PART IDENTIFICATION CHART

Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST in the center of this manual. Note: Some small parts
may have been pre-attached. If a part is not in the parts bag, check to see if it has been pre-attached. If a
part is missing, call toll-free 1-888-533-1333.
M5 Washer (39)
M6 Washer (44)
M8 Washer (37)
M10 Washer (71)
M4 x 12mm Self-tapping Screw (76)
M6 x 15mm Button Screw (40)
M4 x 16mm Self-tapping Screw (38)
M4 x 25mm Self-tapping Screw (42)
M10 x 20mm Bolt (66)
M10 Nylon Locknut (74)
M8 Nylon Locknut (41)
M10 x 49mm Bolt (65)
M6 x 63mm Button Screw (43)
M10 x 58mm Button Bolt (48)
M10 x 68mm Bolt (63)
M8 x 69mm Bolt (58)
M10 x 82mm Button Bolt (49)
M8 x 80mm Button Bolt (70)
M10 x 87mm Button Bolt (50)
M8 x 97mm Bolt (72)
M10 x 100mm Screw (45)
