Specifications and Agency Compliance

Specifications

Sensor operating temperature
Storage temperature
Storage/operating humidity range
Thermistor accuracy
Setpoint functional range
Setpoint markings
Housing material
Mounting
Resolution (display sensor)
Accuracy (display sensor)
Power consumption (display sensor)

Agency Compliance

•
•
•
BAS-SVX10C-EN
From 32°F to 122°F (0°C to 50°C)
From -40°F to 185°F (-40°C to 85°C)
5% to 95% relative humidity (RH), noncondensing
0.2°C at 25°C, 1%
Display sensor: 50°F to 89.6°F (10°C to 32°C)
All other sensors: 45°F to 95°F (7.2°C to 35°C)
Setpoint thumb wheel:
• 50°F to 85°F (in 5°F increments) and *, **
• 10°C to 29°C (in 3°C increments) and *, **
Dual setpoint slider:
• 50 to 85ºF (stamped every 5ºF)
• 10 to 29ºC (stamped every 3ºC)
Polycarbonate/ABS blend, UV protected, UL 94-5VA flammability rating, suitable for
application in a plenum
Fits a standard 2 in. by 4 in. junction box (vertical mount only). Mounting holes are spaced
3.2 in. (83 mm) apart on vertical center line. Includes mounting screws for junction box and
wall anchors for sheetrock walls. Overall dimensions: 2.9 in (74 mm) by 4.7 in. (119 mm)
0.125ºF over a range of 60 to 80ºF (15.6 to 26.7°C); 0.25ºF when outside this range
0.5°F over a range of 55 to 85°F (12.8 to 29.4ºC)
<1 VA
United States:
– UL listed: 94, 5 VA Flammability rating; 916, Energy management equipment
– FCC Part 15, Subpart B
Canada:
– CUL listed: 916, Energy management equipment
Europe:
– CE marked
