- Page 1 ™ ® GEE BEE Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni...
- Page 2 NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, Inc. For up-to-date product literature, visit www.horizonhobby.com and click on the support tab for this product. Meaning of Special Language: The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury.
-
Page 3: Table Of Contents
Gee Bee ® R2 BNF with only basic radio programming. And even though your new model is fully assembled, please read and follow this manual completely to be sure you’re ready to take full advantage of what this awesome RC aircraft has to offer. -
Page 4: Prefl Ight Checklist
Prefl ight Checklist 1. Charge fl ight battery. 6. Set dual rates and exponential. 2. Install fl ight battery in aircraft 7. Adjust center of gravity (once it has been fully charged). 8. Perform a radio system Range Check. 3. -
Page 5: Charging The Battery
Charging the Battery Your aircraft comes with a 2-Cell 7.4V 200mAh 25C Li-Po battery and a Celectra ™ 2S 7.4V DC Li-Po Charger that requires a 12V (11V-14V) DC power source. Refer to the battery warnings. It is recommended to charge the battery pack while you are inspecting the aircraft. -
Page 6: Transmitter And Receiver Binding
Transmitter and Receiver Binding Binding is the process of programming the receiver of the control unit to recognize the GUID (Globally Unique Identifi er) code of a single specifi c transmitter. You need to ‘bind’ your chosen Spektrum ™ DSM2 ®... -
Page 7: Arming The Esc
Arming the ESC Arming the ESC also occurs after binding as previously described, but subsequent connection of a fl ight battery requires the steps below. Lower throttle and throttle Install fl ight battery and Keep plane immobile trim to lowest settings. and away from wind for connect it to the ESC. -
Page 8: Control Centering
Control Centering Before the fi rst fl ights, or in the event of an accident, make sure the fl ight control surfaces are centered. Adjust the linkages mechanically if the control surfaces are not centered. Use of the transmitter sub-trims may not correctly center the aircraft control surfaces due to the mechanical limits of linear servos. -
Page 9: Dual Rates And Expos
Dual Rates and Expos To obtain the best fl ight performance, we High Rate Low Rate recommend using a DSM2/DSMX radio capable of Dual Rates and Expo. The suggested settings shown Aileron 100% here are the recommended starting settings. Adjust Elevator 100% according to the individual preferences after the... -
Page 10: Adjusting Center Of Gravity (Cg)
Adjusting Center of Gravity (CG) The CG location is 26mm back from leading edge The battery tray is oversized to allow for Center of of the wing at the root. This CG location has been Gravity adjustment. Start by placing the battery at determined with the included 2S 200mAh 7.4V the front edge of the battery tray with the connector Li-Po battery installed in the front of the... -
Page 11: Flying Tips And Repairs
CAUTION stick and trim to the lowest ® We recommend fl ying your E-fl ite UMX Gee Bee R2 possible positions during outside in moderate winds or in a large gymnasium. a crash could result in Always avoid fl ying near houses, trees, wires and damage to the ESC in the buildings. -
Page 12: Additional Safety Precautions And Warnings
Additional Safety Precautions and Warnings As the user of this product, you are solely This model is controlled by a radio signal subject responsible for operating it in a manner that does to interference from many sources outside your not endanger yourself and others or result in control. -
Page 13: Service Of Power Components
Service of Power Components Disassembly CAUTION: DO NOT handle propeller parts while the fl ight battery is connected. Personal injury could result. Propeller 1. The front of the cowling covers the battery compartment. Lift the cowling to access the battery compartment. 2. -
Page 14: Troubleshooting Guide
Troubleshooting Guide AS3X Problem Possible Cause Solution Control surfaces not Control surfaces may not have been Center control surfaces mechanically by at neutral position mechanically centered from factory adjusting the U-bends on control linkages when transmitter Aircraft was moved after the fl ight battery Disconnect and reconnect the fl... -
Page 15: Troubleshooting Guide (Continued)
Troubleshooting Guide (Continued) Problem Possible Cause Solution LED on receiver Less than a 5-second wait between fi rst Leaving transmitter on, disconnect and recon- fl ashes rapidly and powering on transmitter and connecting nect fl ight battery to aircraft aircraft will not re- fl... -
Page 16: Limited Warranty
Limited Warranty What this Warranty Covers Warranty Services Horizon Hobby, Inc. (“Horizon”) warrants to the original Questions, Assistance, and Services purchaser that the product purchased (the “Product”) will Your local hobby store and/or place of purchase cannot be free from defects in materials and workmanship at the provide warranty support or service. -
Page 17: Warranty And Service Information
Skid Protection Kufenschutzab- Couvercles de protec- Coperture protezione antisbandamento: UMX EFLU4547 Covers: UMX Gee deckung: UMX Gee tion: UMX Gee Bee R2 Gee Bee R2 Bee R2 Bee R2 Landing Gear & Tail Hauptfahrwerk u. Train d’atterrissage Set ingranaggi di... -
Page 18: Optional Parts And Accessories
Part # • Nummer Description Beschreibung Description Descrizione Numéro • Codice Power Cord for Anschlußstecker mit Câble d’alimentation Cavo alimentazione per EFLUC1008 EFLUC1007 Krokodilklemmen für EFLUC1007 EFLUC1007 EFLUC1007 DSM2 6 Ch Ultra DSM2 6 Kanal Ultra micro récepteur DSM2 6 Ch Ultra Micro AS3X 6voies DSM2 AS3X a Micro AS3X Ricevitore...
