 - Interrupt Pin
Express Port. This will force the LTSSM to transition to the Hot Reset state (via Recovery) from L0, L0s, or L1 states. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... - Page 103 0 = Master Data Parity Error bit in Secondary Status register CANNOT be set. 1 = Master Data Parity Error bit in Secondary Status register CAN be set. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002...
-
Page 104: Pm_Capid6 - Power Management Capabilities
Capability ID (CID) Value of 01h identifies this linked list item (capability structure) as being for PCI Power Management registers. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 105: Pm_Cs6 - Power Management Control/Status
D0 by a system or bus segment reset will return to the device state D0 un-initialized with only PME context preserved if PME is supported and enabled. Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... - Page 106 Master Aborts in Device 0 PCISTS[13] There is no additional hardware functionality required to support these Power States. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
-
Page 107: Ss_Capid - Subsystem Id And Vendor Id Capabilities
Identifies the manufacturer of the subsystem and is the same as the vendor ID which is assigned by the PCI Special Interest Group. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 108: Msi_Capid - Message Signaled Interrupts Capability Id
64-bit memory address. This may need to change in future implementations when addressable system memory exceeds the 32-b/4-GB limit. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... - Page 109 1 = MSI is generated when we receive PME or HotPlug messages. INTA will not be generated and INTA Status (PCISTS6[3]) will not be set. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002...
-
Page 110: Ma - Message Address
The upper 16 bits are always set to 0. The lower 16 bits are supplied by this register. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 111: Peg_Capl - Pci Express-G Capability List
Core Device/Port Type (DPT) hard wired to 4h to indicate root port of PCI Express Root Complex. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 112: Dcap - Device Capabilities
Core Max Payload Size (MPS) hard wired to indicate 128B max supported payload for Transaction Layer Packets (TLP). ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 113: Dctl - Device Control
Other bits also control the full scope of related error reporting. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 114: Dsts - Device Status
Fatal Error Detected bit is not an option as support for AER will not be reported. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 115: Lcap - Link Capabilities
Indicates the PCI Express port number for the given PCI Express link. Matches the value in Element Self Description[31:24]. 23:22 Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... - Page 116 1b in this bit. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
- Page 117 Supported Link Speed – This field indicates the supported Link speed(s) of the associated Port. Defined encodings are: 0001b2.5-GT/s Link speed supported All other encodings are reserved. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002...
-
Page 118: Lctl - Link Control
Clock Power Management (as indicated by a 0b value in the Clock Power Management bit of the Link Capabilities Register) must hardwire this bit to 0b. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... - Page 119 Link state. Core Read Completion Boundary (RCB) hard wired to 0 to indicate 64 byte. Core Reserved (FEDLB) ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002...
-
Page 120: Lsts - Link Status
This bit must be set when the upstream component receives eight consecutive TS1 or TS2 ordered sets with the Autonomous Change bit set. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... - Page 121 00h: Reserved 01h: X1 02h: X2 04h: X4 08h: X8 10h: X16 All other encodings are reserved. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002...
-
Page 122: Slotcap - Slot Capabilities
Specifies the scale used for the Slot Power Limit Value. 1.0x 0.1x 0.01x 0.001x If this field is written, the link sends a Set_Slot_Power_Limit message. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 123: Slotctl - Slot Control
SLOTCTL - Slot Control Register (Sheet 1 of 3) Access Default RST/ Description Value 15:13 000b Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... - Page 124 If the Power Indicator Present bit in the Slot Capabilities register is 0b, this field is permitted to be read-only with a value of 00b. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
- Page 125 Reserved for Attention Button Pressed Enable (ABPE) When set to 1b, this bit enables software notification on an attention button pressed event. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002...
-
Page 126: Slotsts - Slot Status
(where the Slot Implemented bit of the PCI Express Capabilities Register is 0b), this bit must return 1b. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... - Page 127 If an Attention Button is implemented, this bit is set when the attention button is pressed. If an Attention Button is not supported, this bit must not be set. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002...
-
Page 128: Rctl - Root Control
Root Port, or by the Root Port itself. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 129: Rsts - Root Status
LCTL2 - Link Control 2 Register (Sheet 1 of 3) Access Default RST/ Description Value 15:13 000b Core Reserved (RSVD): ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... - Page 130 Default value is 000b. Components that support only the 2.5GT/s speed are permitted to hardwire this bit to 0b. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002...
-
Page 131: Lsts2 - Link Status 2
LSTS2 - Link Status 2 Register (Sheet 1 of 2) Access Default RST/ Description Value 15:1 0000h Core Reserved (Rsvd): ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 132: Peglc - Pci Express-G Legacy Control
General Message GPE Enable (GENGPE) 0 = Do not forward received GPE assert/deassert messages. 1 = Forward received GPE assert/deassert messages. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 133: Pci Device 6 - Extended Configuration
6.3.2 PVCCAP1 - Port VC Capability Register 1 B/D/F/Type: 0/6/0/MMR Address Offset: 104-107h Default Value: 00000000h Access: ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 134: Pvccap2 - Port Vc Capability Register 2
Default Value:00000000h Access: RO; Size:32 bits Describes the configuration of PCI Express Virtual Channels associated with this port. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 135: Pvcctl - Port Vc Control
VC0RCAP - VC0 Resource Capability (Sheet 1 of 2) Default Access RST/PWR Description Value 31:24 Core Reserved for Port Arbitration Table Offset Core Reserved ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 136: Vc0Rctl - Vc0 Resource Control
Default Value: 800000FFh Access: RO; RW; Size: 32 bits Controls the resources associated with PCI Express Virtual Channel 0. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 137: Vc0Rsts - Vc0 Resource Status
B/D/F/Type: 0/6/0/MMR Address Offset: 11A-11Bh Default Value: 0002h Access: Size: 16 bits Reports the Virtual Channel specific status. ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002... -
Page 138: Vc0Rsts - Vc0 Resource Status
Virtual Channel are cleared in both Components on a Link. Core Reserved Reserved for Port Arbitration Table Status (): ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series Datasheet Addendum April 2010 Document Number: 323178-002... -
Page 139: Intel ® Core Tm I7-620Le/Ue, I7-610E, I5-520E And Intel ® Celeron ® Processor P4500, P4505
Processor Configuration Registers ® ® ® Intel Core i7-620LE/UE, i7-610E, i5-520E and Intel Celeron Processor P4500, P4505 Series April 2010 Datasheet Addendum Document Number: 323178-002...
